F-211-1 SUPPLEMENT
6QP–052–11.00–TEU–TED–1–S
6QP SERIES
POWER/SIGNAL COMBO CABLE ASSEMBLY
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?6QP
Mates with:
QFS
38 AWG
50Ω
coax cable
Minimizes EMI
aggression
Signal Cable:
Cable Type:
38 AWG
50Ω coax
Current Rating:
300 mA max
Capacitance:
96.79 pF/meter (nominal)
Inductance:
.230 mH/meter (nominal)
Propagation Delay:
4.79 nS/meter
Minimizes
coupling
to high speed
signals
52 signal
lines
Cable
Length
6" (152,4mm)
12" (304,8mm)
39.37" (1m)
Rated @ 7dB
Insertion Loss
6QP
9.24 GHz / 18.48 Gbps
6.16 GHz / 12.32 Gbps
5.19 GHz / 10.38 Gbps
Power Cable:
Cable Type:
26 AWG 13Ω coax
Current Rating:
4A
Capacitance:
239 pF/meter (nominal)
Inductance:
.092 mH/meter (nominal)
Propagation Delay:
4.79 nS/meter
26 AWG
13Ω “Quiet Power”
coax cable
26 power
lines
Connector:
Insulator Material:
Liquid Crystal Polymer
Terminal & Ground
Plane Material:
Phosphor Bronze
Plating:
Au over 50µ" (1,27µm) Ni
6QP
NO. OF
POSITIONS
WIRE
LENGTH
END
NO. 1
END
NO. 2
WIRING
OPTION
SCREW
OPTION
Leave
blank for
no Screw
Option
–TEU
–052
= 52 Signal Lines,
26 Power Lines
–1
= Pin 1 to
Pin 1
Assembly:
–“XX.XX”
= Wire Length
in Inches
(95,3mm) 03.75"
minimum
OAL = Wire Length + (25,70) 1.012
Wire Length ± (1,27) .050
= Terminal,
Edge Mount Up
Voltage Rating:
300 VAC mated with QFS
Operating Temp:
-55°C to +105°C
RoHS Compliant:
Yes
–TED
= Terminal,
Edge Mount Down
–2
= Pin 1 to
Pin 2
–F
= End
No. 1
–3
= Pin 1 to
Pin 103
–S
= End
No. 2
–4
104
103
1
2
= Pin 1 to
Pin 104
–B
= Both
Ends
Note:
Cable lengths longer than
40.00" (1 meter) are not
supported with S.I. test data.
Note:
Verify part number and correct
wiring scheme with Samtec’s
Interactive Cable Builder at
www.samtec.com/cable_
builder/pitch.aspx
Note:
This Series is non-standard,
non-returnable.
(76,96)
3.030
(73,15)
2.880
2
1
103
104
–TED–TEU SHOWN
WWW.SAMTEC.COM
