SURFACE MOUNT SHIELDED POWER INDUCTORS
ASPI-0403S SERIES
FEATURES:
• Very small foot print
• Flat-top for pick &place
APPLICATIONS:
• DC/DC converter
• PDA's flash Memory
• Step-up, Step-down converters
RoHS
Compliant
| | | | | | | | | | | | | | |
ELECTRICAL SPECIFICATIONS:
PART NO
ASPI-0403S-
1 R0 M
1R5M
2R2M
3R3M
4R7M
5R6M
6R8M
100M
150M
220M
330M
470M
680M
101M
151M
221M
331M
471M
681M
102M
152M
222M
332M
472M
682M
822M
103M
Lp±20%
(
μ
H)
1.0
1.5
2.2
3.3
4.7
5.6
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1000
1500
2200
3300
4700
6800
8200
10000
DCR
(
Ω)
Max
0.040
0.045
0.050
0.055
0.060
0.063
0.065
0.075
0.090
0.11
0.19
0.23
0.29
0.48
0.59
0.77
1.40
1.80
2.20
3.40
4.20
8.50
11.0
13.9
25.0
27.0
32.8
I
RMS
(A) Max
3.0
2.8
1.8
1.6
1.4
1. 3
1.2
1. 0
0.8
0.7
0.6
0.5
0.4
0. 3
0.26
0.22
0.20
0.19
0.18
0.15
0.12
0.10
0.08
0.06
0. 04
0.03
0.02
SRF
MHz Typ
250
125
120
120
105
65
50
38
33
25
20
20
15
10
9
6
5
4
3
2
2
2
1
1
1
0.9
0.8
OUTLINE DRAWING:
TECHNICAL INFORMATION:
•
Operating temperature:
-40°C to +85°C
•
Test Conditions:
100KHz, 0.1V
RMS
•
Marking:
EIA color code or value
•
Lp tolerance:
M = ±20%
•
Δ
T 30°C
temperature rise max at
I
RMS
•
Insulation core to winding:
10M
Ω
min
•
Add:
-T
for Tape and Reel, 2000 pcs per reel
Note:
All specifications subject to change
without notice.
