7-1437567-2

Description
PUSHBUTTON SWITCH
CategoryMechanical and electronic products    switch
File Size130KB，2 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric Compare View All

7-1437567-2 Online Shopping

Suppliers Part Number Price MOQ In stock
7-1437567-2 - - View Buy Now

7-1437567-2 Overview

PUSHBUTTON SWITCH

7-1437567-2 Parametric

Parameter NameAttribute value
Brand NameAlcoswitch
Is it Rohs certified?incompatible
Reach Compliance Codeunknow
ECCN codeEAR99
body width13 mm
body height10 mm
Body length or diameter13 mm
Contact (AC) maximum rated R load3A@115VAC
Maximum contact current (AC)3 A
Maximum contact current (DC)3 A
Contact (DC) maximum rated R load3A@28VDC
Maximum contact voltage (AC)115 V
Maximum contact voltage (DC)28 V
Electrical life50000 Cycle(s)
JESD-609 codee4
Manufacturer's serial number1437567
Installation featuresPANEL MOUNT-THREADED
Maximum operating force6.86 N
Maximum operating temperature70 °C
Minimum operating temperature-15 °C
sealEPOXY TERMINAL SEALED
surface mountNO
Switch actionMOMENTARY
switch functionDPDT
Switch typePUSHBUTTON SWITCH
Terminal surfaceSilver (Ag)
Termination typeSOLDER
Base Number Matches1

Preview

Download Datasheet
This browser does not have Java enabled.
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
Have a Question?
Chat with a Product
Information Specialist
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Switches & Knobs > Product Feature Selector > Product Details
MPS203R Product Details
Pushbutton Switches
Not EU RoHS or ELV Compliant
 (
Find RoHS Compliant Alternates
)
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
Product Highlights:
Switch
Not Tactile
Double Pole ­ Double Throw Configuration (Pole­Throw)
Contact Rating = 3A
Operating Function = Momentary
MPS203R
(7­1437567­2)
TE Internal Number: 7­1437567­2
View all Features
 Superseded
Contact Product Information Center
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Switch
Mount Angle = Vertical
Actuator Style = Cap ­ Order Separately
Electrical Characteristics:
Contact Rating = 3A
Termination Features:
Termination Type = Wire Lugs
Dimensions:
Actuator Length (mm [in]) = 8.00 [0.315]
Bushing Diameter = 1/4­40
Spacer Height (mm [in]) = 1.01 [0.040]
Body Features:
Mount Style = Panel
Actuator Profile = Extended
Bushing Style = Threaded
Case Material = Epoxy Resin
Actuator Material = Nickel Plated Copper Alloy
Contact Features:
Contact Plating = Silver
Housing Features:
Process Sealed = No
Low Profile = No
Configuration Features:
Tactile = No
Configuration (Pole­Throw) = Double Pole ­ Double Throw
Operating Function = Momentary
Ganged = No
ESD Grounding Terminal = Without
Number of Actuators = Single
Illuminated = No
Dust Proof = No
Support Bracket = Without
Snap Action = With
Industry Standards:
RoHS/ELV Compliance = Not ELV/RoHS compliant
Lead Free Solder Processes = Wave solder capable to 240°C
Conditions for Usage:
Temperature Rating = Standard
Operation/Application:
Actuator Force (g [oz]) = 400.00 – 700.00 [14.000 – 25.000]
Packaging Features:
Packaging Method = Loose Piece
Other:
Series = MPS
Brand = Alcoswitch
Comment = Order cap model C22 or C23.
Corporate Information
About TE
Investors
News Room
Supplier Portal
Careers
Terms & Conditions
Privacy Policy
AODA Accessibility Policy
AODA Multi­Year Accessibility
Plan
Quick Links
Distributor Inventory
Product Cross Reference
Documents & Drawings
Product Compliance Support Center
Site Map
Customer Support
Email or Chat With Us
Find a Phone Number
Knowledge Base
Manage Your Account
Keep Me Informed


7-1437567-2 Related Products

7-1437567-2 MPS203R
Description PUSHBUTTON SWITCH PUSHBUTTON SWITCH, DPDT, MOMENTARY, 3A, ROHS COMPLIANT
Brand Name Alcoswitch Alcoswitch
Is it Rohs certified? incompatible conform to
Reach Compliance Code unknow compliant
ECCN code EAR99 EAR99
Maximum contact current (AC) 3 A 3 A
Maximum contact current (DC) 3 A 3 A
Switch action MOMENTARY MOMENTARY
switch function DPDT DPDT
Switch type PUSHBUTTON SWITCH PUSHBUTTON SWITCH
