Thru-Hole DIP Switches
SERIES 76 and 78
DPDT
FEATURES
• Raised and Recessed Rocker,
and Toggle Actuated Styles
• DPDT with Common Poles, or
DPDT with 4 Isolated Circuits
• Spring and Ball Contact
• Top Tape Seal Option for
Most Styles
DIP Switches
DIMENSIONS: Series 76
.380 ± .010
(9,65 ± 0,25)
C1
1
2
In inches (and millimeters)
Toggle-DIP
.447 ± .015
(11,35 ± 0,38)
TYP.
CIRCUITRY: Series 76
DPDT with Commons
True Form D Switching
C1
C1
Series 76 Raised Rocker, Double-DIP
.380 ± .010
(9,65 ± 0,25)
A = .247 ± .010
(6,27 ± 0,25)
.295 + .000 –.020
(7,49 –0,51)
1
C2
2
1
C2
2
C2
.020 + .005 –.000
(0,51 + 0,13)
A
Recessed Rocker
.050 ± .005
(1,27 ± 0,13)
.020
± .002
(0,51
± 0,05)
TYP.
.090 ± .005
(2,29 ± 0,13)
TYP.
.100 ± .005
(2,54 ± 0,13)
TYP.
1
C1
2
1
C1
2
.156 + .015 –.010
(3,96 + 0,38 –0,25)
.180 ± .010
(4,57 ± 0,25)
.247 ± .010
(6,27 ± 0,25)
C2
C2
C
L
C
L
.012 ± .001
(0,30 ± 0,03)
.300 + .030 –.000
(7,62 + 0,76)
DIMENSIONS: Series 78
In inches (and millimeters)
Series 78 Slide
.380 ± .005
(9,65 ± 0,25)
1
2
CIRCUITRY: Series 78
DPDT, 4 Circuits
(No Commons)
Dot on cover indicates active terminal when
slide is on that side of switch. Contact is made
with terminal on opposite side.
.070 (1,78) REF.
DIM. A
SEE CHART
.300 ± .002
(7,62 ± 0,05)
.020
± .002
(0,51
± 0,05)
.050 ± .005
(1,27 ± 0,13)
TYP.
A
.295 + .000 –.020
(7,49 –0,51)
1
1
.156 + .015 –.010
(3,96 + 0,38 –0,25) TYP.
A = .245 + .000 –.020
(6,22 + 0,51)
.180 ± .010 (4,57 ± 0,25)
.012 ± .001 (0,30 ± 0,03)
.300 + .030 –.000
(7,62 + 0,76)
.020 ± .002
(0,51 ± 0,05) TYP.
.090 ± .005 (2,29 ± 0,13) TYP.
.100 ± .005 (2,54 ± 0,13) TYP.
C C
L L
C
L
C
L
To create common poles, tie together 2
adjoining terminals on 1 (either) side of switch.
ORDERING INFORMATION
Circuitry
No./
Positions
1
2
1
2
Length
Inches
0.380"
0.780"
0.480"
0.880"
Length
Metric
9,7mm
19,8mm
12,2mm
22,4mm
No./
Tube
27
13
21
12
Raised
Type*
76SD01
76SD02
78K01
78K02
Recessed
Rockers*
76RSD01
76RSD02
—
—
Toggle-
DIP*
76STD01
76STD02
—
—
ADDITIONAL INFORMATION
For Specifications, see page B-14. For Options
and Accessories, see page B-20.
Available from your local Grayhill Distributor.
For prices and discounts, contact a local Sales
Office, an authorized local Distributor or Grayhill.
DPDT
Form D
DPDT
4 Circ.
A top tape seal is required for switches that are machine soldered or heavily cleaned after hand
soldering. To order top seal versions, add "S" to the Grayhill part number. Not available on Toggle-
DIP.
B-13
Grayhill, Inc. • 561 Hillgrove Avenue • LaGrange, Illinois 60525-5997 • USA • Phone: 708-354-1040 • Fax: 708-354-2820 • www.grayhill.com
