GENERAL TOLERANCE
DIM.RANGE 0.5 - 3 >3-6 >6-30 >30-120 >120-400
TOLERANCE
±0.1
±0.1
±0.2
±0.3
±0.5
DOCUMENT NO.
CUSTOMER DRAWING
REVISION
REV.
DESCRIPTION
DATE
2017-3-9
2017/4/5
PA1 NEW RELEASE
PA2 UPDATED DRAWING
C
P/N
10-101949-06
10-101949-08
10-101949-10
10-101949-12
10-101949-14
10-101949-16
10-101949-18
10-101949-20
10-101949-22
10-101949-24
R±0.3
11.91
15.08
18.26
20.65
23.01
24.61
27.00
29.36
31.75
34.93
S±0.3
17.48
20.62
23.82
26.19
28.58
30.96
33.32
36.53
39.70
42.88
F +0.5/-0
9.53
12.7
15.88
19.05
22.23
25.40
28.58
31.75
34.93
38.10
T±0.2
0.61
0.61
0.61
1.40
0.61
0.61
0.61
0.61
0.61
0.61
S
R
F
R
S
PA2
10-101949-( )
REV.
T
B
DOCUMENT NO.
1.
THE REFERENCED PRODUCT IS IN COMPLIANCE WITH THE MAXIMUM
CONCENTRAT VALUES (MCVS), AS SET BY RoHS 2.0 DIRECTIVE
2011/65/EU AND ANNEX I I AMENDMENT DIRECTIVE (EU)2015/863
UNLESS OTHERWISE SPECIFIED
LINEAR DIMENSIONS ARE IN:
MILLIMETERS
TOLERANCES:
ANGLES= ±2°
DEFAULT LINEAR TOLERANCES SEE TABLE
DIM. & TOL. PER ASME Y14.5M-1994;
DRM PER MIL-DTL-31000;
OTHER AMPHENOL STANDARDS: 9-3800
LEGENDS:
=FLAG NOTE CALL OUT
REFERENCE
APPROVALS
PREPARED BY:
ENGINEER IN CHANGE:
DESIGN MANAGER:
PRODUCT GROUP:
AIPG DIVISION:
MATERIAL SPEC
DATE
Peter.ling
Peter.ling
Ran.Xiao
C&3
PROCESS SPEC
Apr-05-17
AMPHENOL INDUSTRIAL OPERATIONS
Amphenol Technology(Zhuhai)Co.,Ltd
No.63, Xinghan Road, Sanzao Town, Jinwan, Zhuhai, PRC
A
NOTES:
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION AND
SUCH INFORMATION MAY NOT BE DISCLOSED TO OTHERS FOR
ANY PURPOSE OR USED FOR MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION FROM THE AMPHENOL CORP.
GASKET,FLAT
ELECTRICAL CONNECTOR
SIZE
CAGE CODE
DOCUMENT NUMBER
U
REV
THIRD ANGLE PROJECTION
C
SCALE:
77820
REF:
10-101949-( )
PA2
SHEET 1 OF 1
DOCUMENT NO.
10-101949-( )
SHEET 1 OF 1
REV
.
PA2
3
2
1
SHEET 1 OF 1
10-101949-( )
DOCUMENT NO.
SHEET 1 OF 1
PA2
REV.
4
10-101949-( )
3
2
D
SHEET 1 OF 1
PA2
REV.
C
A
