89009-116LF: DescriptionHigh Speed / Modular Connectors 5R SIGNAL HDR WIDE STRT PRSS FIT 240P; CategoryThe connector; File Size3MB，25 Pages; ManufacturerFCI / Amphenol; Environmental Compliance

Download Datasheet Parametric Compare View All

89009-116LF Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	89009-116LF	-	-	View	Buy Now

89009-116LF Overview

High Speed / Modular Connectors 5R SIGNAL HDR WIDE STRT PRSS FIT 240P

89009-116LF Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	FCI / Amphenol
Product Category	High Speed / Modular Connectors
RoHS	Details
Product	Headers
Number of Positions	240 Position
Number of Rows	5 Row
Pitch	2 mm
Termination Style	Through Hole
Packaging	Tube
Current Rating	1 A
Housing Material	Liquid Crystal Polymer (LCP)
Mounting Angle	Straight
Contact Material	Phosphor Bronze
Insulation Resistance	5 GOhms
Maximum Operating Temperature	+ 125 C
Minimum Operating Temperature	- 55 C
Factory Pack Quantity	6

Preview

Download Datasheet

View All

Terran Huang

Julia Wang

-

Pei-Ming Zheng

2010/07/08

2012/08/29

-

2012/08/30

ELX-DG-012703-1

Released

U

PDS: Rev :U

STATUS:Released

Printed: Aug 30, 2012
