Note: Inclusive of initial frequency accuracy, operating temperature range, supply variation, load variation, 3 times solder reflow, shock, vibration and 1 year aging at 25°C. We do not
recommend hand soldering the devices
JUNE 20, 2017
3
IDT XO LVDS CRYSTAL OSCILLATOR
XLL DATASHEET
DC Characteristics
(V
DD
= 2.5V
±5%, T
A
= - 20°C to +70°C; -40° to +85°C)
Parameter
Power Supply Current
Differential Output Voltage
Output Offset Voltage
Enable/Disable Input HIGH Voltage
(Output enabled)*
Enable/Disable Input LOW Voltage
(Output disabled)
Symbol
I
DD
V
OD
V
OS
V
IH
V
IL
Condition
Common Frequencies
Standard LVDS load
Standard LVDS load
Min
26
Typ
0.4
1.25
Max
65
Units
mA
V
V
V
70%V
DD
30%V
DD
V
* A pullup resistor from pin 6 (VDD) to pin 1 (E/D) enables output when pin 1 is left open.
Note: Inclusive of initial frequency accuracy, operating temperature range, supply variation, load variation, 3 times solder reflow, shock, vibration and 1 year aging at 25°C. We do not
recommend hand soldering the devices
IDT XO LVDS CRYSTAL OSCILLATOR
4
JUNE 20, 2017
XLL DATASHEET
Output Waveform
Output Levels/Rise Time/Fall Time Measurements
T
R
OUTPUT 2
T
F
20% to 80% V
PP
50% V
PP
V
OS
V
OD
OUTPUT 1
Oscillator Symmetry
Ideally, Symmetry should be 50/50 for ½ period –Other expressions are 45/55 or 55/45
