ZAMP002
800-2500MHz MMIC WIDEBAND AMPLIFIER
Medium Power, 22dB Gain, Wide Dynamic Range
DESCRIPTION
The ZAMP002 is an low current high performance RF
amplifier designed for L band and IF applications.
Although the ZAMP002 has been designed primarily
for DBS applications the ZAMP002 is capable of
extending to frequencies of 2.5GHz so it has a good fit
with various applications. An additional benefit of the
ZAMP002 is it’s rising gain characteristic, this has been
designed to counteract the gain losses found at the
higher frequencies. The ZAMP002 has been optimized
to an input impedance of 50ohms while the output
impedance has been designed for optimum match to
an impedance of 75ohms. Packaged in a small SC70-6
w i t h t he mi ni m um n um be r of e x t e rn a l b ia s
components required it is the ideal solution for space
and current limited applications.
SC70-6
FEATURES
•
L and IF frequency band
•
Low noise
•
Low current consumption 21mA typical
•
Gain 22dB typical
•
Rising gain across band
•
IP3 22dBm @ 1GHz
•
4.5 to 5.5V supply voltage
•
SC70-6 SMD package
CONNECTION DIAGRAM
Top View
GND 1
GND 2
INPUT 3
6 OUTPUT
5 GND
4 V
CC
APPLICATIONS
•
Satellite LNB receivers
•
RF buffers - tuners
•
SMR (Special Mobile Radio)
•
RLAN/WLAN
•
General purpose
ZAMP002H6TA
ZAMP002H6TC
ORDERING INFORMATION
DEVICE
REEL SIZE
(inches)
7”
13”
QUANTITY
PER REEL
3000 units
10000 units
DEVICE
MARKI
NG
ZB02
ZB02
ISSUE 2 - MARCH 2003
1
SEMICONDUCTORS
ZAMP002
ABSOLUTE MAXIMUM RATINGS
Supply Voltage
Supply Current
Operating Temperature
Storage Temperature
7V
30mA
-40 to 85°C
-50 to 125°C
ELECTRICAL CHARACTERISTICS
Test Conditions (unless otherwise stated): VCC = 5V, Tamb = 25°C, Zo = 50 .
SYMBOL
F
O
V
CC
I
CC
Gp
PARAMETER
Operating Frequency
Supply Voltage
Supply Current
Power Gain
F = 950 MHz
F = 1550 MHz
F = 2150 MHz
NF
Noise Figure
F = 950 MHz
F = 1550 MHz
F = 2150 MHz
IP3
3rd Order Intercept Point
F = 950 MHz
F = 2150 MHz
P1dB
RL
IN
RL
OUT
Risol
1dB Gain Compression
Input Return Loss
F = 950 to 2150 MHz
F = 950 MHz
F = 2150 MHz
Output Return Loss
F = 950 MHz
F = 2150 MHz
Reverse Isolation
F = 950 MHz
F = 2150 MHz
18
21
CONDITIONS
MIN
800
4.5
5
21
22
22
23
6
6.5
7
22
17
7
16
17
10
9
30
33
25
TYP.
MAX
2500
5.5
24
UNITS
MHz
V
mA
dB
dB
dB
dB
dB
dB
dBm
dBm
dBm
dB
dB
dB
dB
dB
dB
ISSUE 2 - MARCH 2003
SEMICONDUCTORS
2
TEST CIRCUIT
ZAMP002
Vcc
C4
100nF
X7R
C3
100pF
NPO
C5
100pF
NPO
L1
100nH
4
J1
C1
3
100pF
NPO
IC1
6
C2
100pF
NPO
J2
1
2
5
ZAMP002
CIRCUIT COMPONENTS LIST
Circuit Ref.
C1,C2,C3, C5
C4
L1
IC1
Description
Chip ceramic capacitor
Chip ceramic capacitor
Chip inductor
ZAMP002
Value
100 pF
100 nF
100 nH
Type
Murata GRH708 series, size 0805
X7R, size 0805
Murata LQW18ANR10G00D, size 0805
Wideband Amplifier, SC70-6
ISSUE 2 - MARCH 2003
5
SEMICONDUCTORS
