SAW Components
SAW IF filter
Satellite Radio
Series/type:
Ordering code:
Date:
Version:
X3403
B39800X3403H810
May 29, 2013
2.1
EPCOS AG 2015. Reproduction, publication and dissemination of this publication, enclosures hereto and the information
contained therein without EPCOS' prior express consent is prohibited.
EPCOS AG is a TDK Group Company.
SAW Components
SAW IF filter
Data Sheet
Application
s
s
s
s
s
s
X3403
72.54 and 80.46 MHz
IF filter for Sirius Digital Satellite Radio
Diplexing of TDM1 and TDM2 satellite signal
Single balanced input and two balanced outputs
Constant group delay
Usable bandwidths of 3.7 MHz in TDM1 and TDM2
Low voltage loss
Features
Package size 7 x 5 x 1.33 mm
3
Maximum package height 1.48 mm
Package code QCC12E
RoHS compliant
Approximate weight 0.24 g
Package for
Surface Mount Technology
(SMT)
s
Ni, gold-plated terminals
s
s
s
s
s
s
1,4
12
1,27 1,27
1
2
3
1,1 2,54
4
bottom view
11
10
9
8
7
0,8
1,33
6
5
side view
7,0
5,0
top view
Pin configuration
s
10,12
Input, balanced
s
6,8
Output TDM1, balanced
s
3,4
Output TDM2, balanced
s
2,9
To be grounded
s
1,5,7,11 Case–grounds
8
10
6
4
12
3
1,5,7,11
Please read
cautions and warnings and
important notes
at the end of this document.
2
May 29, 2013
SAW Components
SAW IF filter
Data Sheet
Characteristics of TDM1 channel
Operating temperature range:
Terminating source impedance:
Terminating load impedance:
T = –40 ˚C to +105 ˚C
Z
S
=
27
Ω
and matching network
Z
L
=
1 kΩ and matching network
min.
Nominal frequency
f
N
—
—
typ.
@ 25 ˚C
72.54
17.2
max.
—
20.0
X3403
72.54 and 80.46 MHz
MHz
dB
Minimum insertion attenuation
α
min
(including losses in the matching network)
Amplitude ripple (p-p)
∆α
f
N
±
1.85 MHz
Pass bandwidth
α
rel
≤
1.5 dB
α
rel
≤
3 dB
α
rel
≤
15 dB
α
rel
≤
30 dB
—
1.1
3.0
dB
B
1.5dB
B
3dB
B
15dB
B
30dB
—
—
—
—
4.4
4.6
5.7
6.3
—
—
6.1
7.0
MHz
MHz
MHz
MHz
Mean attenuation (relative to
α
min
)
α
rel
Upper sidelobe 86.47 ...
91.53 MHz
Relative attenuation (relative to
α
min
)
α
rel
Lower sidelobe 50.00 ...
65.00 MHz
65.00 ...
66.48 MHz
66.48 ...
68.08 MHz
Upper sidelobe 77.30 ...
81.00 MHz
81.00 ...
86.47 MHz
86.47 ...
91.53 MHz
91.53 ...
95.21 MHz
95.21 ... 100.00 MHz
Group delay ripple
(p–p)
∆τ
50.0
52.0
—
dB
30.0
30.0
28.0
30.0
37.0
48.0
48.0
48.0
35.0
35.0
33.0
35.0
41.0
52.0
52.0
54.0
—
—
—
—
—
—
—
—
dB
dB
dB
dB
dB
dB
dB
dB
f
N
±
1.85MHz
Temperature coefficient of frequency
TC
f
—
—
220
– 18
—
—
ns
ppm/K
Please read
cautions and warnings and
important notes
at the end of this document.
3
May 29, 2013
