Common Mode Inductors
Horizontal PCB
CEP4748
CEP4748 is a Common Mode Inductor for Switch Mode Power Supplies.
•
•
•
•
•
Inductance range:
0.33 to 82 mH.
Rated current range:
17.8 to 1.3 Amp.
Split bobbins for increased dielectric strength (4000 V RMS).
CSA
listed (LR 47366) and
U.L.
recognized (E100878).
Exceeds
VDE, BSI
and
IEC
regulatory requirements.
MECHANICAL
Dimensions, Inches
P/N
CEP4748
L
1.65
W
1.65
H
1.40
A
0.20
C
D
1.40 0.225
S
0.020 x 0.045
ELECTRICAL SPECIFICATION
Part No.
CEP4748 -
Ind.
(mH) Min.
DCR
Ohms Max.
Rated
Current Amp.
Part No.
CEP4748 -
Ind.
(mH) Min.
DCR
Ohms Max.
Rated
Current Amp.
* 01
* 02
* 03
* 04
* 05
* 06
* 07
* 08
* 09
* 10
* 11
* 12
* 13
* 14
* 15
CEP4748
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
0.008
0.009
0.009
0.013
0.015
0.020
0.022
0.024
0.035
0.038
0.053
0.058
0.064
0.069
0.075
17.8
17.0
16.3
14.0
13.1
11.3
10.7
10.2
8.2
8.2
6.9
6.5
6.3
5.8
5.8
* 16
* 17
* 18
* 19
* 20
* 21
* 22
* 23
* 24
* 25
* 26
* 27
* 28
* 29
* 30
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
0.103
0.115
0.159
0.173
0.191
0.270
0.295
0.412
0.458
0.631
0.684
0.753
1.11
1.14
1.59
4.9
4.7
4.2
3.8
3.6
3.0
2.9
2.5
2.3
2.0
1.9
1.8
1.5
1.5
1.3
An ISO 9001 Registered Company
229 Colonnade Road, Nepean, Ontario, Canada K2E 7K3
Tel: (613) 226-1626 Fax: (613) 226-7124 www.filtran.com
34-4
