• Special lead wire design to prevent open circuit failure
• Excellent terminal strength to mechanical stress
ELECTRICAL SPECIFICATIONS:
FEATURES:
MSL level: 1
ASPI-0403H
Pb
RoHS/RoHS II compliant
4.5 x 4.0 x 3.2mm
• OA equipments
• PC and notebook
• LCD TV set
• Power supply
APPLICATIONS:
Abracon P/N:
Operating Temperature:
Storage Temperature:
PART NUMBER
ASPI-0403H-1R0
ASPI-0403H-1R4
ASPI-0403H-1R8
ASPI-0403H-2R2
ASPI-0403H-2R7
ASPI-0403H-3R3
ASPI-0403H-3R9
ASPI-0403H-4R7
ASPI-0403H-5R6
ASPI-0403H-6R8
ASPI-0403H-8R2
ASPI-0403H-100
ASPI-0403H-120
ASPI-0403H-150
ASPI-0403H-180
ASPI-0403H-220
ASPI-0403H-270
ASPI-0403H-330
ASPI-0403H-390
ASPI-0403H-470
ASPI-0403H-560
ASPI-0403H-680
ASPI-0403H-820
ASPI-0403H Series
-40˚C to +125˚C
-10
˚C
to +40˚C
Tolerance
M
M
M
M
M
M
M
M
M
K
K
K
K
K
K
K
K
K
K
K
K
K
K
DCR(Ω) max
0.033
0.038
0.042
0.047
0.052
0.058
0.076
0.094
0.101
0.117
0.132
0.182
0.210
0.235
0.338
0.378
0.522
0.540
0.587
0.844
0.937
1.170
1.20
IDC (A) max
3.80
3.30
2.91
2.60
2.43
2.15
1.98
1.70
1.60
1.40
1.26
1.15
1.05
0.92
0.84
0.76
0.71
0.64
0.59
0.54
0.46
0.48
0.30
Inductance Code
1R0
1R4
1R8
2R2
2R7
3R3
3R9
4R7
5R6
6R8
8R2
100
120
150
180
220
270
330
390
470
560
680
820
INDUCTANCE (uH)
1.0
1.4
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
OPTIONS AND PART IDENTIFICATION
Test Conditions
Inductance:
Test Frequency: 100KHz / 1V
Isat:
∆L/L
(initial)
≥
-10% or
ΔT=40°C
(Ta=20°C), whichever is lower.
Test Equipment:
UC1068B
ASPI-0403H-
Inductance Code
Please refer to the table above
-
Tolerance %
K: ± 10%
M: ± 20%
Packaging
T: Tape and Reel (2Kpcs / reel)
ABRACON IS
ISO9001:2008
CE RTIFIED
LLC
2 Faraday, Suite# B
|
Irvine
|
CA 92618
Revised: 11.09.15
Ph. 949.546.8000
|
Fax. 949.546.8001
Visit
www.abracon.com
for Terms and Conditions of Sale
High Current Unshielded, SMD Power Inductors
ASPI-0403H
OUTLINE DRAWING:
Pb
RoHS/RoHS II compliant
4.5 x 4.0 x 3.2mm
Recommended Land Pattern
A
4.5±0.3
REFLOW PROFILE:
B
4.0±0.3
C
3.2±0.30
D
1.80
E
1.50
F
4.50
Dimension: mm
ABRACON IS
ISO9001:2008
CE RTIFIED
LLC
2 Faraday, Suite# B
|
Irvine
|
CA 92618
Revised: 11.09.15
Ph. 949.546.8000
|
Fax. 949.546.8001
Visit
www.abracon.com
for Terms and Conditions of Sale
High Current Unshielded, SMD Power Inductors
ASPI-0403H
TAPE & REEL:
Packing
Weight:
2,000pcs / tape & reel, 8,000pcs / 4 reels / box
0.26 grams / pcs
Pb
RoHS/RoHS II compliant
4.5 x 4.0 x 3.2mm
Outer carton (optional): 16,000pcs/2 boxes/carton
GW: 12.8kg/carton
CARRIER TAPE / SIZE (mm)
A0
4.25 ±
0.1
B0
4.8 ±
0.1
K0
3.6 ±
0.1
F
5.5 ±
0.1
E
1.75 ±
0.1
W
12 ±
0.3
P
8±
0.1
Po
4±
0.1
P2
2±
0.1
t
0.4±
0.05
A
12.4 ±
0.2
REEL 13"×24mm
B
100 ±
0.5
C
13.0 ±
0.2
D
330 ±
2.0
Dimension: mm
ATTENTION:
Abracon Corporation’s products are COTS – Commercial-Off-The-Shelf products; suitable for Commercial, Industrial and, where designated, Automo-
tive Applications. Abracon’s products are not specifically designed for Military, Aviation, Aerospace, Life-dependant Medical applications or any application requir-
ing high reliability where component failure could result in loss of life and/or property. For applications requiring high reliability and/or presenting an extreme
operating environment, written consent and authorization from Abracon Corporation is required. Please contact Abracon Corporation for more information.
