2000205109 Overview

Power Conditioning Thyro-S 1S 500-130 H3

2000205109 Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	Advanced Energy
Product Category	Power Conditioning

Preview

Download Datasheet

View All

THYRO-S® THYRISTOR SWITCH

16 TO 280 A

The digital, communication-enabled Thyro-S® thyristor switch

provides a comprehensive set of

advanced functions to suit the exacting requirements of a wide variety of applications and process

technologies.

APPLICATIONS

›

Automotive

(e.g. paint drying equipment)

›

Chemical (pipe trace heaters, pre-heating

equipment)

›

Furnace construction (industrial, diffusion,

drying)

›

Glass processing (drying coatings)

›

Machine building (extruders,

plastic presses)

›

Packaging (shrink tunnels)

›

Printing machines (IR drying)

RELIABLE, FAST, ECONOMIC, AND

COMMUNICATION-ENABLED

The high-effiency, connection-ready Thyro-S® thyristor

switch delivers accurate, reliable, switch-free performance.

It can be connected to bus systems, used as a standalone

unit, or used in combination with all established two-point

process controllers, PLCs, or computer systems.

With simple mounting, minimal space requirements, quick

commissioning, and safe operation, Thyro-S thyristor

switches are easily integrated into a wide range of

applications.

KEY FEATURES

›

For ohmic or transformer loads

Current, voltage, or power switching

230, 400, or 500 V

16 to 280 A

Integrated semiconductor fuse

Secure isolation between control and power sections

Three-phase design by connecting two Thyro-S

units

›

DIN rail mounting for 16 A, 30 A, 45 A, 60 A

ADVANCED COMMUNICATION AND CONTROL

›

Standard system interfaces for connection to an

optional bus module:

EtherNet/IP®

CANopen®

DeviceNet™

Modbus RTU®

Modbus TCP®

PROFIBUS® DPV1

PROFINET®

›

LED status messages

›

1:1 operating mode, as well as 1:2, 1:3, 1:5 for

commissioning

›

24 V (> 3 V) or standard system interface logic

signal control

CERTIFICATION AND COMPLIANCE

›

UL 508A (100 kVA SCCR)

›

ISO 9001 quality standards

ADDITIONAL FEATURES FOR H RL1 MODEL

›

24 VAC/VDC external electronic power supply

›

Load monitoring

›

Alarm relay
