5962-9063301MCB: Description5962-9063301MCB amplifier basic information: 5962-9063301MCB is an OPERATIONAL AMPLIFIER. The commonly used packaging method is CERDIP-14 5962-9063301MCB amplifier core information: The minimum operating temperature of 5962-9063301MCB is -55 °C and the maximum operating temperature is 125 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum average bias current is 0.0002 µA How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of 5962-9063301MCB is 20 V/us. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the gain of 5962-9063301MCB becomes 0.707 times the low-frequency gain is 4000 kHz. The nominal supply voltage of 5962-9063301MCB is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of 5962-9063301MCB is 2000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).) Related dimensions of 5962-9063301MCB: The width of 5962-9063301MCB is: 7.62 mm and the length is 19.43 mm. 5962-9063301MCB has 14 terminals. Its terminal position type is: DUAL. Terminal pitch is 2.54 mm. Total pins: 14 5962-9063301MCB amplifier other information: Its temperature grade is: MILITARY. 5962-9063301MCB does not comply with Rohs certification. The corresponding JESD-30 code is: R-GDIP-T14. The corresponding JESD-609 code is: e0. The packaging code of 5962-9063301MCB is: DIP. The materials used in the 5962-9063301MCB package are mostly CERAMIC and GLASS-SEALED. The package shape is RECTANGULAR. The 5962-9063301MCB package pin format is: IN-LINE. Its terminal form is: THROUGH-HOLE. The maximum seat height is 5.08 mm.; CategoryAmplifier circuit; File Size459KB，14 Pages; ManufacturerADI; Websitehttps://www.analog.com; Alternative parts：5962-9063301MCB

Download Datasheet Parametric Compare View All

5962-9063301MCB Overview

5962-9063301MCB amplifier basic information:

5962-9063301MCB is an OPERATIONAL AMPLIFIER. The commonly used packaging method is CERDIP-14

5962-9063301MCB amplifier core information:

The minimum operating temperature of 5962-9063301MCB is -55 °C and the maximum operating temperature is 125 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum average bias current is 0.0002 µA

How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of 5962-9063301MCB is 20 V/us. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the gain of 5962-9063301MCB becomes 0.707 times the low-frequency gain is 4000 kHz.

The nominal supply voltage of 5962-9063301MCB is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of 5962-9063301MCB is 2000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)

Related dimensions of 5962-9063301MCB:

The width of 5962-9063301MCB is: 7.62 mm and the length is 19.43 mm. 5962-9063301MCB has 14 terminals. Its terminal position type is: DUAL. Terminal pitch is 2.54 mm. Total pins: 14

5962-9063301MCB amplifier other information:

Its temperature grade is: MILITARY. 5962-9063301MCB does not comply with Rohs certification. The corresponding JESD-30 code is: R-GDIP-T14. The corresponding JESD-609 code is: e0. The packaging code of 5962-9063301MCB is: DIP.

The materials used in the 5962-9063301MCB package are mostly CERAMIC and GLASS-SEALED. The package shape is RECTANGULAR. The 5962-9063301MCB package pin format is: IN-LINE. Its terminal form is: THROUGH-HOLE. The maximum seat height is 5.08 mm.

5962-9063301MCB Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	ADI
Parts packaging code	DIP
package instruction	CERDIP-14
Contacts	14
Reach Compliance Code	compliant
ECCN code	EAR99
Amplifier type	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	0.0002 µA
Nominal Common Mode Rejection Ratio	80 dB
Maximum input offset voltage	2000 µV
JESD-30 code	R-GDIP-T14
JESD-609 code	e0
length	19.43 mm
Negative supply voltage upper limit	-18 V
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of functions	4
Number of terminals	14
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Filter level	MIL-STD-883
Maximum seat height	5.08 mm
Nominal slew rate	20 V/us
Supply voltage upper limit	18 V
Nominal supply voltage (Vsup)	15 V
surface mount	NO
technology	BIPOLAR
Temperature level	MILITARY
Terminal surface	TIN LEAD
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Nominal Uniform Gain Bandwidth	4000 kHz
width	7.62 mm
Base Number Matches	1

