SOM-5992
NEW
Intel Xeon Processor D-1500
COM Express R3.0 Type 7 Module
Features
Intel
®
Xeon
®
Processor D-1500 Product Family
COM Express R3.0 Basic Module Type 7 pin out
2~16 core processor, with max. TDP 45W
Dual-CH DDR4 2400 w/ECC, max. 64GB
High speed Ethernet (dual 10GBASE-KR interfaces, one GbE)
Abundant expansion. (PCIe x16, PCIe x8, 8 PCIe x1)
Supports iManager, Embedded Software APIs and Wise-PaaS/RMM
Software APIs:
Watchdog
I
2
C
SMBus
H/W Monitor
GPIO
Brightness
Control
Utilities:
BIOS flash
Monitoring Embedded
Security ID
Specifications
Form Factor
Form Factor
Pin-out Type
CPU
Base Frequency
Max Single Core Turbo
Frequency
Cores
LLC
CPU TDP
BIOS
Technology
ECC Support
Max. Capacity
Socket
PCI Express x16
PCI Express x8
PCI Express x1
LPC
SMBus
I
2
C Bus
10GB Ethernet
Gigabit
SATA
USB3.0
USB2.0
SPI Bus
GPIO
Watchdog
COM Port
TPM
Smart Fan
Type
Supply Voltage
Power Consumption (Max.)
Power Consumption (Idle)
Temperature
Environment
Humidity
Vibration Resistance
Dimensions
COM Express Basic Module
COM Express R3.0 Type 7 compatible
Xeon
Xeon
Xeon
Xeon
D-1577
D-1548
D-1537
D-1527
1.3 GHz
2.0 GHz
1.7 GHz
2.2 GHz
2.1 GHz
2.6 GHz
2.3 GHz
2.7 GHz
Pentium
D1517
1.6 GHz
2.2 GHz
Pentium
D1508
2.2 GHz
2.6 GHz
Xeon
D-1559
1.5 GHz
2.1 GHz
Xeon
D-1539
1.6 GHz
2.2 GHz
8
12MB
35W
Pentium
D1519
1.5 GHz
2.1 GHz
4
6MB
25W
Processor System
Memory
Expansion
Serial Bus
Ethernet
I/O
Power
Mechanical
16
8
8
4
4
2
12
24MB
12MB
12MB
6MB
6MB
3MB
18MB
45W
45W
35W
35W
25W
25W
45W
AMI UEFI 128Mbit
DDR4 1866/2133/2400MHz
ECC and non-ECC
up to 64GB
Dual Channel, 4x 260P SODIMM
1 PCIe x16 Gen.3, and bifurcatable to 2 x8, 1 x8 & 2 x4, or 4 x4
1 PCIe x8 Gen.3, and bifurcatable to 2 x4
7 Ports, PCIe x1 Gen.2, and bifurcatable to x2 or x4 (max. 8 Ports if remove GbE LAN)
Yes. 33MHz, support DMA read/write
Yes
Support 100Kb/s & 400Kb/s devices. Default master mode, optional slave mode
Intel integrated 2x 10G LAN contorller; Interface: 10GBase-KR
Intel I210AT/I210IT controller; Speed: 10/100/1000 Mbps
2 ports support SATA III 6.0Gb/s
4 Ports
4 Ports
Yes. for BIOS ROM
8-bit GPIO
65536 level, 0 ~ 65535 sec
2 Ports (2-Wire)
TPM2.0
2 Ports; 1 Port on COM Module. Support 12V Fan, 1 Port on Carrier Board
ATX: Vin, VSB, AT: Vin
Vin: 8.5 (9-5%) ~ 20V (19+5%), VSB: 5V±5%, RTC Battery: 2.0-3.3V
Burn-in: 50.26W ; Turbo on: 55.53W
12.34W
Operating Standard: 0 ~ 60° C (32 ~ 140° F)
Extend Temp. : -40 ~ 85° C (-40 ~ 185° F) with 0.7m/s air flow
Storage: -40 ~ 85° C (-40 ~ 185° F)
Operating: 40° C @ 95% relative humidity, non-condensing
Storage: 60° C @ 95%relative humidity, non-condensing
3.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
125 x 95 mm (4.92" x 3.74")
Computer On Modules
All product specifications are subject to change without notice.
