AVH316K datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Consumption circuit> AVH316K

AVH316K: Descriptionsingle-chip voice synthesizing CMOS IC; CategoryAnalog mixed-signal IC Consumption circuit; File Size357KB，10 Pages; ManufacturerAplus; Websitehttp://www.aplusinc.com.tw/

Download Datasheet Parametric Compare View All

AVH316K Overview

single-chip voice synthesizing CMOS IC

AVH316K Parametric

Parameter Name	Attribute value
Maker	Aplus
package instruction	, DIE OR CHIP
Reach Compliance Code	unknow
Commercial integrated circuit types	SPEECH SYNTHESIZER
Maximum operating temperature	70 °C
Minimum operating temperature
Encapsulate equivalent code	DIE OR CHIP
power supply	3 V
Certification status	Not Qualified
Maximum read time	3.5 s
Maximum slew rate	0.2 mA
technology	CMOS
Temperature level	COMMERCIAL

Preview

Download Datasheet

View All

PLUS MAKE YOUR PRODUCTION A-PLUS

AVxx16K Series

DATA SHEET

PLUS

INTEGRATED CIRCUITS INC.

Sales E-mail:

sales@aplusinc.com.tw

Technology E-mail:

service@aplusinc.com.tw

Address:

3 F-10, No. 32, Sec. 1, Chenggung Rd., Taipei,

Taiwan 115, R.O.C.

(115)台北市南港區成功路㆒段 32

號

樓之

10.

TEL:

886-2-2782-9266

FAX:

886-2-2782-9255

WEBSITE :

http: //www.aplusinc.com.tw

AVxx16K

Series

1. GENERAL DESCRIPTION:

The

AVH316K , AV0716K , AV1416K , AV2116K , AV2816K

and

AV4216K

are single-chip

voice synthesizing CMOS IC. They are low cost with proper functions and can synthesize voice up to 3.5, 7,

14, 21, 28 and 42 seconds, using

Aplus

5-bit LOGPCM algorithm. om t

Cus

er speech data can be

programmed into ROM by changing one mask during the device fabrication. Besides, not only the very

flexible and functional PowerIO pins (IO1/IO2) are available for user to apply in various applications, but also

an interactive development tool “EzSpeech” is ready for user-friendly programming.

2. FEATURES:

(1). Single power supply can operate from 2.4V to 6.4V (in this range, user can set Rosc as a fixed value).

(2). The total voice duration is about 3.5, 7, 14, 21, 28 and 42 seconds those can be partitioned up to 32

voice_sections. Each voice_section length is flexible. Besides, there are additional 32 mute_sections.

(3). Voice length can be individually up to 3.5, 7, 14, 21, 21 and 21 seconds and voice+mute length can be

individually up to 21 seconds at 6kHz sample rate for each voice_section.

(4). Total 96 voice_steps are available for 16 sub_tables. The number of voice_step for each sub_table is

flexible, but maximum is 96. For each voice_step, it can specify one voice_section, playback speed and

IO1/IO2 output enable options if IO1/IO2 are set as output.

(5). Built-in variable oscillator, 16 kinds of playback speed option : ( 3.9k ~ 14.0kHz)

14.0kHz

6.0kHz

12.0kHz

5.5kHz

10.5kHz

5.2kHz

9.3kHz

4.9kHz

8.3kHz

4.6kHz

7.5kHz

4.4kHz

7.0kHz

4.1kHz

6.4kHz

3.9kHz

(6). IO1 or IO2 can be either input or output pin (Mask option).

(7). Optional “Three Triggers Input” (all OKY, IO1 and IO1 are input), “Two Triggers Input” (OKY and IO1 are

input, IO2 is output), or “One Trigger Input” (OKY is input, IO1 and IO2 are output).

(A). Each input pin has mask options for Edge/Level, Hold/Unhold and Retrigger/Irritrigger trigger modes.

(B). OKY input can choose One-Key Sequential or Random for maximum 16 sub_tables. At One-Key

Sequential, the Reset function of sub_table sequence can be chosen when other keys are triggered.

(C). OKY and IO1 input can choose Toggle On/Off function or not.