Preview

Download Datasheet

View All

FEATURES

Enhanced Replacement for LF347 and TL084

AC PERFORMANCE

1 ms Settling to 0.01% for 10 V Step

20 V/ms Slew Rate

0.0003% Total Harmonic Distortion (THD)

4 MHz Unity Gain Bandwidth

DC PERFORMANCE

0.5 mV max Offset Voltage (AD713K)

20 mV/°C max Drift (AD713K)

200 V/mV min Open Loop Gain (AD713K)

2 mV p-p typ Noise, 0.1 Hz to 10 Hz

True 14-Bit Accuracy

Single Version: AD711, Dual Version: AD712

Available in 16-Pin SOIC, 14-Pin Plastic DIP and

Hermetic Cerdip Packages

Standard Military Drawing Available

APPLICATIONS

Active Filters

Quad Output Buffers for 12- and 14-Bit DACs

Input Buffers for Precision ADCs

Photo Diode Preamplifier Application

Quad Precision, Low Cost,

High Speed, BiFET Op Amp

AD713

CONNECTION DIAGRAMS

Plastic (N) and

Cerdip (Q) Packages

SOIC (R) Package

OUTPUT

–IN

+IN

–IN

OUTPUT

14 OUTPUT

13 –IN

12 +IN

–IN

+IN

–IN

OUTPUT

–IN

+IN

–V

+IN

–IN

OUTPUT

AD713

(TOP VIEW)

AD713

(TOP VIEW)

11 –V

10 +IN

–IN

OUTPUT

NC = NO CONNECT

The AD713 is offered in a 16-pin SOIC, 14-pin plastic DIP and

hermetic cerdip package.

PRODUCT HIGHLIGHTS

PRODUCT DESCRIPTION

The AD713 is a quad operational amplifier, consisting of four

AD711 BiFET op amps. These precision monolithic op amps

offer excellent dc characteristics plus rapid settling times, high

slew rates, and ample bandwidths. In addition, the AD713

provides the close matching ac and dc characteristics inherent

to amplifiers sharing the same monolithic die.

The single-pole response of the AD713 provides fast settling:

µs

to 0.01%. This feature, combined with its high dc precision,

makes the AD713 suitable for use as a buffer amplifier for 12-

or 14-bit DACs and ADCs. It is also an excellent choice for use

in active filters in 12-, 14- and 16-bit data acquisition systems.

Furthermore, the AD713’s low total harmonic distortion (THD)

level of 0.0003% and very close matching ac characteristics

make it an ideal amplifier for many demanding audio applications.

The AD713 is internally compensated for stable operation at

unity gain and is available in seven performance grades. The

AD713J and AD713K are rated over the commercial temperature

range of 0°C to 70°C. The AD713A and AD713B are rated

over the industrial temperature of –40°C to +85°C. The

AD713S and AD713T are rated over the military temperature

range of –55°C to +125°C and are available processed to

standard microcircuit drawings.

REV. C

Information furnished by Analog Devices is believed to be accurate and

reliable. However, no responsibility is assumed by Analog Devices for its

use, nor for any infringements of patents or other rights of third parties that

may result from its use. No license is granted by implication or otherwise

under any patent or patent rights of Analog Devices.

1. The AD713 is a high speed BiFET op amp that offers excellent

performance at competitive prices. It upgrades the perfor-

mance of circuits using op amps such as the TL074, TL084,

LT1058, LF347 and OPA404.

2. Slew rate is 100% tested for a guaranteed minimum of

16 V/µs (J, A and S Grades).

3. The combination of Analog Devices’ advanced processing

technology, laser wafer drift trimming and well-matched

ion-implanted JFETs provides outstanding dc precision.

Input offset voltage, input bias current and input offset cur-

rent are specified in the warmed-up condition and are 100%

tested.

4. Very close matching of ac characteristics between the four

amplifiers makes the AD713 ideal for high quality active filter

applications.

One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.

Tel: 781/329-4700

www.analog.com

Fax: 781/326-8703
