Features
n
n
n
n
n
n
n
n
n
n
n
Integrated Precision Reference:
2.5V Full-Scale 10ppm/°C (LTC2637-L)
4.096V Full-Scale 10ppm/°C (LTC2637-H)
Maximum INL Error: 2.5LSB (LTC2637-12)
Low Noise: 0.75mV
P-P
0.1Hz to 200kHz
Guaranteed Monotonic Over –40°C to 125°C
Temperature Range
Selectable Internal or External Reference
2.7V to 5.5V Supply Range (LTC2637-L)
Ultralow Crosstalk Between DACs (<3nV• s)
Low Power: 100µA per DAC at 3V (LTC2637-L)
Power-On-Reset to Zero-Scale/Mid-Scale
Double-Buffered Data Latches
Tiny 14-Lead 4mm
×
3mm DFN and 16-Lead MSOP
Packages
Mobile Communications
Process Control and Industrial Automation
Automatic Test Equipment
Portable Equipment
Automotive
Optical Networking
LTC2637
Octal 12-/10-/8-Bit I
2
C V
OUT
DACs with 10ppm/°C Reference
Description
The
LTC
®
2637
is a family of octal 12-, 10-, and 8-bit
voltage-output DACs with an integrated, high-accuracy,
low-drift 10ppm/°C reference in 14-lead DFN and 16-lead
MSOP packages. It has a rail-to-rail output buffer and is
guaranteed monotonic. The LTC2637-L has a full-scale
output of 2.5V, and operates from a single 2.7V to 5.5V
supply. The LTC2637-H has a full-scale output of 4.096V,
and operates from a 4.5V to 5.5V supply. Each DAC can
also operate with an external reference, which sets the
DAC full-scale output to the external reference voltage.
These DACs communicate via a 2-wire I
2
C-compatible
serial interface. The LTC2637 operates in both the stan-
dard mode (clock rate of 100kHz) and the fast mode (clock
rate of 400kHz). The LTC2637 incorporates a power-on
reset circuit. Options are available for reset to zero-scale
or reset to mid-scale in internal reference mode, or reset
to mid-scale in external reference mode after power-up.
L,
LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks and
ThinSOT is a trademark of Analog Devices, Inc. All other trademarks are the property of their
respective owners. Protected by U.S. Patents including 5396245, 5859606, 6891433, 6937178,
7414561.
applications
n
n
n
n
n
n
Block Diagram
INTERNAL REFERENCE
GND
SWITCH
V
REF
V
CC
REGISTER
REGISTER
REGISTER
REGISTER
V
OUTA
V
REF
REGISTER
REGISTER
REGISTER
V
OUTB
V
REF
REGISTER
REGISTER
REGISTER
V
OUTC
V
REF
V
OUTD
DAC D
REGISTER
DAC C
DAC F
V
REF
DAC E
POWER-ON RESET
I
2
C
ADDRESS
DECODE
I
2
C INTERFACE
2637 BD
REF
Integral Nonlinearity (LTC2637-LZ12)
2
V
CC
= 3V
INTERNAL REF
.
DAC A
DAC H
V
REF
V
OUTH
INL (LSB)
1
REGISTER
0
DAC B
DAC G
V
REF
V
OUTG
–1
V
OUTF
–2
0
1024
REGISTER
REGISTER
REGISTER
REGISTER
2048
CODE
3072
4095
2637 TA01
V
OUTE
CAO
(CA1)
(CA2)
DECODE
SCL
SDA
( ) MSOP PACKAGE ONLY
2637fc
For more information
www.linear.com/LTC2637
1
LTC2637
aBsolute maximum ratings
(Notes 1, 2)
Supply Voltage (V
CC
) ................................... –0.3V to 6V
SCL, SDA ..................................................... –0.3V to 6V
V
OUTA
- V
OUTH
,
CA0, CA1, CA2................... –0.3V to Min(V
CC
+ 0.3V, 6V)
REF ................................... –0.3V to Min(V
CC
+ 0.3V, 6V)
Operating Temperature Range
LTC2637C ................................................ 0°C to 70°C
LTC2637I ............................................. –40°C to 85°C
LTC2637H (Note 3) ............................ –40°C to 125°C
Maximum Junction Temperature .......................... 150°C
Storage Temperature Range .................. –65°C to 150°C
Lead Temperature (Soldering, 10 sec)
MS Package ...................................................... 300°C
pin conFiguration
TOP VIEW
V
CC
V
OUTA
V
OUTB
V
OUTC
V
OUTD
CA0
SCL
1
2
3
4
5
6
7
15
14 GND
13 V
OUTH
12 V
OUTG
11 V
OUTF
10 V
OUTE
9 REF
8 SDA
V
CC
V
OUTA
V
OUTB
V
OUTC
V
OUTD
CA2
CA0
SCL
1
2
3
4
5
6
7
8
TOP VIEW
16
15
14
13
12
11
10
9
GND
V
OUTH
V
OUTG
V
OUTF
V
OUTE
REF
CA1
SDA
DE PACKAGE
14-LEAD (4mm
×
3mm) PLASTIC DFN
T
JMAX
= 150°C,
θ
JA
= 37°C/W
EXPOSED PAD (PIN 15) IS GND, MUST BE SOLDERED TO PCB
MS PACKAGE
16-LEAD (4mm
×
5mm) PLASTIC MSOP
T
JMAX
= 150°C,
θ
JA
= 110°C/W
2
2637fc
For more information
www.linear.com/LTC2637
LTC2637
orDer inFormation
LTC2637 C
DE
–L
Z
12
#TR
http://www.linear.com/product/LTC2637#orderinfo
PBF
LEAD FREE DESIGNATOR
TAPE AND REEL
TR = 2500-Piece Tape and Reel
RESOLUTION
12 = 12-Bit
10 = 10-Bit
8 = 8-Bit
POWER-ON RESET
MI = Reset to Mid-Scale in Internal Reference Mode
MX = Reset to Mid-Scale in External Reference Mode
Z = Reset to Zero-Scale in Internal Reference Mode
FULL-SCALE VOLTAGE, INTERNAL REFERENCE MODE
L = 2.5V
H = 4.096V
PACKAGE TYPE
DE = 14-Lead DFN
MS = 16-Lead MSOP
TEMPERATURE GRADE
C = Commercial Temperature Range (0°C to 70°C)
I = Industrial Temperature Range (–40°C to 85°C)
H = Automotive Temperature Range (–40°C to 125°C)
PRODUCT PART NUMBER
Consult LTC Marketing for information on non-standard lead based finish parts.
For more information on lead free part marking, go to:
http://www.linear.com/leadfree/
For more information on tape and reel specifications, go to:
http://www.linear.com/tapeandreel/.
Some packages are available in 500 unit reels
through designated sales channels with #TRMPBF suffix.
2637fc
For more information
www.linear.com/LTC2637
