1N4728G ~ 1N4758G
Taiwan Semiconductor
Small Signal Product
1W DO-41 Zener Volatge Regulators
FEATURES
- Zener voltage range 3.3 to 56Volts
- DO-41 package (JEDEC)
- Through-hole device type mounting
- Hermetically sealed glass
- Compression bonded construction
- All external surfaces are corrosion resistant and
terminals are readily solderable
- Solder hot dip tin(Sn) lead finish
- Pb free and RoHS compliant
DO-41
MECHANICAL DATA
- Lead: Pure tin plated, lead free, solderable per
MIL-STD-202, method 208 guaranteed
- Polarity: Color band denotes cathode
- High temperature soldering guaranteed: ' 260
o
C/10 s
- Weight: 0.270~0.290 grams
- Marking code: 1N47XXG for ± 5% Vz
Cathode
Anode
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25℃ unless otherwise noted)
PARAMETER
Power Dissipation
Thermal Resistance Junction to Lead
Thermal Resistance Junction to Ambient
OperatingTemperature Range
Storage Temperature Range
SYMBOL
P
D
R
jl
R
ja
T
OPR
T
STG
VALUE
1
53.5
100
- 65 to + 200
- 65 to + 200
UNIT
W
o
o
C/W
C/W
o
o
C
C
Note: These ratings are limiting values above which the serviceability of the diode may be impaired
Version: F1606
1N4728G ~ 1N4758G
Taiwan Semiconductor
Small Signal Product
ELECTRICAL CHARACTERISTICS
(Ratings at T
A
=25
o
C ambient temperature unless otherwise specified)
V
F
Forward Voltage = 1.2 V Maximum @ I
F
= 200 mA for all types
Device
Type
1N4728G
1N4729G
1N4730G
1N4731G
1N4732G
1N4733G
1N4734G
1N4735G
1N4736G
1N4737G
1N4738G
1N4739G
1N4740G
1N4741G
1N4742G
1N4743G
1N4744G
1N4745G
1N4746G
1N4747G
1N4748G
1N4749G
1N4750G
1N4751G
1N4752G
1N4753G
1N4754G
1N4755G
1N4756G
1N4757G
1N4758G
V
Z
@ I
ZT
(V)
Typ.
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
I
ZT
(mA)
76
69
64
58
53
49
45
41
37
34
31
28
25
23
21
19
17
15.5
14
12.5
11.5
10.5
9.5
8.5
7.5
7
6.5
6
5.5
5
4.5
Z
ZT
@ O
ZK
(Ω)
Max.
10
10
9
9
8
7
5
2
3.5
4
4.5
5
7
8
9
10
14
16
20
22
23
25
35
40
45
50
60
70
80
95
110
I
ZK
(mA)
1
1
1
1
1
1
1
1
1
0.5
0.5
0.5
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
Z
ZK
@ I
ZK
(Ω)
Max.
400
400
400
400
500
550
600
700
700
700
700
700
700
700
700
700
700
700
700
750
750
750
750
1000
1000
1000
1000
1500
1500
1500
2000
I
R
@ V
R
(μA)
Max.
100
100
50
10
10
10
10
10
10
10
10
10
10
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
V
R
(V)
1
1
1
1
1
1
2
3
4
5
6
7
7.6
8.4
9.1
9.9
11.4
12.2
13.7
15.2
16.7
18.2
20.6
22.8
25.1
27.4
29.7
32.7
35.8
38.8
42.6
Notes : 1. TOLERANCE AND TYPE NUMBER DESIGNATION (V
Z
)
The type numbers listed have a standard tolerance on the nmial zener voltage of ±5%.
2. SPECIAL AVAILABLE INCLUDE
Nomial zener voltages shown and tighter voltage, for detailed information on price, availability and delivery,
contact your nearest Taiwan Semiconductor representative.
3. ZENER VOLTAGE (V
Z
) MEASUREMENT
The zener voltage (V
Z
) is tested under pulse condition. The measured V
Z
is guaranteed to be within
specification with device junction in thermal equilibrium.
4. ZENER IMPEDANCE (Z
Z
) DERIVATION
The zener impedance is derived from the 60-cycle ac voltage, which results when an ac current having an
RMS value equal to 10% of the dc zener current(I
ZT
or I
ZK
) is superimposed to I
ZT
or I
ZK
.
Version: F1606
1N4728G ~ 1N4758G
Taiwan Semiconductor
Small Signal Product
ORDERING INFORMATION
PART NO.
1N47xxG
(Note1,2)
PACKING CODE
R0
A0
GREEN COMPOUND
CODE
G
G
PACKAGE
DO-41
DO-41
PACKING
5K / 14" Reel
3K / BOX (Ammo)
Note 1: "xx" is Device Code from "28" through "58"
Note 2: Whole series with green compound.
EXAMPLE
PREFERRED
PART NO.
1N4728G R0G
PART NO.
1N4728G
PACKING
CODE
R0
PACKING CODE
SUFFIX
G
DESCRIPTION
Green compound
Version: F1606
1N4728G ~ 1N4758G
Taiwan Semiconductor
Small Signal Product
PACKAGE OUTLINE DIMENSIONS
DO-41
DIM.
A
B
C
D
Unit (mm)
Min
0.50
3.50
22.00
1.80
Max
0.90
5.20
--
2.80
Unit (inch)
Min
0.020
0.138
0.866
0.071
Max
0.035
0.205
--
0.110
MARKING DIAGRAM
XX
XX
XXX
1N
47
XXG
Version: F1606
1N4728G ~ 1N4758G
Taiwan Semiconductor
Small Signal Product
Notice
Specifications of the products displayed herein are subject to change without notice. TSC or anyone on its behalf, assumes no
responsibility or liability for any errors inaccuracies.
Information contained herein is intended to provide a product description only. No license, express or implied, to any intellectual property
rights is granted by this document. Except as provided in TSC's terms and conditions of sale for such products, TSC assumes no liability
whatsoever, and disclaims any express or implied warranty, relating to sale and/or use of TSC products including liability or warranties
relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright, or other intellectual property right.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications. Customers using or seling these
products for use in such applications do so at their own risk and agree to fully indemnify TSC for any damages resulting from such
improper use or sale.
Version: F1606
