05218
EM10Q-100
Only One Name Means ProT
ek’Tion™
LCD - EMI FIL
TER/TVS ARRA
Y
APPLICA
TIONS
✔
LCD Displays
✔
Cellular Phones
✔
Notebooks
✔
Personal Digital Assistant (PDA)
✔
Ground Positioning System (GPS)
✔
SMART Cards
IEC COMPA
TIBILITY
(EN61000-4)
✔
61000-4-2 (ESD): Air - 15kV, Contact - 8kV
✔
61000-4-4 (EFT): 40A - 5/50ns
FEA
TURES
✔
ESD Protection > 25 kilovolts
✔
Bidirectional EMI Filtering/TVS Low Pass Filters
✔
Low Insertion Loss: -3db Roll-Off @ 150MHz
✔
Protects Up to Ten(10) Data Lines
✔
RoHS Compliant on Lead-Free Versions
MECHANICAL CHARACTERISTICS
✔
✔
✔
✔
QFN-20 Package
Weight 0.73 milligrams (Approximate)
Available in Tin-Lead or Lead-Free Pure-Tin Plating(Annealed)
Solder Reflow Temperature:
Tin-Lead - Sn/Pb, 85/15: 240-245°C
Pure-Tin - Sn, 100: 260-270°C
✔
Flammability rating UL 94V-0
✔
Marking: Logo, Part Number and Pin One Defined By Dot on Package
1 2 3 4 5
L3 L2 L1 L1 L2
L4 L5 L6 L7 L8
20 19 18 17 16
L9 L10 L10 L9 L 8
15 14 13 12 11
6 7 8 9 10
L3 L4 L5 L6 L7
20 PIN QFN PACKAGE
3.5mm X 3.5mm
PIN CONFIGURA
TION
I/O 1
Pin 3
D1
I/O 2
Pin 2
I/O 3
Pin 1
I/O 4
Pin 20
I/O 5
Pin 19
R1
D2
R2
R3
R4
R5
Pin 4
I/O 6
I/O 7
Pin 5
I/O 8
Pin 6
I/O 9
Pin 7
I/O 10
Pin 8
Pin 18
D1
Pin 17
Pin 16
Pin 15
Pin 14
R6
D2
R7
R8
R9
R10
Pin 9
Pin 10
Pin 11
Pin 12
Pin 13
Note: Center Tab as the Ground.
05218.R2 3/05
1
www.protekdevices.com
EM10Q-100
DEVICE CHARACTERISTICS
MAXIMUM RATINGS @ 25°C Unless Otherwise Specified
PARAMETER
Operating Temperature
Storage Temperature
DC Power Per Resistor
Typical Resistance @ ± 15%
Soldering Temperature for 10 seconds
SYMBOL
T
J
T
STG
P
R
T
L
VALUE
-40°C to 85°C
-55°C to 150°C
100
100
265 °C
UNITS
°C
°C
mW
OHMS
°C
ELECTRICAL CHARACTERISTICS PER LINE @ 25°C Unless Otherwise Specified
PART
NUMBER
RATED
MINIMUM
STAND-OFF BREAKDOWN
VOLTAGE
VOLTAGE
MAXIMUM
REVERSE
LEAKAGE
CURRENT
@ 3V
I
D
µA
0.1
TYPICAL
FORWARD
VOLTAGE
MINIMUM
ATTENUATION
CUT-OFF
TYPICAL
FREQUENCY CAPACITANCE
(50 Ohms I/O
PER LINE
ZERO BIAS)
(See Note 1)
@2.5V, 1 MHz
C
pF
20
V
WM
VOLTS
EM10Q-100
Note 1:
±20% tolerance.
@ 1mA
V
(BR)
VOLTS
6.0
@10mA
V
F
VOLTS
0.8
@
800-3000 MHz
dB
25
fc
MHz
150
5.0
05218.R2 3/05
2
www.protekdevices.com
EM10Q-100
GRAPHS
FIGURE 1
TYPICAL INSERTION LOSS
(T
A
= 25°C, DC BIAS = 0V, 50OHM ENVIRONMENT)
0
-5
-10
-15
-20
-25
-30
-35
0.1
Insertion Loss - (dB)
1
10
100
1000
10000
Frequency (MHz)
1.100
FIGURE 2
RESISTANCE VS TEMPERATURE
(Normalized to Resistance at 25°C)
Normalized Resistance
1.060
1.020
0.980
0.940
0.900
-40
-20
0
20
40
Temperature °C
60
80
100
05218.R2 3/05
3
www.protekdevices.com
EM10Q-100
PACKAGE OUTLINE & DIMENSIONS
PACKAGE DIMENSIONS
DIM
A
B
D
A
B
Chamfer 0.300 x 45
PACKAGE OUTLINE
Pin 1 Identified by Dot
E
D
F
MILLIMETERS
3.500 SQ ± 0.050
1.830 SQ ± 0.050
0.510 BSC
0.250 ± 0.05
0.450 ± 0.05
0.760 ± 0.05
0.000 - 0.05
0.203 ± 0.025
INCHES
0.1377 SQ ± 0.002
0.0720 SQ ± 0.002
0.020 BSC
0.0098 ± 0.002
0.0177 ± 0.002
0.0299 ± 0.002
0.000 - 0.002
0.0079 ± 0.001
E
F
G
G
H
I
TOP VIEW
H
SIDE VIEW
I
NOTES:
1. Controlling dimensions in inches.
2. Decimal tolerances for mounting pad and
outline: .xxx ± 0.05mm (± 0.002”).
TAPE & REEL ORDERING NOMENCLATURE
1. Surface mount product is taped and
reeled in accordance with EIA 481.
2. Suffix-T7 = 7 Inch Reels - 1,000
pieces per 8mm tape, i.e.,
EM10Q-100-T7.
3. Suffix-T13 = 13 Inch Reels - 3,000
pieces per 8mm tape,
i.e.,
EM10Q-100-T13.
4. Suffix-LF = Pure Tin Plating,
i.e,
EM10Q-100-LF-T7.
MOUNTING PAD
TYPICAL
DIM Millimeters
1
2
3
4
5
4.500
0.820
1.000
0.500
0.310
Inches
0.1771
0.0322
0.0393
0.0200
0.0122
2
1
3
5
4
Outline & Dimensions: Rev 0 - 3/04, 06053
COPYRIGHT © ProTek Devices 2005
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical
characteristics described herein without notice (except JEDEC).
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice, and that
the final judgement concerning selection and specifications is the buyer’s and that in furnishing
engineering and technical assistance, ProTek assumes no responsibility with respect to the
selection or specifications of such products.
