RAFIX 22 QR - Pushbutton, non-illuminated, flush lens, round
collar, plastic front ring, momentary
1.30.240.101/0208
General information
Form of lens
Color of lens
Color of front ring
Form of collar
Dimensions
Dimensions of collar
Overall height
Mounting depth with contact block without cable
Mounting hole
Mounting grid
Mechanical design
Mounting
Contact function
Illumination
Mechanical characteristics
Operating travel
Operating force max.
Robustness max.
Other specifications
Operating life (operations)
Degree of protection from front side
Ambient temp. operating min.
Ambient temp. operating max.
Storage temperature min.
Storage temperature max.
Environmental restistance
ROHS compliant
REACH compliant
flat lens
opaque white
silver-grey
round
ø 29.8 mm
9.4 mm
56.4 mm
ø 22.3 mm
50 x 30 mm
ring nut
momentary
no
4 mm
approx. 5 N for 1 switching element
100 N
1,000,000 momentary / 500,000 latching cycle
IP65 (DIN EN 60529)
-25 °C
+70 °C
-40 °C
+80 °C
acc. to IEC 60068-2-14, -30, -33 and -78
yes
yes
Technical data are approximate and intended solely for general orientation in the selection of a product.
Subject to modifications and errors. Images and other graphics may only be similar.
For more information, refer to www.rafi.de chapter Imprint / Data Protection.
17.06.2018
Panel cut-out to IEC 60947-5-1
Technical data are approximate and intended solely for general orientation in the selection of a product.
Subject to modifications and errors. Images and other graphics may only be similar.
For more information, refer to www.rafi.de chapter Imprint / Data Protection.
