87898-0316 datasheet, PDF - EEWORLD Datasheet

Suppliers	Part Number	Price	MOQ	In stock
	87898-0316	-	-	View	Buy Now

9

8

7

6

5

B

4

3

2

1

2.54

±

0.05

TYP

NON-ACCUM

A

CKT 1

E

B

0.32

2.40

TYP

½

2.51

½

CKT 1

CKT 6

2.96

TYP

1.27

TYP

CKT 6

D

10

½

7.50

½

RECOMMENDED PCB LAYOUT: COMPONENT SIDE

½

4.50

½

0.64

±

0.05

SQ TYP

C

M

½

G

½

2.49

±

0.10

½

F

½

1.32 TYP

8

⌓

0.15

CKT 2-20

0.20

CKT 21-40

2.54

TYP

½

4.80

½

7

B

NOTES:

1. MATERIAL:

HSG: NYLON, GLASS-FILLED, UL94V-0, COLOR: BLACK

CAP: NYLON, GLASS-FILLED, UL94V-0, COLOR: BLACK

PIN: 0.64MM SQ, COPPER ALLOY

2. PLATING TYPE:

(1) GOLD FLASH OVER

1.25µm MIN. NICKEL OVERALL.

(2) GOLD FLASH ON CONTACT AND

2.50µm MIN. TIN ON SOLDERTAIL OVER

1.25µm MIN. NICKEL OVERALL.

(4) 0.38µm MIN. GOLD PLATE ON CONTACT AND

2.00µm MIN. TIN ON SOLDERTAIL OVER

1.25µm MIN. NICKEL OVERALL.

(5) 0.75µm MIN. GOLD PLATE ON CONTACT AND

2.00µm MIN. TIN ON SOLDERTAIL OVER

1.25µm MIN. NICKEL OVERALL.

(6) 2.50µm MIN. TIN OVERALL

1.25µm MIN. NICKEL OVERALL

3. PRODUCT SPECIFICATION: PS-87920-019

4. PACKAGING TYPE: SEE TABLE

5. PACKAGING SPEC:

TUBE WITH CAP VERSION: PK-89990-558

TUBE W/O CAP VERSION: PK-89990-545

TRAY W/O CAP: PK-89990-489

EMBOSS TAPE WITH CAP: PK-89990-486 AND PK-87898-400

6. WAFER TO BE FLAT WITHIN 0.003 mm/mm

7

BEND DEPRESSION IS ACCEPTED SO LONG AS IT DOES NOT

AFFECT THE OVERALL COPLANARITY OF TAIL

8

COPLANARITY IS TO BE MEASURED BY RESTING THE SOLDER

TAIL ON A FLAT SURFACE

9

IRREGULAR CIRCUIT CUTOFF WITHIN BREAKAWAY SECTION IS

PERMISSIBLE.CUTTING OR CHIPPING OF THE MAIN BODY IS

NOT ACCEPTABLE

10

CAP LOCATION IS CENTERED ALONG THE MATING ENDS AS

SHOWN. TOP SURFACE OF CAP TO BE FLAT FOR THE

PURPOSE OF PICK & PLACE BY VACUUM SUCTION NOZZLE

11. RECOMMENDED PCB THICKNESS IS 1.60mm

±

0.10

12. THE ABOVE CKT 6 IS FOR ILLUSTRATION PURPOSE ONLY

13. TUBE LENGTH AS PER STANDARD 560mm

E

D

C

B

THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION

2017/11/27

2017/12/12

DIMENSION UNITS

SCALE

GENERAL TOLERANCES

(UNLESS SPECIFIED)

MM

DRWN BY

DATE

NTS

MM

INCH

±

ADD -0318 & -0458

4 PLACES

3 PLACES

2 PLACES

±

0.2

±

YLQIAO

CHK'D BY

DATE

2005/03/14

2005/03/29

DATE

A

PTLIM

APPR BY

CUSTOM HEADER

2.54MM PITCH SINGLE ROW SINGLE WAFER SMT

HEADER

PRODUCT CUSTOMER DRAWING

A

168622

FCSOO

CGOH

KHLIM

1 PLACES

0 PLACES

MLONG

DRAWING SIZE

2010/10/04

THIRD ANGLE PROJECTION

SERIES

MATERIAL NUMBER

CUSTOMER

EC NO:

DRWN:

CHK'D:

APPR:

ANGULAR TOL

±

3.0

DRAFT WHERE APPLICABLE

MUST REMAIN

WITHIN DIMENSIONS

87898

DOCUMENT NUMBER

SEE TABLE

GENERAL MARKET

DOC TYPE DOC PART

SHEET NUMBER

RELEASE STATUS

FORMAT: Met-lega-master-tb-prod-A3

REVISION: C

DATE: 2016/02/04

RELEASE DATE

B19

8

7

6

5

REV

A3

3

SD-87898-001

PSD

000

1 OF 21

9

4

2

1

9

8

7

6

5

4

3

2

1

PACKAGING OPTION PART NO.

DIMENSION

CKT

VOID

PLATING

TRAY

TUBE

TAPE & REEL TAPE & REEL

SIZE POSITION

TYPE

A

B

F

M

G

WITHOUT CAP WITH CAP WITHOUT CAP WITH CAP WITHOUT CAP

WITH CAP

------

-----

87898-0301

3

1

7.62 5.08 10.81 9.65 5.84

------

-----

87898-0302

3

2

7.62 5.08 10.81 9.65 5.84

------

-----

4

87898-0304

87898-0314

3

7.62 5.08 10.81 9.65 5.84

E

87898-0305

------

-----

5

87898-0315

3

7.62 5.08 10.81 9.65 5.84

------

-----

87898-0306

87898-0316

3

6

7.62 5.08 10.81 9.65 5.84

------

-------

87898-0317

3

6

7.62 5.08 10.81 9.65 5.84

B18

------

-----

------

-----

5

87898-0318

3

7.62 5.08 10.81 9.65 5.84

E

REFER TO LAST SHEET FOR 2CKT SIZE
