LT6411IUD#TR

Description
High Speed Operational Amplifiers LT6411 - 650MHz Differential ADC Driver/Dual Selectable Gain Amplifier
CategoryAnalog mixed-signal IC    Amplifier circuit
File Size341KB,16 Pages
ManufacturerADI
Websitehttps://www.analog.com
Download Datasheet Parametric Compare View All

LT6411IUD#TR Overview

High Speed Operational Amplifiers LT6411 - 650MHz Differential ADC Driver/Dual Selectable Gain Amplifier

LT6411IUD#TR Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerADI
package instructionHVQCCN,
Reach Compliance Codenot_compliant
ECCN codeEAR99
Amplifier typeOPERATIONAL AMPLIFIER
Maximum input offset voltage20000 µV
JESD-30 codeS-PQCC-N16
JESD-609 codee0
length3 mm
Humidity sensitivity level1
Negative supply voltage upper limit-6.3 V
Nominal Negative Supply Voltage (Vsup)-5 V
Number of functions2
Number of terminals16
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
encapsulated codeHVQCCN
Package shapeSQUARE
Package formCHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)235
Certification statusNot Qualified
Maximum seat height0.8 mm
Nominal slew rate3300 V/us
Supply voltage upper limit6.3 V
Nominal supply voltage (Vsup)5 V
surface mountYES
technologyBIPOLAR
Temperature levelINDUSTRIAL
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formNO LEAD
Terminal pitch0.5 mm
Terminal locationQUAD
Maximum time at peak reflow temperature20
width3 mm
FEATURES
LT6411
650MHz Differential ADC
Driver/Dual Selectable
Gain Amplifier
DESCRIPTION
The LT
®
6411 is a dual amplifier with individually selectable
gains of +1, +2 and –1. The amplifiers have excellent dis-
tortion performance for driving ADCs as well as excellent
bandwidth and slew rate for video, data transmission and
other high speed applications. Single-ended to differential
conversion with a system gain of 2 is particularly straight-
forward by configuring one amplifier with a gain of +1
and the other amplifier with a gain of –1. The LT6411 can
be used on split supplies as large as ±6V and on a single
supply as low as 4.5V.
Each amplifier draws only 8mA of quiescent current when
enabled. When disabled, the output pins become high
impedance and each amplifier draws less than 350µA.
The LT6411 is manufactured on Linear Technology’s
proprietary, low voltage, complimentary, bipolar process
and is available in the ultra-compact, 3mm
×
3mm, 16pin
QFN package.
, LT, LTC and LTM are registered trademarks of Linear Technology Corporation.
All other trademarks are the property of their respective owners.
650MHz –3dB Small-Signal Bandwidth
600MHz –3dB Large-Signal Bandwidth
High Slew Rate: 3300V/µs
Easily Configured for Single-Ended to Differential
Conversion
200MHz ±0.1dB Bandwidth
User Selectable Gain of +1, +2 and –1
No External Resistors Required
46.5dBm Equivalent OIP3 at 30MHz When Driving an
ADC
IM3 with 2V
P-P
Composite, Differential Output:
–87dBc at 30MHz, –83dBc at 70MHz
–77dB SFDR at 30MHz, 2V
P-P
Differential Output
6ns 0.1% Settling Time for 2V Step
Low Supply Current: 8mA per Ampifier
Differential Gain of 0.02%, Differential Phase of 0.01°
50dB Channel Separation at 100MHz
Wide Supply Range: ±2.25V (4.5V) to ±6.3V (12.6V)
3mm
×
3mm 16-Pin QFN Package
APPLICATIONS
Differential ADC Driver
Single-Ended to Differential Conversion
Differential Video Line Driver
TYPICAL APPLICATION
Differential ADC Driver
5V
V
CC
LT6411
30MHz 2-Tone 32768 Point FFT, LT6411
Driving an LTC
®
2249 14-Bit ADC
0
–10
–20
–30
–40
–50
–60
–70
–80
–90
–100
–110
–120
–130
–140
0
32768 POINT FFT
TONE 1 AT 29.5MHz, –7dBFS
TONE 2 AT 30.5MHz, –7dBFS
IM3 = –87dBc
1.9V
DC
370Ω
30MHz
INPUT
1.9V
DC
370Ω
+
370Ω
370Ω
24Ω
A
IN–
LTC2249
14-BIT ADC
80Msps
A
IN+
6411 TA01a
+
DGND
EN
V
EE
24Ω
AMPLITUDE (dBFS)
5
10
15 20 25 30
FREQUENCY (MHz)
35
40
6411 TA01b
6411f
1
