Data Sheet
May 4, 2012
12V Mega TLynx
TM
: Non-Isolated DC-DC Power Modules:
6.0Vdc – 14Vdc input; 0.8 to 3.63Vdc Output; 30A Output Current
Features
•
Compliant to RoHS EU Directive 2002/95/EC (-Z
versions)
Compliant to ROHS EU Directive 2002/95/EC
with lead solder exemption (non-Z versions)
Compliant to IPC-9592 (September 2008),
Category 2, Class II
Delivers up to 30A of output current
High efficiency: 92.9% @ 3.3V full load
(V
IN
=12Vdc)
Input voltage range from 6 to 14Vdc
Output voltage programmable from 0.8 to
3.63Vdc
Small size and low profile:
33.0 mm x 13.46 mm x 10.00 mm
(1.30 in. x 0.53 in. x 0.39 in.)
RoHS Compliant
Applications
Distributed power architectures
Intermediate bus voltage applications
Telecommunications equipment
Servers and storage applications
Networking equipment
Vin+
VIN
VOUT
SENSE
RTUNE
Vout+
Monotonic start-up
Startup into pre-biased output
Output voltage sequencing (EZ-SEQUENCE
Remote On/Off
Remote Sense
Over current and Over temperature protection
Option- Parallel operation with active current
sharing
Wide operating temperature range (-40°C to
85°C)
UL*
60950 Recognized,
CSA
†
C22.2 No.
‡
60950-00 Certified, and
VDE
0805 (EN60950-1
rd
3 edition) Licensed
ISO** 9001 and ISO 14001 certified
manufacturing facilities
TM
)
MODULE
Cin
CTUNE
Co
ON/OFF
GND
TRIM
RTrim
Description
The 12V Mega TLynx power modules are non-isolated dc-dc converters that can deliver up to 30A of output
current. These modules operate over a wide range of input voltage (V
IN
= 6Vdc-14Vdc) and provide a precisely
regulated output voltage from 0.8Vdc to 3.63Vdc, programmable via an external resistor. Features include remote
On/Off, adjustable output voltage, over current and over temperature protection, output voltage sequencing and
paralleling with active current sharing (-P versions). A new feature, the Tunable Loop
TM
, allows the user to optimize
the dynamic response of the converter to match the load with reduced amount of output capacitance leading to
savings on cost and PWB area
*
UL
is a registered trademark of Underwriters Laboratories, Inc.
†
‡
TM
CSA
is a registered trademark of Canadian Standards Association.
VDE
is a trademark of Verband Deutscher Elektrotechniker e.V.
** ISO is a registered trademark of the International Organization of Standards
Document No: DS09-003 ver. 1.13
PDF Name: APTS030A0X3_ds.pdf
Data Sheet
May 4, 2012
12V Mega TLynx
TM
: Non-Isolated DC-DC Power Modules:
6.0 – 14Vdc Input; 0.8Vdc to 3.63Vdc Output; 30A output current
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are
absolute stress ratings only, functional operation of the device is not implied at these or any other conditions in
excess of those given in the operations sections of the data sheet. Exposure to absolute maximum ratings for
extended periods can adversely affect the device reliability.
Parameter
Input Voltage
Continuous
Sequencing pin voltage
Operating Ambient Temperature
(see Thermal Considerations section)
Storage Temperature
All
T
stg
-55
125
°C
All
All
All
V
IN
Vs
EQ
T
A
-0.3
-0.3
-40
15
15
85
Vdc
Vdc
°C
Device
Symbol
Min
Max
Unit
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature
conditions.