(D). OKY input can choose CDS+1M、CDS、1M pull-low、10M pull low or floating input type.

IO1 and IO2 input can choose CDS+1M、CDS、1M pull-low or floating input type.

(E). Each input can choose debounce time: Long debounce for push buttons. Short debounce for fast

switches.

(F). Input pin priority：OKY > IO1 > IO2.

Rev 1.1

2003/9/18

AVxx16K

Series

(8). IO1/IO2 have 7 kinds of output option :

(A). Stop_High pulse : high active stop pulse output whenever device stop playing.

(B). Busy_High active : high active signal output during playing.

(C). Busy_Low active : low active signal output during playing.

(D). LED 3Hz flash : 3Hz sink signal output for driving LED during playing at 6kHz sample rate.

(E). LED 6Hz flash : 6Hz sink signal output for driving LED during playing at 6kHz sample rate.

(F). LED dynamic 2/4 : dynamic sink signal output for driving LED during playing.

(G). Synchronous output : arbitrary output with voice, user can edit the Sync signal by PowerIO editor.

※

Where (D) and (E) is the LED flash rate at 6kHz sample rate. For different sample rate, the LED flash

rate is different from original 3Hz or 6Hz.

(9). PWM1 and PWM2 can directly drive buzzer or 8, 16, 32 or 64 ohms speaker.

(10). The voice length in voice_section must be the multiple of 200Hex, and the mute length in voice_section

must be the multiple of 80Hex. But when the voice length in voice_section of “voice + mute” don’t fully

use the last 200Hex, the unused voice length is set as mute and combined with the followed mute time.

(11). In pure mute voice_section of M00~M31, the mute length must be the multiple of 80Hex. The maximum

mute length is up to 21 seconds at 6kHz sample rate for each mute voice_section.

(12). Oscillator selection:

(A). External oscillator: Connect OSC pin to Vdd with a resistor, Rosc.

(B). Internal oscillator: Connect OSC pin to GND.

(Not suggested because of frequency shift and system

stability)

※Input

Type Description:

Option

CDS + 1M

CDS

1M pull-low

Description

Normal selection for button trigger.

Only 1M pull-low resistance when key-pressed, and 1M+300K(parallel) pull-low resistance

when key-released.

Internal 300K ohms pull-low resistance, usually for photo-resistor trigger.

Internal 1M ohms pull-low resistance, reserve for some special applications.

No internal resistor connection, usually connected to other output pin or connected to GND

by an external resistor.

10M pull-low Internal 10M ohms weak pull-low, usually for touching trigger.

Floating

* 10M pull-low option is not available for IO1/IO2 input.

The input type figure is as page 2.

Rev 1.1

2003/9/18

AVH316K Related Products

	AVH316K	AVXX16K	AV4216K	AV2816K	AV1416K
Description	single-chip voice synthesizing CMOS IC	single-chip voice synthesizing CMOS IC	single-chip voice synthesizing CMOS IC	single-chip voice synthesizing CMOS IC	single-chip voice synthesizing CMOS IC
Maker	Aplus	-	Aplus	Aplus	Aplus
package instruction	, DIE OR CHIP	-	, DIE OR CHIP	, DIE OR CHIP	, DIE OR CHIP
Reach Compliance Code	unknow	-	unknow	unknow	unknow
Commercial integrated circuit types	SPEECH SYNTHESIZER	-	SPEECH SYNTHESIZER	SPEECH SYNTHESIZER	SPEECH SYNTHESIZER
Maximum operating temperature	70 °C	-	70 °C	70 °C	70 °C
Encapsulate equivalent code	DIE OR CHIP	-	DIE OR CHIP	DIE OR CHIP	DIE OR CHIP
power supply	3 V	-	3 V	3 V	3 V
Certification status	Not Qualified	-	Not Qualified	Not Qualified	Not Qualified
Maximum read time	3.5 s	-	42 s	28 s	14 s
Maximum slew rate	0.2 mA	-	0.2 mA	0.2 mA	0.2 mA
technology	CMOS	-	CMOS	CMOS	CMOS
Temperature level	COMMERCIAL	-	COMMERCIAL	COMMERCIAL	COMMERCIAL
