APL5708R
Low I
Q
, Low Dropout 700mA Fixed Voltage Regulator
Features
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Low Quiescent Current : 60µA (No load)
Low Dropout Voltage : 700mV (@700mA)
Very low Shutdown Current : < 0.5uA
Fixed Output Voltage : 1.5V ~ 3.5V
by step 0.1V increment
Stable with 2.2µF Output Capacitor
Stable with Aluminum, Tantalum or Ceramic
Capacitors .
No Protection Diodes Needed
Built in Thermal Protection
Built in Current Limit Protection
Controlled Short Circuit Current : 50mA
Fast Transient Response
Short Setting Time
SOT-223 Package
Lead Free Available (RoHS Compliant)
General Description
The APL5708R series are micropower, low dropout
linear regulators, which operate from 2.7V to 6V input
voltage and deliver up to 700mA. Typical dropout volt-
age is only 700mV at 700mA loading. Designed for
using in battery-powered system, the low 60µA qui-
escent current makes it an ideal choice. Design with
an internal P-channel MOSFET pass transistor, the
APL5708R maintain a low supply current, indepen-
dent of the load current and dropout voltage. Other
features include thermal-shutdown protection, current
limit protection to ensure specified output current and
controlled short-circuit current. The APL5708R regu-
lators come in a miniature SOT-223 package.
Pin Configuration
T A B is V
O U T
Applications
•
•
•
•
•
5V to 3.3~3.5V Linear Regulators
3.3V to 1.5~2.5V Linear Regulators
CD-R/W, DVD Player
LAN Card, ADSL/Cable Modem
Computers
1
2
3
GND
V
OUT
V
IN
SOT-223 (Top View)
APL5708R
ANPEC reserves the right to make changes to improve reliability or manufacturability without notice, and advise
customers to obtain the latest version of relevant information to verify before placing orders.
Copyright
ANPEC Electronics Corp.
Rev. A.2 - May., 2005
1
www.anpec.com.tw
APL5708R
Ordering and Marking Information
APL5708R -
L e a d F re e C o d e
H a n d lin g C o d e
Tem p. Range
P ackage C ode
V o lta g e C o d e
P ackage C ode
V : S O T -2 2 3
Tem p. Range
C : 0 to 7 0
°
C
H a n d lin g C o d e
TR : Tape & Reel
V o lta g e C o d e :
1 5 : 1 .5 V ~ 3 5 : 3 .5 V
L e a d F re e C o d e
L : L e a d F re e D e vc ie
B la n k : O rig in a l D e vic e
A P L 5 7 0 8 R -1 5 V :
A PL5708R
XXXXX15
XXXXX
- D a te C o d e
;
1 5 - 1 .5 V
Notes: ANPEC lead-free products contain molding compounds/die attach materials and 100% matte in plate termi-
nation finish; which are fully compliant with RoHS and compatible with both SnPb and lead-free soldiering operations.
ANPEC lead-free products meet or exceed the lead-free requirements of IPC/JEDEC J STD-020C for MSL classifica-
tion at lead-free peak reflow temperature.
Pin Description
PIN
Name
GND
V
OUT
V
IN
I/O
Description
Ground pins of the circuitry.
Output pin of the regulator.
Supply voltage input.
No.
1
2
3
O
I
Absolute Maximum Ratings
Symbol
V
IN
, V
OUT
R
TH,JA
P
D
T
J
Parameter
Input Voltage or Out Voltage
Thermal Resistance – Junction to Ambient
Power Dissipation
Operating Junction Temperature
Control Section
Power Transistor
T
STG
T
L
Storage Temperature Range
Lead Temperature (Soldering, 10 second)
Rating
6
135
Internally Limited
0 to 125
0 to 150
-65 to +150
260
°C
°C
Unit
V
°C/W
W
°C
Copyright
ANPEC Electronics Corp.
Rev. A.2 - May., 2005
2
www.anpec.com.tw
APL5708R
Electrical Characteristics
Unless otherwise noted these specifications apply over full temperature, C
IN
=1µF, C
OUT
=2.2µF, T
J
=0 to
125°C. Typical values refer to T
J
=25°C.
Symbol
V
IN
V
OUT
I
LIMIT
Parameter
Input Voltage
Output Voltage
Circuit Current Limit
V
OUT
+1.0V< V
CC
<6.0V, 0mA< I
OUT
<
V
IN
=V
OUT
+1V
V
OUT
=0V
V
IN
=V
OUT
+1V
V
OUT
+1V< V
CC
<6.0V, I
OUT
=1mA
V
IN
=V
OUT
+1V, 0mA< I
OUT
< I
MAX
V
IN
= V
OUT
+1V, I
OUT
=1mA-700mA in 1µs
(Note1)
Test Conditions
APL5708R
Min.
2.7
V
OUT
-2%
Typ.
Max.
6
Unit
V
V
mA
mA
mA
V
OUT
V
OUT
+2%
900
50
I
SHORT
Short Current
I
OUT
Load Current
REG
LINE
Line Regulation
REG
LOAD
Load Regulation
Load Transient
700
1
25
150
1.1
0.9
0.8
0.7
55
60
450
150
30
10
40
250
1.3
1.0
0.9
0.8
100
500
mV
mV
mV
V
DROP
Dropout Voltage
PSRR Ripple Rejection
I
Q
OTS
1.5V≤V
OUT
<2.0V
2.0V≤V
OUT
<2.5V
I
OUT
=700mA
2.5V≤V
OUT
<3V
3V≤V
OUT
≤
3.5V
F≤1kHz, 1Vpp at V
IN
= V
OUT
+1.0V
No load
I
OUT
=700mA
V
45
dB
µA
°C
°C
ppm/°C
µF
1
Ohm
Quiescent Current
Over Temperature
Shutdown
Over Temperature
Hysteresis
Shutdown Hysteresis
TC
C
OUT
Output Voltage
Temperature
Coefficient
Output Capacitor
ESR
0.01
50
2.2
0.1
Note1: Dropout voltage definition: V
IN
- V
OUT
when V
OUT
is 2% below the value of V
OUT
for V
IN
= V
OUT
+1V.
Application Circuit
IN P U T
2 .7 V to 6 V
V
IN
AP L5708R
GND
C
OUT
2 .2
µ
F
V
OUT
VO UT
C
IN
1
µ
F
1
Copyright
ANPEC Electronics Corp.
Rev. A.2 - May., 2005
3
www.anpec.com.tw
