M12-Round-Plug Connector, Single-Ended Cordsets,
According to IEC 61076-2-101
RKTS | RKWTH
4-, 5-, and 8-Poles (Shielded)
Actuator/sensor cordset, single-ended, M12,
4-, 5-, and 8-poles, female straight connector,
internal threads with threaded joint and molded
cable, shielding connecting to knurled nut.
RKTS
Actuator/sensor cordset, single-ended, M12,
4-, 5-, and 8-poles, female 90
°connector,
internal threads with threaded joint and molded
cable, shielding connecting to knurled nut.
RKWTH
Pin Assignments
M12 - Female
4 poles
1=
2=
3=
4=
brown
white
blue
black
5 poles
1=
2=
3=
4=
5=
brown
white
blue
black
grey
8 poles
1=
2=
3=
4=
5=
6=
7=
8=
white
brown
green
yellow
grey
pink
blue
red
108
Technical Support:
1-717-217-2289
www.lumberg-automationusa.com
Cordsets
Single-Ended
Be Certain with Belden
M12-Round-Plug Connector, Single-Ended Cordsets, According to IEC 61076-2-101
RKTS | RKWTH
Technical Data
Environmental
Degree of protection
Operating temperature range
Mechanical
Housing / Molded body
Insert
Contact
Coupling nut
Shield sleeve
O-ring
Electrical
Contact resistance
Nominal current at 40°C
Nominal voltage
Rated voltage
Test voltage
Insulation resistance
IP 67 / NEMA 6P
-25°C (-13°F) / +80°C (+176°F)
TPU
TPU
CuSn, pre-nickeled and
0.8 microns gold-plated
CuZn, nickel-plated
CuZn, nickel-plated
FKM
≤
5 mΩ
4A
4 poles 240 V
5 poles 60 V
8 poles 30 V
3–4 poles 250 V
5 poles 63 V
8 poles 36 V
3–4 poles 2.0 kV eff. / 60 s
5–8 poles 1.5 kV eff. / 60 s
> 10
9
Ω
Cable Specifications
Cable No. Outer Jacket
182
183
184
288
298
299
PVC,
shielded
PVC,
shielded
PVC,
shielded
Conductor Size
4
x 0.34 mm
2
5
x 0.34 mm
2
8
x 0.25 mm
2
Jacket Color
Orange
Orange
Orange
Black
Black
Black
OD
.217” (5.5 mm)
.236” (6.0 mm)
.260” (6.6 mm)
.217” (5.5 mm)
.236” (6.0 mm)
.260” (6.6 mm)
Cordsets
Single-Ended
PUR,
halogen-free,
4
x 0.34 mm
2
shielded
PUR,
halogen-free,
5
x 0.34 mm
2
shielded
PUR,
halogen-free,
8
x 0.25 mm
2
shielded
RKWTH (8-pole version)
Part Number
Female Straight
RKTS 4-182/...M
RKTS 4-288/...M
RKTS 5-183/...M
RKTS 5-298/...M
RKTS 8-184/...M
RKTS 8-299/...M
RKWTH 8-299/...M
RKWTH 5-298/...M
Female 90°
RKWTH 4-182/...M
RKWTH 4-288/...M
Pins
4
Outer Jacket
Standard Cable Lengths
Characteristics
PVC
PUR, halogen-free
2 M / 5 M / 10 M
2 M / 5 M / 10 M
2 M / 5 M / 10 M
2 M / 5 M / 10 M
2 M / 5 M / 10 M
2 M / 5 M / 10 M
5
PVC
PUR, halogen-free
8
PVC
PUR, halogen-free
www.lumberg-automationusa.com
Technical Support:
1-717-217-2289
109
