57669-M001

Description
Fiber Optic Cable Assemblies ST2 to ST2, Single Mode, Duplex, 3 mm, 1 meter
CategoryWire/cable
File Size44KB,1 Pages
ManufacturerFCI / Amphenol
Download Datasheet Parametric Compare View All

57669-M001 Overview

Fiber Optic Cable Assemblies ST2 to ST2, Single Mode, Duplex, 3 mm, 1 meter

57669-M001 Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerFCI / Amphenol
Product CategoryFiber Optic Cable Assemblies
ModeSinglemode
Connector End AST-Style (2.5 mm Bayonet)
Connector End BST-Style (2.5 mm Bayonet)
Fiber Diameter8.3/900
Length1 m
Description/FunctionSinglemode, 3 mm diameter
FeaturesSingle Mode, diameter 3 mm
Mounting AngleStraight, Straight
Insertion Loss0.5 dB
Cable Diameter3 mm
PDM: Rev:A
STATUS:
Released
Printed: Apr 08, 2008
.

57669-M001 Related Products

57669-M001
Description Fiber Optic Cable Assemblies ST2 to ST2, Single Mode, Duplex, 3 mm, 1 meter
Product Attribute Attribute Value
Manufacturer FCI / Amphenol
Product Category Fiber Optic Cable Assemblies
Mode Singlemode
Connector End A ST-Style (2.5 mm Bayonet)
Connector End B ST-Style (2.5 mm Bayonet)
Fiber Diameter 8.3/900
Length 1 m
Description/Function Singlemode, 3 mm diameter
Features Single Mode, diameter 3 mm
Mounting Angle Straight, Straight
Insertion Loss 0.5 dB
Cable Diameter 3 mm
