C1206C240GHGAC Overview

CERAMIC CHIP / HIGH VOLTAGE

Preview

Download Datasheet

View All

CERAMIC CHIP / HIGH VOLTAGE

KEMET's High Voltage Surface Mount Capacitors are designed to withstand high voltage applications. They

offer high capacitance with low leakage current and low ESR at high frequency. The capacitors have pure tin

(Sn) plated external electrodes for good solderability. X7R dielectrics are not designed for AC line filtering

applications. An insulating coating may be required to prevent surface arcing. These components are RoHS

compliant.

APPLICATIONS

Applications

• Switch Mode Power Supply

• Input Filter

• Resonators

• Tank Circuit

• Snubber Circuit

• Output Filter

• High Voltage Coupling

• High Voltage DC Blocking

• Lighting Ballast

• Voltage Multiplier Circuits

• Coupling Capacitor/CUK

MARKETS

Markets

• Power Supply

• High Voltage Power Supply

• DC-DC Converter

• LCD Fluorescent Backlight Ballast

• HID Lighting

• Telecommunications Equipment

• Industrial Equipment/Control

• Medical Equipment/Control

• Computer (LAN/WAN Interface)

• Analog and Digital Modems

• Automotive

OUTLINE DRAWING

Outline Drawing

ELECTRODES

TIN PLATE

NICKEL PLATE

TABLE 1 - DIMENSIONS - MILLIMETERS (in.)

Metric

Code

2012

3216

3225

4520

4532

4564

5650

5664

EIA Size

Code

0805

1206

1210

1808

1812

1825

2220

2225

L - Length

2.0 (0.079)

± 0.2 (0.008)

3.2 (0.126)

± 0.2 (0.008)

3.2 (0.126)

± 0.2 (0.008)

4.5 (0.177)

± 0.3 (0.012)

4.5 (0.177)

± 0.3 (0.012)

4.5 (0.177)

± 0.3 (0.012)

5.6 (0.224)

± 0.4 (0.016)

5.6 (0.224)

± 0.4 (0.016)

W - Width

1.2 (0.049)

± 0.2 (0.008)

1.6 (0.063)

± 0.2 (0.008)

2.5 (0.098)

± 0.2 (0.008)

2.0 (0.079

± 0.2 (0.008)

3.2 (0.126)

± 0.3 (0.012)

6.4 (0.250)

± 0.4 (0.016)

5.0 (0.197)

± 0.4 (0.016)

6.4 (0.250)

± 0.4 (0.016)

B - Bandwidth

0.5 (0.02

±0.25 (0.010)

0.5 (0.02)

± 0.25 (0.010)

0.5 (0.02)

± 0.25 (0.010)

0.6 (0.024)

± 0.35 (0.014)

0.6 (0.024)

± 0.35 (0.014)

0.6 (0.024)

± 0.35 (0.014)

0.6 (0.024)

± 0.35 (0.014)

0.6 (0.024)

± 0.35 (0.014)

Band

Separation

0.75 (0.030)

N/A

Ceramic Surface Mount

CONDUCTIVE

METALLIZATION
