05008
DLZ-5
thru
Only One Name Means ProT
ek’Tion™
DLZ-30CA
ST
ANDARD CAPACIT
ANCE TVS ARRA
Y
APPLICA
TIONS
✔
✔
✔
✔
Military & Aerospace Data Line Protection
RS-232 & RS-423 Data Lines
Microprocessor Based Equipment
Multiple Data & Power Bus Line Protection
IEC COMPA
TIBILITY
(EN61000-4)
✔
61000-4-2 (ESD): Air - 15kV, Contact - 8kV
✔
61000-4-4 (EFT): 40A - 5/50ns
✔
61000-4-5 (Surge): 24A, 8/20µs Level 2 (Line-Ground) & Level 3 (Line-Line)
FEA
TURES
✔
MIL-STD-461 Compatible
✔
Protects I/O Devices
✔
Satisfies Military NEMP Requirements
✔
1300 Watts Peak Pulse Power per Line (tp=8/20µs)
✔
Unidirectional & Bidirectional Configurations
✔
ESD Protection > 40 kilovolts
✔
Internal Common Ground
✔
Available in Multiple Voltage Types: 5.0V to 30.0V
✔
MULTIPLE TVS ARRAY: PROTECTS UP TO 15 LINES
MECHANICAL CHARACTERISTICS
✔
Ceramic 16 Pin Hermetically Sealed Package
✔
Weight 3.2 grams (Approximate)
✔
Flammability Rating UL 94V-0
✔
Marking: Logo, Part Number, Date Code & Pin One Defined By Flag on Lead
16 PIN CERAMIC
✔
Screening Available Upon Request - The DLZ series can be screened upon request for military
requirements in accordance with MIL-PRF-19500 (applicable test). Standard screening is available
based on the following options:
H1 - 100% screening per test plans 05227 & 05229
H2 - 100% screening per test plans 05228 & 05230
✔
Screening to DESC Drawing #94029 (Bidirectional) & #94030 (Unidirectional) is also available
PIN CONFIGURA
TIONS
UNIDIRECTIONAL
BIDIRECTIONAL
16
15
14
13
12
11
10
9
16
15
14
13
12
11
10
9
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
05008.R6 11/04
1
www.protekdevices.com
DLZ-5
thru
DLZ-30CA
DEVICE CHARACTERISTICS
MAXIMUM RATINGS @ 25°C Unless Otherwise Specified
PARAMETER
Peak Pulse Power (t
p
= 8/20µs) - See Figure 1
Operating Temperature
Storage Temperature
Forward Surge Rating (1/20 seconds) - Unidirectional Only
SYMBOL
P
PP
T
J
T
STG
I
F
VALUE
1300
-55°C to 150°C
-55°C to 150°C
10
UNITS
Watts
°C
°C
Amps
ELECTRICAL CHARACTERISTICS PER LINE @ 25°C Unless Otherwise Specified
PART
NUMBER
(Note 1)
RATED
STAND-OFF
VOLTAGE
MINIMUM
BREAKDOWN
VOLTAGE
@ 1mA
V
(BR)
VOLTS
MAXIMUM
CLAMPING
VOLTAGE
(See Fig. 2)
@ I
P
= 1 A
V
C
VOLTS
MAXIMUM
CLAMPING
VOLTAGE
(See Fig. 2)
@ 8/20µs
V
C
@ I
PP
MAXIMUM
LEAKAGE
CURRENT
@V
WM
I
D
µA
MAXIMUM
TEMPERATURE
CAPACITANCE COEFFICIENT
OF V
(BR)
@ 0V, 1 MHz
C
J
pF
qV
(BR)
mV/°C
V
WM
VOLTS
DLZ-5
DLZ-5A
DLZ-12
DLZ-12A
DLZ-17
DLZ-17A
DLZ-24
DLZ-24A
DLZ-30
DLZ-30A
DLZ-8C
DLZ-13C
DLZ-13CA
DLZ-19C
DLZ-19CA
DLZ-30C
DLZ-30CA
5.0
5.0
12.0
12.0
17.0
17.0
24.0
24.0
30.0
30.0
8.0
13.0
13.0
19.0
19.0
30.0
30.0
6.0
6.0
13.3
13.3
19.2
19.2
26.7
26.7
33.3
33.3
8.5
14.4
14.4
21.6
21.6
33.3
33.3
10.2
9.5
21.1
19.1
30.4
27.5
42.3
38.3
52.8
47.8
13.4
22.8
20.6
34.2
31.0
52.8
47.8
19.2V @ 66A
18.1V @ 70A
33.0V @ 41A
28.0V @ 48A
40.0V @ 33A
37.4V @ 35A
62.4V @ 21A
50.5V @ 26A
62.9V @ 21A
60.0V @ 24A
29.0V @ 45A
34.0V @ 39A
31.0V @ 43A
47.6V @ 28A
40.5V @ 33A
68.7V @ 19A
62.5V @ 21A
200
200
2
2
2
2
2
2
2
2
10
4
4
4
4
4
4
880
880
440
440
330
330
275
275
220
220
440
385
385
275
275
165
165
5
5
18
18
20
20
31
31
39
39
9
18
18
24
24
39
39
Note 1:
Part numbers with a “C” suffix are bidirectional devices, i.e., DLZ-8C.
05008.R6 11/04
2
www.protekdevices.com
DLZ-5
thru
DLZ-30CA
PACKAGE OUTLINE & DIMENSIONS
PACKAGE OUTLINE
16 PIN CERAMIC DIP
A
C
DIMENSIONS
B
Pin 1
Pin 1 Index
D
DIM
A
B
C
D
E
F
G
H
I
MILLIMETERS
MIN
MAX
22.72
11.43
-
7.36
-
4.19
2.42
0.33
0.88
23.48
12.19
4.87
7.84
-
-
2.66
0.57
1.12
INCHES
MIN
MAX
0.895
0.450
-
0.310
0.025 REF
0.165
0.095
0.023
0.035
0.925
0.480
0.192
0.290
- REF
-
0.105
0.013
0.045
E
G
H
I
F
NOTES:
1. Dimensions are exclusive of metal burrs and solder
protusions.
2. Package sealed with ceramic or metal lid.
Outline & Dimensions: Rev 0 - 3/02, 06029
COPYRIGHT © ProTek Devices 2005
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical characteristics described herein without notice (except JEDEC).
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice, and that the final judgement concerning selection and
specifications is the buyer’s and that in furnishing engineering and technical assistance, ProTek assumes no responsibility with respect to the selection or
specifications of such products.
ProTek Devices
2929 South Fair Lane, Tempe, AZ 85282
Tel: 602-431-8101 Fax: 602-431-2288
E-Mail:
sales@protekdevices.com
Web Site:
www.protekdevices.com
05008.R6 11/04
4
www.protekdevices.com