Last updated: 3-Nov-2017
SOM-5992
Block Diagram
DDR4 SO-DIMM0
Up to 16GB (A0*)
DDR4 SO-DIMM1
Up to 16GB (A1)
DDR4 SO-DIMM1
Up to 16GB (B1)
DDR4 SO-DIMM0
Up to 16GB (B0)
Channel A
Channel B
PCIe x1
[#7]
1 PCIe x1 [#6]
(Port 7 Opt. w/o GbE)
GbE LAN
6 PCIe x1
[#0-5]
4 USB 2.0
Ethernet
2 10GBase-KR
[#0-1]
[#0-3]
2 SATA III
Connector Row C,D
10GbE Side-Band (MDIO/I
2
C/SDP)
Intel Xeon Processor
D-1500
1 PCIe x8
[#0-7]
LPC Bus
1 PCIe x16
[#0-15]
iManager
4 USB 3.0
[#0-3]
PECI
TPM2.0
WDT/GPIO/I
2
C
Serial Port/FAN
SMBus
EFI BIOS
*Note: A0 (the higher slot in front side) is the 1st priority for system boot up.
SPI Bus
Ordering Information
Part No.
SOM-5992D8-U0A1
CPU
Core
Freq.
CPU
TDP
LLC
DDR4
SODIMM
Giga
LAN
1
1
1
1
1
1
1
1
1
10GBase-KR
2
2
2
2
2
2
2
2
2
PEG
x16
1
1
1
1
1
1
1
1
1
PCIe
x8
1
1
1
1
1
1
1
1
1
PCIe
x1
7
8
8
7
8
7
7
7
7
USB USB
2.0 3.0
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
SATA
III
2
2
2
2
2
2
2
2
2
LPC
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Power
AT/ATX
AT/ATX
AT/ATX
AT/ATX
AT/ATX
AT/ATX
AT/ATX
AT/ATX
AT/ATX
Thermal
solution
Active
Active
Active
Active
Active
Active
Active
Active
Active
Operating
Temp.
0 ~ 60 °C
0 ~ 60 °C
0 ~ 60 °C
0 ~ 60 °C
0 ~ 60 °C
0 ~ 60 °C
0 ~ 60 °C
-40 ~ 85 °C
-40 ~ 85 °C
Xeon
8
2.0
45W
12MB ECC/non ECC
D-1548
Xeon
8
1.7
35W
12MB ECC/non ECC
SOM-5992D8-S7A1
D-1537
Xeon
6
1.9
35W
9MB ECC/non ECC
SOM-5992D6-S9A1
D-1528
Xeon
4
2.2
35W
6MB ECC/non ECC
SOM-5992D4-U2A1
D-1527
Pentium
4
1.6
25W
6MB ECC/non ECC
SOM-5992P4-S6A1
D1517
Pentium
2
2.2
25W
3MB ECC/non ECC
SOM-5992P2-U2A1
D1508
Xeon
16
1.3
45W
24MB ECC/non ECC
SOM-5992D16-S3A1
D-1577
Xeon
12
1.5
45W
18MB ECC/non ECC
SOM-5992D12X-S5A1
D-1559
Xeon
8
1.6
35W
12MB ECC/non ECC
SOM-5992D8X-S6A1
D-1539
Note: Any other sku or combination is project based support. Please contact sales for details.
Optional Accessories
Part No.
1960048820N001
1960075879N001
Description
Semi-Cooler 125 x 95 x 33.5 mm with 12V Fan
Cooler 66 x 60 x 23 mm with 12V Fan
Development Board
Part No.
SOM-DB5920-00A1
Description
COM-Express Development Board, Type 7 Pin-out
Packing List
Part No.
-
1960081925N001
Description
SOM-5992 COM module
Heatspreader
Quantity
1
1
Embedded OS
OS
Win10
Part No.
2070015250
Description
Img Win10 IoT Ent_LTSB 64 bit
Online Download
www.advantech.com/products
Connector Row A,B
