BZV55C Series
V
Z
:
2.4 to 75V
P
D
:
500mW
FEATURES :
• Silicon planar zener diodes
• For use as low voltage stabilizer or voltage reference.
• Standard Zener voltage tolerance is
±
5%
• Pb / RoHS Free
ZENER DIODES
MiniMELF (SOD-80C)
Cathode Mark
φ
0.063 (1.64)
0.055 (1.40)
0.019(0.48)
0.011(0.28)
0.142(3.6)
0.134(3.4)
Mounting Pad Layout
MECHANICAL DATA :
* Case : MiniMELF Glass Case (SOD-80C)
* Weight : 0.05 gram (approximately)
0.049 (1.25)Min.
0.098 (2.50)
Max.
0.079 (2.00)Min.
0.197 (5.00)
REF
Dimensions in inches and ( millimeters )
Maximum Ratings and Thermal Characteristics
Rating at 25
°
C ambient temperature unless otherwise specified.
Parameter
Zener Current see Table "Characteristics"
Maximum Forward Voltage at I
F
= 10 mA.
Power Dissipation at Tflange = 50°C
Power Dissipation at Ta = 50°C
Continuous Forward Current
Thermal Resistance Junction to Ambient Air
Thermal Resistance Junction to Lead
Peak reverse power dissipation (non-repetitive) tp = 100µs
Junction temperature
Storage temperature range
Notes: (1) Mounted on ceramic substrate 10mm x 10mm x 0.6mm
(2) Tj = 150
°
C
Symbol
V
F
P
D
P
D
I
F
R
θ
JA
R
θJL
P
ZSM
T
J
T
S
Value
0.9
500
400
1)
250
0.38
0.3
(1)
Unit
V
mW
mW
mA
°C/mW
°C/mW
W
°C
°C
30
-65 to + 200
-65 to + 200
(2)
Page 1 of 2
Rev. 02 : March 25, 2005
ELECTRICAL CHARACTERISTICS
(Ta = 25
°
C unless otherwise noted)
Type
Zener Voltage
V
Z
@ I
ZT
1)
I
ZT
Nom
(V)
(mA)
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
2
2
2
2
2
2
2
2
Maximum Zener
Impedance , f = 1kHz
Z
ZT
@ I
ZT
Z
Zk
@ I
ZK
I
ZK
(Ω)
(Ω)
(mA)
100
100
95
95
90
90
90
80
60
40
10
15
15
15
15
20
20
25
30
30
40
45
55
55
70
80
80
80
90
130
150
170
180
200
215
240
255
600
600
600
600
600
600
600
500
480
400
150
80
80
80
100
150
150
150
170
200
200
225
225
250
250
300
300
325
350
350
375
375
400
425
450
475
500
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
Maximum Reverse
Leakage Current
I
R
at V
R
(µA)
(V)
50
20
10
5
5
3
3
3
2
1
3
2
1
0.7
0.5
0.2
0.1
0.1
0.1
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
0.05
1
1
1
1
1
1
1
2
2
2
4
4
5
5
6
7
8
8
8
10
11
13
14
15
17
19
21
23
25
27
30
33
36
39
43
48
53
Temp. coefficient
of Zener Voltage
α
vz
(% /
°C)
-0.08...-0.06
-0.08...-0.06
-0.08...-0.05
-0.08...-0.05
-0.08...-0.04
-0.07...-0.03
-0.04...-0.01
-0.03...+0.01
-0.02...+0.05
-0.01...+0.06
0.00...0.07
0.01...0.08
0.01...0.09
0.01...0.09
0.02...0.10
0.03...0.11
0.03...0.11
0.03...0.11
0.03...0.11
0.03...0.11
0.03...0.11
0.03...0.11
0.03...0.11
0.03...0.11
0.04...0.12
0.04...0.12
0.04...0.12
0.04...0.12
0.04...0.12
0.04...0.12
0.04...0.12
0.04...0.12
0.04...0.12
0.1 (typ.)
0.1 (typ.)
0.1 (typ.)
0.1 (typ.)
BZV55C2V4
BZV55C2V7
BZV55C3V0
BZV55C3V3
BZV55C3V6
BZV55C3V9
BZV55C4V3
BZV55C4V7
BZV55C5V1
BZV55C5V6
BZV55C6V2
BZV55C6V8
BZV55C7V5
BZV55C8V2
BZV55C9V1
BZV55C10
BZV55C11
BZV55C12
BZV55C13
BZV55C15
BZV55C16
BZV55C18
BZV55C20
BZV55C22
BZV55C24
BZV55C27
BZV55C30
BZV55C33
BZV55C36
BZV55C39
BZV55C43
BZV55C47
BZV55C51
BZV55C56
BZV55C62
BZV55C68
BZV55C75
Notes :
1) Tested with pulses tp = 5 ms
2) Valid Provided that leads are kept at ambient temperature.
3) The type number listed have a standard tolerance on the nominal zener voltage of
±
5.0%.
For
±
2% tolerance altered the sixth letter of type from "C" to be "B"
Page 2 of 2
Rev. 02 : March 25, 2005
