GS8182D09BGD-300I datasheet, PDF

Datasheet> All Categories > storage> storage> GS8182D09BGD-300I

GS8182D09BGD-300I: DescriptionSRAM 1.8 or 1.5V 2M x 9 18M; Categorystorage storage; File Size485KB，36 Pages; ManufacturerGSI Technology; Websitehttp://www.gsitechnology.com/; Environmental Compliance

Download Datasheet Parametric View All

GS8182D09BGD-300I Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	GS8182D09BGD-300I	-	-	View	Buy Now

GS8182D09BGD-300I Overview

SRAM 1.8 or 1.5V 2M x 9 18M

GS8182D09BGD-300I Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	GSI Technology
Parts packaging code	BGA
package instruction	LBGA,
Contacts	165
Reach Compliance Code	compliant
ECCN code	3A991.B.2.B
Factory Lead Time	8 weeks
Maximum access time	0.45 ns
Other features	PIPELINED ARCHITECTURE
JESD-30 code	R-PBGA-B165
JESD-609 code	e1
length	15 mm
memory density	18874368 bit
Memory IC Type	DDR SRAM
memory width	9
Humidity sensitivity level	3
Number of functions	1
Number of terminals	165
word count	2097152 words
character code	2000000
Operating mode	SYNCHRONOUS
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
organize	2MX9
Package body material	PLASTIC/EPOXY
encapsulated code	LBGA
Package shape	RECTANGULAR
Package form	GRID ARRAY, LOW PROFILE
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum seat height	1.4 mm
Maximum supply voltage (Vsup)	1.9 V
Minimum supply voltage (Vsup)	1.7 V
Nominal supply voltage (Vsup)	1.8 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Silver/Copper (Sn/Ag/Cu)
Terminal form	BALL
Terminal pitch	1 mm
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
width	13 mm

Preview

Download Datasheet

View All

GS8182D08/09/18/36BD-400/375/333/300/250/200/167

165-Bump BGA

Commercial Temp

Industrial Temp

Features

• Simultaneous Read and Write SigmaQuad™ Interface

• JEDEC-standard pinout and package

• Dual Double Data Rate interface

• Byte Write controls sampled at data-in time

• Burst of 4 Read and Write

• 1.8 V +100/–100 mV core power supply

• 1.5 V or 1.8 V HSTL Interface

• Pipelined read operation

• Fully coherent read and write pipelines

• ZQ pin for programmable output drive strength

• IEEE 1149.1 JTAG-compliant Boundary Scan

• Pin-compatible with present 9Mb and future 36Mb and

144Mb devices

• 165-bump, 13 mm x 15 mm, 1 mm bump pitch BGA package

• RoHS-compliant 165-bump BGA package available

18Mb SigmaQuad-II

Burst of 4 SRAM

Clocking and Addressing Schemes

400 MHz–167 MHz

1.8 V V

1.8 V and 1.5 V I/O

The GS8182D08/09/18/36BD SigmaQuad-II SRAMs are

synchronous devices. They employ two input register clock

inputs, K and K. K and K are independent single-ended clock

inputs, not differential inputs to a single differential clock input

buffer. The device also allows the user to manipulate the

output register clock inputs quasi independently with the C and

C clock inputs. C and C are also independent single-ended

clock inputs, not differential inputs. If the C clocks are tied

high, the K clocks are routed internally to fire the output

registers instead.

Each internal read and write operation in a SigmaQuad-II B4

RAM is four times wider than the device I/O bus. An input

data bus de-multiplexer is used to accumulate incoming data

before it is simultaneously written to the memory array. An

output data multiplexer is used to capture the data produced

from a single memory array read and then route it to the

appropriate output drivers as needed. Therefore the address

field of a SigmaQuad-II B4 RAM is always two address pins

less than the advertised index depth (e.g., the 2M x 8 has a

512K addressable index).

SigmaQuad™ Family Overview

The GS8182D08/09/18/36BD are built in compliance with

the SigmaQuad-II SRAM pinout standard for Separate I/O

synchronous SRAMs. They are 18,874,368-bit (18Mb)

SRAMs. The GS8182D08/09/18/36BD SigmaQuad SRAMs

are just one element in a family of low power, low voltage

HSTL I/O SRAMs designed to operate at the speeds needed to

implement economical high performance networking systems.

Parameter Synopsis

-400

tKHKH

tKHQV

2.5 ns

0.45 ns

-375

2.67 ns

0.45 ns

-333

3.0 ns

0.45 ns

-300

3.3 ns

0.45 ns

-250

4.0 ns

0.45 ns

-200

5.0 ns

0.45 ns

-167

6.0 ns

0.50 ns

Rev: 1.03d 11/2011

1/36

Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
