Technical specification:
Rated voltage:
IEC 61076-2-101
Current rating:
IEC 61076-2-101
Insulation resistance:
IEC 60512
Pollution degree:
IEC 60664-1
Degree of protection:
IEC 60529
4pos
250V
5pos
60V
Ø20
M12
7,5 A at 40°C, with 1,5mm²
>=100 M
3/2
IP 67, in mated
condition
-30° ... +85°C
C
>=50
max. AWG16 / max. 1,50 mm²
(incl. wire end ferrule)
Ö
Width across flats 18
~57
Temperature range:
IEC 60664-1
Mating cycles:
IEC 60512-9a
Width across flats 19
max. external cable
diameter see table
Ø20
Wire cross section:
Materials:
Contact:
Contact plating:
Contact carrier:
Cable seal:
CuZn
CUSnZn (white bronze)
PA6, UL 94 V-0
Elastomere
NBR
GD-Zn, Ni plated
GD-Zn, Ni plated
B-coding
4pos
2
1
2
5pos
1
5
O-Ring:
Coupling nut:
Housing:
Installation specification:
Recommended torque:
Conec
installation tooling:
0,6 Nm
Torque wrench:
36-000200
Insert across flats 18:
36-000240
0,3 Nm
3
4
3
4
Recommended torque,
screw termination
contact:
c
Part no:
43-00282
43-00283
DO NOT ALTER CAD DRAWING BY HAND
Description:
SAL - 12B - RSC4 - S / 150 / A5220
SAL - 12B - RSC5 - S / 150 / A5220
Pos:
4
5
Cable-
n
:
4 - 8 mm
4 - 8 mm
Directive 2002/95/EC RoHS compliant
Index: c / 30.05.16 KH Ä6152
Description expanded
date
drawn
dim. in mm
name
title:
tolerance of cable:
0
0,0
0,00
± 0,50mm
± 0,25mm
± 0,10mm
08.11.13
02.01.14
Strakerjahn
Kühle
R
Male connector M12x1,
field attachable, shielded, axial,
screw termination, Profibus DP
43K1A2246
appd.
dwg no:
general tolerance:
THIS DRAWING MAY NOT BE COPIED OR REPRODUCED IN ANY WAY, AND
MAY NOT BE PASSED ON TO A THIRD PARTY WITHOUT WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
part no:
see table
