1623865-3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> 1623865-3

1623865-3: DescriptionRESISTOR, TRIMMER, CERMET, 15 TURN(S), 0.75W, 50ohm, ROHS COMPLIANT; CategoryPassive components The resistor; File Size100KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

1623865-3 Overview

RESISTOR, TRIMMER, CERMET, 15 TURN(S), 0.75W, 50ohm, ROHS COMPLIANT

1623865-3 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	,
Reach Compliance Code	unknow
ECCN code	EAR99
Actuator direction	HORIZONTAL
Actuator type	SCREW
Manufacturer's serial number	422
Installation features	THROUGH HOLE MOUNT
Number of terminals	3
number of turns	15
Package shape	RECTANGULAR PACKAGE
Rated power dissipation(P)	0.75 W
resistance	50 Ω
resistance law	LINEAR
Resistor type	TRIMMER
surface mount	NO
technology	CERMET
Terminal surface	NOT SPECIFIED
Terminal shape	WIRE
Tolerance	10%
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Resistors

Product Feature Selector

> Product Details

404806507003 Product Details

Live Product Chat

Variable Resistors

C onve rte d to EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

404806507003

(1623865-3)

T E I nternal N umber: 1 6 2 3 8 6 5 - 3

Product Highlights:

Variable Resistor

Resistor Type = Trimmer

Resistance Selection = <1K ?

Resistance = 50 ?

Power Rating = .75 W

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

Professional Trimmers - Type 433PW Series - Tyco Ele...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Variable Resistor

Resistor Type

= Trimmer

Resistance (?)

= 50

Element

= C ermet

Sealed

= Yes

Mount Angle

= Horizontal

Termination Type

= PC B Terminations

Electrical Characteristics:

Resistance Selection (?) = <1K

Power Rating (W)

= 0.75

Tolerance (%)

= 10

Termination Related Features:

Termination Post Orientation

= 12.7 x 2.5

Body Related Features:

Series

= 422

Package, C omponent Size

= 19

Configuration Related Features:

Sections

= Single

Adjustment Location

= Side

Adjustment Style

= Screwdriver Slot

Operating Function

= Multi Turn

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C

RoHS/ELV C ompliance History = C onverted to comply with RoHS

directive

Conditions for Usage:

Temperature C oefficient (ppm/?C )

= 250

Other:

Brand = C itec

Additional Information:

Product Line Information
