05027
PHP8.4-PHP500
thru
Only One Name Means ProT
ek’Tion™
PIP8.4-PIP500
AC POWER BUS VOL AGE SUPPRESSOR
T
APPLICA
TIONS
✔
Secondary AC Power Supply
✔
Aircraft & Shipboard AC Power Bus
✔
Heavy Duty AC Switching Power
FEA
TURES
✔
Meets the Following Military Specifications:
- DOD-STD-1389
- MIL-STD-2036
- MIL-STD-704
- MIL-PRF-STD-19500/507
✔
7,500 & 15,000 Watts Peak Pulse Power per Line (tp=10/1000µs)
✔
Each Device 100% Tested
✔
Available in Multiple Voltages Ranging From: 8.4V to 500V
MECHANICAL CHARACTERISTICS
✔
Hermetically Sealed Glass to Metal Sub-Assemblies (PHP)
✔
Sub-Assemblies are Packaged in Molded Epoxy Case (PIP)
✔
Weight 46 grams (Approximate)
✔
Flammability rating UL 94V-0
✔
Device Marking: Logo & Part Number
✔
Screening Available Upon Request - The PHP & PIP series can be screened upon
request for military requirements in accordance with MIL-PRF-19500 (applicable test).
Standard screening is available based on the following options:
H1 - Submodule Screening per test plans 05231 & 05232
H2 - Submodule & Module Screening per test plan 05233
H3 - Submodule & Module Screening, Module Group B & C Lot Testing
per test plans 05234 & 05235
PIP & PHP PACKAGE
MAXIMUM RATINGS @ 25°C Unless Otherwise Specified
PARAMETER
Peak Pulse Power (tp = 10/1000µs) - See Figure 1
Operating Temperature
Storage Temperature
Steady State Power Dissipation @ 50°C
SYMBOL
P
PP
T
J
T
STG
T
A
VALUE
7.5 & 15
-55°C to 150°C
-55°C to 150°C
7.5
UNITS
kilowatts
°C
°C
Watts
05027.R4 11/04
1
www.protekdevices.com
PHP8.4-PHP500
thru
PIP8.4-PIP500
DEVICE CHARACTERISTICS
ELECTRICAL CHARACTERISTICS PER LINE @ 25°C Unless Otherwise Specified
PART
NUMBER
(See Notes 1-2)
AVERAGE
RMS
VOLTAGE
RATED
STAND-OFF
VOLTAGE
MINIMUM
BREAKDOWN
VOLTAGE
(See Note 1)
@ 1mA
V
(BR)
VOLTS
14
40
50
100
200
347
418
735
835
14
40
50
100
200
347
418
735
835
MAXIMUM
CLAMPING
VOLTAGE
(See Fig. 2)
@ I
PPM
V
C
VOLTS
22
67
84
167
319
536
652
1138
1292
22
67
84
167
319
536
652
1138
1292
MAXIMUM
LEAKAGE
CURRENT
MAXIMUM
PEAK PULSE
CURRENT
MAXIMUM
PEAK PULSE
POWER
V
RMS
VOLTS
PHP8.4
PHP24
PHP30
PHP60
PHP120*
PHP208
PHP250*
PHP440
PHP500*
PIP8.4
PIP24
PIP30
PIP60
PIP120*
PIP208
PIP250*
PIP440
PIP500*
8.4
24.0
30.0
60.0
120.0
208.0
250.0
440.0
500.0
8.4
24.0
30.0
60.0
120.0
208.0
250.0
440.0
500.0
V
WM
VOLTS
12.0
34.0
42.5
85.0
170.0
295.0
354.0
623.0
708.0
12.0
34.0
42.5
85.0
170.0
295.0
354.0
623.0
708.0
@V
WM
I
D
µA
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
I
PPM
AMPS
341
112
90
90
47
28
23
13.2
11.6
341
112
90
90
47
28
23
13.2
11.6
@ 1ms
P
PP
KILOWATTS
7.5
7.5
7.5
15.0
15.0
15.0
15.0
15.0
15.0
7.5
7.5
7.5
15.0
15.0
15.0
15.0
15.0
15.0
Note 1:
An * indicates that this series is recommended for marine applications. For military and aerospace applications, use the PHP Series. For
industrial applications use the PIP Series
Note 2:
The following devices have a peak pulse power rating of 7,500W for a 10/1000µs waveform (see Figure 1): 8.4V, 24V and 30V.
05027.R4 11/04
2
www.protekdevices.com
PHP8.4-PHP500
thru
PIP8.4-PIP500
PACKAGE OUTLINE & DIMENSIONS
PHP & PIP PACKAGE OUTLINE
PHP & PIP PACKAGE
A
C
B
D
G
H
DIM
A
B
C
D*
E
F*
G
DIMENSIONS
MILLIMETERS
MIN
MAX
56.38
49.02
3.43
20.32
8.26
3.18 DIA
16.76
34.16
6.35
11.94
57.91
50.03
4.17
20.32
9.27
3.18 DIA
18.29
35.69
6.35
13.46
INCHES
MIN
MAX
2.22
1.93
0.135
0.800
0.325
2.28
1.97
0.165
E
F
J
I
Outline & Dimensions: Rev 0 - 4/02, 06032
H
I*
J
0.800
0.365
0.125 DIA 0.125 DIA
0.660
0.720
1.345
1.405
0.250
0.47
0.250
0.53
Note*:
Dimensions are nominal.
COPYRIGHT © ProTek Devices 2005
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical characteristics described herein without notice (except JEDEC).
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice, and that the final judgement concerning selection and
specifications is the buyer’s and that in furnishing engineering and technical assistance, ProTek assumes no responsibility with respect to the selection or
specifications of such products.
