Solid State Relay
OCMOS FET
PS7342-1A,PS7342L-1A
DESCRIPTION
and MOS FETs on the output side.
The PS7342L-1A has a surface mount type lead.
They are suitable for analog signal control because of their low offset and high linearity.
FEATURES
• High isolation voltage (BV = 3 750 Vr.m.s.)
• 1 channel type (1 a output)
• Low LED Operating Current (I
F
= 2 mA)
• Designed for AC/DC switching line changer
• Small package (6-pin DIP)
• Low offset voltage
<R>
<R>
• Pb-Free product
• Safety standards
• Ordering number of taping product : PS7342L-1A-E3, E4: 1 000 pcs/reel
• UL approved: File No. E72422
• BSI approved: No. 8252/8253
• CSA approved: No. CA 101391
• SEMKO approved: No. 606398
• DEMKO approved: No. 309836
• NEMKO approved: No. P00100964
• FIMKO approved: No. FI 15188
• DIN EN60747-5-2 (VDE0884 Part2) approved (Option)
APPLICATIONS
• Exchange equipment
• FA/OA equipment
• Measurement equipment
DI
Document No. PN10309EJ02V0DS (2nd edition)
Date Published September 2006 NS CP(K)
SC
O
NT
The mark <R> shows major revised points.
IN
1996, 2006
The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.
UE
The PS7342-1A and PS7342L-1A are solid state relays containing GaAs LEDs on the light emitting side (input side)
D
6-PIN DIP, HIGH ISOLATION VOLTAGE
400 V BREAK DOWN VOLTAGE
NORMALLY OPEN TYPE
1-ch Optical Coupled MOS FET
−NEPOC
Series−
PS7342-1A,PS7342L-1A
<R>
ORDERING INFORMATION
Part Number
Order Number
Solder Plating
Specification
PS7342-1A
PS7342L-1A
PS7342L-1A-E3
PS7342L-1A-E4
PS7342-1A-A
PS7342L-1A-A
PS7342L-1A-E3-A
PS7342L-1A-E4-A
Embossed Tape 1 000 pcs/reel
Pb-Free
Magazine case 50 pcs
Packing Style
Safety Standard
Approval
Standard products
(UL, BSI, CSA, SEMKO,
DEMKO, NEMKO,
FIMKO approved)
Application Part
Number
*1
PS7342-1A
*1
For the application of the Safety Standard, following part number should be used.
DI
4
SC
Data Sheet PN10309EJ02V0DS
O
NT
IN
UE
D
PS7342-1A,PS7342L-1A
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C, unless otherwise specified)
Parameter
Diode
Forward Current (DC)
Reverse Voltage
Power Dissipation
Peak Forward Current
MOS FET
Break Down Voltage
Continuous
Load Current
*2
*1
Symbol
I
F
V
R
P
D
I
FP
V
L
Connection A
Connection B
Connection C
I
L
Ratings
50
5.0
50
1
400
200
250
400
Unit
mA
V
A
V
mA
Pulse Load Current
*3
I
LP
400
(AC/DC Connection)
Power Dissipation
Isolation Voltage
*4
P
D
BV
P
T
T
A
T
stg
560
3 750
610
Total Power Dissipation
Operating Ambient Temperature
Storage Temperature
*2
Conditions: I
F
≥
2 mA. The following types of load connections are available.
1
2
3
6
Connection A
NT
5
I
L
1
2
3
1
2
3
1
2
3
4
6
5
4
6
5
4
6
5
4
I
L
I
L
L
L
I
L
+ I
L
I
L
L
L
I
L
*1
PW = 100
µ
s, Duty Cycle = 1%
O
Connection B
DI
SC
*3
PW = 100 ms, 1 shot
Connection C
*4
AC voltage for 1 minute at T
A
= 25°C, RH = 60% between input and output
Pins 1-3 shorted together, 4-6 shorted together.
IN
−40
to +85
−40
to +125
UE
mA
mW
Vr.m.s.
mW
°C
°C
V
L
(AC/DC)
+
V
L
(DC)
–
–
+ V
L
(DC)
+
V
L
(DC)
–
D
5
mW
Data Sheet PN10309EJ02V0DS
