BA2902YF-CE2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> BA2902YF-CE2

BA2902YF-CE2: DescriptionOperational Amplifiers - Op Amps Grd Snse 4Ch SOP14 3-32V; CategoryAnalog mixed-signal IC Amplifier circuit; File Size775KB，34 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

BA2902YF-CE2 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BA2902YF-CE2	-	-	View	Buy Now

BA2902YF-CE2 Overview

Operational Amplifiers - Op Amps Grd Snse 4Ch SOP14 3-32V

BA2902YF-CE2 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Parts packaging code	SOIC
package instruction	ROHS COMPLIANT, SOP-14
Contacts	14
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	12 weeks
Amplifier type	OPERATIONAL AMPLIFIER
Architecture	VOLTAGE-FEEDBACK
Maximum average bias current (IIB)	0.1 µA
Maximum bias current (IIB) at 25C	0.06 µA
Nominal Common Mode Rejection Ratio	80 dB
frequency compensation	YES
Maximum input offset voltage	7000 µV
JESD-30 code	R-PDSO-G14
JESD-609 code	e3
length	8.7 mm
low-dissonance	NO
micropower	YES
Number of functions	1
Number of terminals	14
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP14,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
method of packing	TAPE AND REEL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	+-1.5/+-16/3/32 V
Certification status	Not Qualified
Maximum slew rate	3 mA
Supply voltage upper limit	36 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	BIPOLAR
Temperature level	AUTOMOTIVE
Terminal surface	TIN
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Minimum voltage gain	25000
width	4.4 mm
Base Number Matches	1

Preview

Download Datasheet

View All

Operational Amplifier Series

Automotive Ground Sense

Operational Amplifiers

BA2904Yxxx-C, BA2902Yxx-C

●General

Description

BA2904Yxxx-C,BA2902Yxx-C integrate two or four

independent Op-Amps and ground sense input

Amplifier on a single chip. These Op-Amps have some

features of high-gain, low power consumption, and can

operate from +3V to +36V (single power supply ).

BA2904Yxxx-C, BA2902Yxx-C are manufactured for

automotive requirements of engine control unit, electric

power steering, and so on.

●Features



AEC-Q100 Qualified



Single or dual power supply operation



Wide operating supply voltage



Standard Op-Amp Pin-assignments



Common-mode Input Voltage Range includes ground

level, allowing direct ground sensing



Low supply current



High open loop voltage gain



Internal ESD protection circuit



Wide temperature range

●Application



Engine Control Unit



Electric Power Steering (EPS)



Anti-Lock Braking System (ABS)



Automotive electronics

●Key

Specifications



Wide operating supply voltage

Single supply :

Dual supply :



Low supply current

BA2904Yxxx-C

BA2902Yxx-C



Input bias current :



Input offset current :



Operating temperature range :

●Packages

SOP8

SOP14

SSOP-B8

SSOP-B14

MSOP8

+3.0V to +36V

±1.5V to ±18V

0.5mA(Typ.)

0.7mA(Typ.)

20nA(Typ.)

2nA(Typ.)

-40℃ to +125℃

W(Typ.) x D(Typ.) x (Max.)

5.00mm x 6.20mm x 1.71mm

8.70mm x 6.20mm x 1.71mm

3.00mm x 6.40mm x 1.35mm

5.00mm x 6.40mm x 1.35mm

2.90mm x 4.00mm x 0.90mm

●Selection

Guide

Maximum operating temperature

Output current

Source/Sink

Automotive

Dual

30mA / 20mA

supply current

0.5mA

+125°C

BA2904YF-C

BA2904YFV-C

BA2904YFVM-C

BA2902YF-C

BA2902YFV-C

Quad

30mA / 20mA

0.7mA

○Product

structure：Silicon monolithic integrated circuit

TSZ22111½14½001

○This

product is not designed protection against radioactive rays.

1/30

TSZ02201-0RAR1G200110-1-2

8.MAY.2013 Rev.004

BA2902YF-CE2 Related Products

	BA2902YF-CE2	BA2904YF-CE2	BA2902YFV-CE2	BA2904YFVM-CTR
Description	Operational Amplifiers - Op Amps Grd Snse 4Ch SOP14 3-32V	Operational Amplifiers - Op Amps Grd Snse 2Ch SOP8 3-32V	Operational Amplifiers - Op Amps Grd Snse 4Ch SSOP-B14 3-32V	Operational Amplifiers - Op Amps Grd Snse 2Ch MSOP8 3-32V
Is it lead-free?	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to
Maker	ROHM Semiconductor	ROHM Semiconductor	ROHM Semiconductor	ROHM Semiconductor
Parts packaging code	SOIC	SOIC	SSOP	MSOP
package instruction	ROHS COMPLIANT, SOP-14	ROHS COMPLIANT, SOP-8	LSSOP, TSSOP14,.25	VSSOP, TSSOP8,.16
Contacts	14	8	14	8
Reach Compliance Code	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99
Factory Lead Time	12 weeks	16 weeks	12 weeks	16 weeks
Amplifier type	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER
Architecture	VOLTAGE-FEEDBACK	VOLTAGE-FEEDBACK	VOLTAGE-FEEDBACK	VOLTAGE-FEEDBACK
Maximum average bias current (IIB)	0.1 µA	0.1 µA	0.1 µA	0.1 µA
Maximum bias current (IIB) at 25C	0.06 µA	0.06 µA	0.06 µA	0.06 µA
Nominal Common Mode Rejection Ratio	80 dB	80 dB	80 dB	80 dB
frequency compensation	YES	YES	YES	YES
Maximum input offset voltage	7000 µV	7000 µV	7000 µV	4000 µV
JESD-30 code	R-PDSO-G14	R-PDSO-G8	R-PDSO-G14	R-PDSO-G8
JESD-609 code	e3	e2	e2	e2
length	8.7 mm	5 mm	5 mm	2.9 mm
low-dissonance	NO	NO	NO	NO
Number of functions	1	1	1	2
Number of terminals	14	8	14	8
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SOP	SOP	LSSOP	VSSOP
Encapsulate equivalent code	SOP14,.25	SOP8,.25	TSSOP14,.25	TSSOP8,.16
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH	SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH
method of packing	TAPE AND REEL	TAPE AND REEL	TAPE AND REEL	TAPE AND REEL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
power supply	+-1.5/+-16/3/32 V	+-1.5/+-16/3/32 V	+-1.5/+-16/3/32 V	+-1.5/+-16/3/32 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum slew rate	3 mA	1.2 mA	3 mA	1.2 mA
Supply voltage upper limit	36 V	36 V	36 V	36 V
Nominal supply voltage (Vsup)	5 V	5 V	5 V	5 V
surface mount	YES	YES	YES	YES
technology	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR
Temperature level	AUTOMOTIVE	AUTOMOTIVE	AUTOMOTIVE	AUTOMOTIVE
Terminal surface	TIN	TIN COPPER	TIN COPPER	Tin/Copper (Sn/Cu)
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING
Terminal pitch	1.27 mm	1.27 mm	0.65 mm	0.65 mm
Terminal location	DUAL	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Minimum voltage gain	25000	25000	25000	25000
width	4.4 mm	4.4 mm	4.4 mm	2.8 mm
Base Number Matches	1	1	-	1
