SRS1020 - SRS10150
Taiwan Semiconductor
CREAT BY ART
10A, 20V - 150V Dual Common Cathode Schottky Rectifiers
FEATURES
- Low power loss, high efficiency
- Ideal for automated placement
- Guardring for overvoltage protection
- High surge current capability
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21
TO-263AB (D PAK)
MECHANICAL DATA
Case:
TO-263AB (D
2
PAK)
Molding compound, UL flammability classification rating 94V-0
Moisture sensitivity level: level 1, per J-STD-020
Part No. with suffix "H" means AEC-Q101 qualified
Packing code with suffix "G" means green compound (halogen-free)
Terminal:
Matte tin plated leads, solderable per JESD22-B102
Meet JESD 201 class 2 whisker test
Polarity:
As marked
Weight:
1.37 g (approximately)
2
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25°C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak forward surge current, 8.3 ms single half sine-wave
superimposed on rated load
Maximum instantaneous forward voltage (Note 1)
I
F
= 5 A
T
J
=25°C
Maximum reverse current @ rated V
R
Typical thermal resistance
Operating junction temperature range
Storage temperature range
Note 1: Pulse test with PW=300μs, 1% duty cycle
T
J
=100°C
T
J
=125°C
R
θJC
T
J
T
STG
- 55 to +125
- 55 to +150
I
R
15
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
0.55
0.5
10
SRS
1020
20
14
20
SRS
1030
30
21
30
SRS
1040
40
28
40
SRS
1050
50
35
50
10
120
0.70
0.90
0.1
-
5
2
- 55 to +150
°C/W
°C
°C
mA
1.00
SRS
1060
60
42
60
SRS
90
63
90
SRS
100
70
100
SRS
150
105
150
1090 10100 10150
UNIT
V
V
V
A
A
V
-
Document Number: DS_D1410045
Version: M15
SRS1020 - SRS10150
Taiwan Semiconductor
ORDERING INFORMATION
PART NO.
SRS10xx
(Note 1)
*: Optional available
PART NO.
SUFFIX
H
PACKING
CODE
RN
MN
PACKING CODE
SUFFIX
G
(*)
PACKAGE
PACKING
800 / 13" Paper reel
800 / 13" Plastic reel
D
2
PAK
Note 1: "xx" defines voltage from 20V (SRS1020) to 150V (SRS10150)
EXAMPLE
PREFERRED
PART NO.
SRS1060HRNG
PART NO.
SRS1060
PART NO.
SUFFIX
H
PACKING CODE
RN
PACKING CODE
SUFFIX
G
DESCRIPTION
AEC-Q101 qualified
Green compound
RATINGS AND CHARACTERISTICS CURVES
(T
A
=25°C unless otherwise noted)
FIG.1 FORWARD CURRENT DERATING CURVE
12
SRS1050-10150
AVERAGE FORWARD CURRENT (A)
10
8
6
4
2
0
50
60
70
80
90
100
110
120
130
140
150
LEAD TEMPERATURE (
°
C)
RESISTIVE OR
INDUCTIVELOAD
SRS1020-1040
FIG. 2 MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
PEAK FORWARD SURGE CURRENT (A)
300
250
200
150
100
50
0
1
10
100
NUMBER OF CYCLES AT 60 Hz
FIG. 3 TYPICAL FORWARD CHARACTERISTICS
100
INSTANTANEOUS REVERSE CURRENT (mA)
SRS1050-SRS1060
INSTANTANEOUS FORWARD CURRENT (A)
10
FIG. 4 TYPICAL REVERSE CHARACTERISTICS
SRS1020-1040
10
T
J
=100°C
1
1
SRS10150
0.1
T
J
=25°C
SRS1090-10100
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
1.1
1.2
1.3
1.4
FORWARD VOLTAGE (V)
0.01
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
Document Number: DS_D1410045
Version: M15
SRS1020 - SRS10150
Taiwan Semiconductor
FIG. 5 TYPICAL JUNCTION CAPACITANCE
TRANSIENT THERMAL IMPEDANCE (°C/W)
10000
f=1.0MHz
Vsig=50mVp-p
CAPACITANCE (pF)
FIG. 6 TYPICAL TRANSIENT THERMAL IMPEDANCE
100
10
1000
1
100
0.1
1
10
100
REVERSE VOLTAGE (V)
0.1
0.01
0.1
1
T-PULSE DURATION(s)
10
100
PACKAGE OUTLINE DIMENSIONS
TO-263AB (D
2
PAK)
DIM.
A
B
C
D
E
F
G
H
I
J
K
Unit (mm)
Min
-
14.60
2.41
0.68
2.29
4.44
1.14
1.14
8.25
0.36
2.03
Max
10.5
15.88
2.67
0.94
2.79
4.70
1.40
1.40
9.25
0.53
2.79
Unit (inch)
Min
-
0.575
0.095
0.027
0.090
0.175
0.045
0.045
0.325
0.014
0.080
Max
0.413
0.625
0.105
0.037
0.110
0.185
0.055
0.055
0.364
0.021
0.110
SUGGESTED PAD LAYOUT
Symbol
A
B
C
D
E
F
G
Unit (mm)
10.8
8.3
1.1
3.5
16.9
9.5
2.5
Unit (inch)
0.425
0.327
0.043
0.138
0.665
0.374
0.098
MARKING DIAGRAM
P/N
G
YWW
F
Document Number: DS_D1410045
= Specific Device Code
= Green Compound
= Date Code
= Factory Code
Version: M15