Parameter
Operating Input Voltage
Maximum Input Current
(V
IN
= V
IN,min
, V
O
= V
O,set,
I
O
=I
O, max
)
Inrush Transient
Input No Load Current
(V
IN
= 12.0Vdc, I
O
= 0, module enabled)
Input Stand-by Current
(V
IN
= 12.0Vdc, module disabled)
Input Reflected Ripple Current, peak-to-
peak
(5Hz to 20MHz, 1μH source impedance;
V
IN
=6.0V to 14.0V, I
O
= I
Omax
; See Figure 1)
Input Ripple Rejection (120Hz)
All
All
100
50
mAp-p
dB
All
V
O,set
= 0.8 Vdc
V
O,set
= 3.3Vdc
All
I t
I
IN,No load
I
IN,No load
I
IN,stand-by
91
265
20
2
Device
All
All
Symbol
V
IN
I
IN,max
Min
6.0
Typ
12
Max
14
19
Unit
Vdc
Adc
2
1
A s
mA
mA
mA
LINEAGE
POWER
2
Data Sheet
May 4, 2012
12V Mega TLynx
TM
: Non-Isolated DC-DC Power Modules:
6.0 – 14Vdc Input; 0.8Vdc to 3.63Vdc Output; 30A output current
Electrical Specifications
(continued)
Parameter
Output Voltage Set-point
(V
IN
=V
IN,nom
, I
O
=I
O, nom
, T
ref
=25°C)
Output Voltage
(Over all operating input voltage, resistive load,
and temperature conditions until end of life)
Adjustment Range
Selected by an external resistor
Output Regulation
Line (V
IN
=V
IN, min
to V
IN, max
)
Load (I
O
=I
O, min
to I
O, max
)
Temperature (T
ref
=T
A, min
to T
A, max
)
Output Ripple and Noise on nominal output
(V
IN
=V
IN, nom
and I
O
=I
O, min
to I
O, max
C
OUT
= 0.1μF // 47
μF
ceramic capacitors)
Peak-to-Peak (5Hz to 20MHz bandwidth)
External Capacitance
ESR
≥
1 mΩ
With the Tunable Loop
ESR
≥
0.15 mΩ
ESR
≥
10 mΩ
Output Current
(V
IN
= 6 to 14Vdc)
Output Current Limit Inception (Hiccup Mode)
Output Short-Circuit Current
(V
O
≤250mV)
( Hiccup Mode )
Efficiency
V
IN
=12Vdc, T
A
=25°C
I
O
=I
O, max ,
V
O
= V
O,set
V
O,set
= 0.8dc
V
O,set
= 1.2Vdc
V
O,set
= 1.8Vdc
V
O,set
= 2.5Vdc
V
O,set
= 3.3Vdc
Switching Frequency, Fixed
All
η
η
η
η
η
f
sw
⎯
83.0
87.1
90.1
91.8
92.9
300
⎯
%
%
%
%
%
kHz
All
All
All
I
o
I
O, lim
I
O, s/c
⎯
0
140
3.5
⎯
30
Adc
% I
omax
Adc
TM
1
TM
Device
All
Symbol
V
O, set
Min
-1.5
Typ
⎯
Max
+1.5
Unit
% V
O, set
All
V
O, set
–3.0
⎯
+3.0
% V
O, set
All
0.8
⎯
⎯
⎯
⎯
⎯
0.5
3.63
Vdc
All
All
All
10
10
1
mV
mV
% V
O, set
All
⎯
50
mV
pk-pk
Without the Tunable Loop
All
C
O, max
C
O, max
C
O, max
0
⎯
⎯
⎯
200
μF
All
All
0
0
1000
10000
μF
μF
General Specifications
Parameter
Min
Typ
4,443,300
Max
Unit
Calculated MTBF (V
IN
=12V, V
O
=2.5Vdc, I
O
= 0.8I
O, max
,
T
A
=40°C, 200LFM) Per Telcordia Issue 2 Method 1 Case 3
Weight
⎯
Hours
⎯
g (oz.)
7.04 (0.248)
LINEAGE
POWER
3
Data Sheet
May 4, 2012
12V Mega TLynx
TM
: Non-Isolated DC-DC Power Modules:
6.0 – 14Vdc Input; 0.8Vdc to 3.63Vdc Output; 30A output current
Feature Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature
conditions. See Feature Descriptions for additional information.
Parameter
On/Off Signal Interface
(V
IN
=V
IN, min
to V
IN, max
; open collector or equivalent,
Signal referenced to GND)
Logic High (On/Off pin open – Module OFF)
Input High Current
Input High Voltage
Logic Low (Module ON)
Input Low Current
Input Low Voltage
Turn-On Delay and Rise Times
(V
IN
=V
IN, nom
, I
O
=I
O, max ,
V
O
to within ±1% of steady state)
Case 1: On/Off input is enabled and then
input power is applied (delay from instant at
which V
IN
= V
IN, min
until V
o
= 10% of V
o, set
)
Case 2: Input power is applied for at least one second and
then the On/Off input is enabled (delay from instant at which
Von/Off is enabled until V
o
= 10% of V
o, set
)
Output voltage Rise time (time for V
o
to rise from
10% of Vo, set to 90% of Vo, set)
Output voltage overshoot
I
O
= I
O, max
; V
IN, min
– V
IN, max
, T
A
= 25 C
Remote Sense Range
Over temperature Protection
(See Thermal Consideration section)
Sequencing Slew rate capability
(V
IN, min
to V
IN, max
; I
O, min
to I
O, max
V
SEQ
< V
o
)
Sequencing Delay time (Delay from V
IN, min
to application of voltage on SEQ pin)
Tracking Accuracy
Power-up (2V/ms)
Power-down (1V/ms)
(V
IN, min
to V
IN, max
; I
O, min
- I
O, max
V
SEQ
< V
o
)
Input Undervoltage Lockout
Turn-on Threshold
Turn-off Threshold
Forced Load Share Accuracy
Number of units in Parallel
All
All
-P
-P
⎯
5.5
5.0
10
5
Vdc
Vdc
% Io
All
All
Ts
EQ-delay
V
SEQ
–V
o
V
SEQ
–V
o
10
100
200
200
400
msec
mV
mV
All
dV
SEQ
/dt
—
2
V/msec
All
All
T
ref
⎯
⎯
⎯
125
0.5
⎯
V
°C
o
Device
Symbol
Min
Typ
Max
Unit
All
All
All
All
I
IH
V
IH
I
IL
V
IL
25
3.0
⎯
-0.3
⎯
⎯
⎯
⎯
200
V
IN, max
200
1.2
µA
V
µA
V
All
Tdelay
―
2.5
5
msec
All
Tdelay
―
2.5
5
msec
All
Trise
2
10
3.0
msec
% V
O, set
LINEAGE
POWER
4
Data Sheet
May 4, 2012
12V Mega TLynx
TM
: Non-Isolated DC-DC Power Modules:
6.0 – 14Vdc Input; 0.8Vdc to 3.63Vdc Output; 30A output current
Characteristic Curves
The following figures provide typical characteristics for the APTS030A0X3-SRPHZ at 0.8V out and 25
o
C.
95
35
30
1m/s
(200LFM)
OUTPUT CURRENT, Io (A)
90
EFFICIENCY,
η
(%)
25
20
15
10
5
0
35
45
55
65
O
85
NC
80
Vin=12V
Vin=6V
0.5m/s
(100LFM)
75
Vin=14V
70
0
5
10
15
20
25
30
75
85
OUTPUT CURRENT, I
O
(A)
AMBIENT TEMPERATURE, T
A
C
Figure 1. Converter Efficiency versus Output Current.
OUTPUT VOLTAGE
OUTPUT CURRENT,
Figure 4. Derating Output Current versus Ambient
Temperature and Airflow at 12V in.
V
O
(V) (200mV/div)
I
O
(A) (5Adiv)
OUTPUT VOLTAGE
V
O
(V) (20mV/div)
TIME, t (1μs/div)
TIME, t (20μs /div)
Figure 2. Typical output ripple and noise (V
IN
= 12V, I
o
=
30A, C
OUT
= 0.1μF // 47
μF
ceramic capacitors ).
ON/OFF VOLTAGE
V
ON/OFF
(V) (5V/div)
Figure 5. Transient Response to Dynamic Load
Change from 0% to 50% to 0% with V
IN
=12V.
INPUT VOLTAGE
OUTPUT VOLTAGE
V
IN
(V) (5V/div)
V
O
(V) (200mV/div)
OUTPUT VOLTAGE
V
O
(V) (200mV/div)
TIME, t (2ms/div)
TIME, t (2ms/div)
Figure 3. Typical Start-up Using On/Off Voltage (I
o
=
I
o,max
).
Figure 6. Typical Start-up Using Input Voltage (VIN =
14V, Io = Io,max).
LINEAGE
POWER
5
