MIL-DTL-83513
Micro-D
500-010
EMI/RFI Micro-D Banding Backshell
Round Cable Entry
Glenair’s Most Popular Micro-D Backshell
is
stocked in all sizes. Choose straight, side or 45°
cable entry.
Rugged One-Piece Aluminum shell
with
stainless steel hardware, available in standard
nickel plating, or choose optional finishes.
17-7PH Stainless Steel Clips
attach the backshell
to the connector. These backshells accept
standard and micro BandMaster™ ATS shield
termination straps.
Note: It is easy to exceed the maximum allowable wire bundle diameter for the cable entry
on these miniaturized backshells. Please see the table on C-3 for assistance, or chose an
elliptical backshell entry design instead.
How To Order EMI/RFI Backshells
Sample Part Number
Series
500T010
M
25
H
08
Shell Finish
Shell Size
Hardware Option
Cable Entry Code
EMI Band Strap Option
500S010
- Side Entry
500T010
- Top Entry
500E010
- 45° Entry
500D010
- Dual 45°
(See Table III)
A
- Cadmium Plate/Bright Dip
N
- Cadmium Plate/Olive Drab; Over Nickel
B
- Cadmium Plate/Olive Drab
NF
- Cad/O. D. Over Electroless; Nickel
B1
- Cadmium Plate/Olive Drab, Type II Class 1 (1000 Hour Salt Spray)
J
- Gold Iridite Over Cadmium; Plate Over
T
- Cadmium Plate/Bright Dip Over Nickel
Nickel
Z2
- Gold Plate
M
- Electroless Nickel
Z1
- Passivate, Stainless;Steel Material
09, 15, 21, 25, 31, 37, 51, 51-2, 67, 69, 100
(See Table III)
EJ
- (2) Male Extended (Style T and S Only)
B
- (2) Fillister Head Jackscrew
BJ
- (2) Male Fillister Head
F
- (2) Jackpost, Female
H
- (2) Hex Head Jackscrew
FB
- (1) Female Jackpost, (1) Male Filister Head
HJ
- (2) Male Hex
FH
- (1) Female Jackpost, (1) Male Hex Socket
E
– (2) Extended Jackscrew
N
- No Hardware
05
- .156 (4.0)
06
- .188 (4.8)
07
- .219 (5.6)
08
- .250 (6.4)
04
- .125 (3.2)
09
- .281 (7.1)
10
- .312 (7.9)
11
- .344 (8.7)
12
- .375 (9.5)
(See Table I)
Omit
(Leave Blank) - Band Not Included
Standard Band
- .250" Wide
K
- Coiled Band Included
B
- Uncoiled Band Included
Use the following codes to order band strap with
Micro Band
-
.125" Wide
the connector. For best availability, order band
M
- Uncoiled Band Included
L
- Coiled Band Included
separately.
Table I: Maximum Cable Entry
Code
Shell
Size
9
15
21
25
31
37
51
51-2
67
69
100
Style E
&T
08
08
08
08
09
09
10
09
09
10
12
Style D
06
08
08
08
09
09
10
09
09
10
12
Style S
09
10
10
12
12
12
12
12
12
12
12
Table II: Maximum Cable Entry
Dimensions
Cable
Size
04
05
06
07
08
09
10
11
12
P ±.015
In. ± mm. ±
.015
0.38
.125
3.2
.156
.188
.219
.250
.281
.312
.344
.375
4.0
4.8
5.6
6.4
7.1
7.9
8.7
9.5
R Dia. Max
In.
.296
.327
.359
.390
.421
.452
.484
.515
.546
mm.
7.5
8.3
9.1
9.9
10.7
11.5
12.3
13.1
13.7
Notes
1. Assembly identified with manufacturer's name and P/N
1. 51-2 shell size is for a special 51 position 2 row Micro D
connector
2. Knurled or ribbed banding platform - manufactures option
3. EMI gasket mounts between mating connector and panel
Materials/Finish
• Shell: Aluminum Alloy 6061 -T6 Per QQ-A-200, QQ-A-225
(Machined Components)
Aluminum Alloy 6061-T6 Per QQ-A-591 (A380) (Die-Cast
Components)
• Clips, E-Rings: 17-7PH Stainless Steel
• Jackscrews, Washers, Jackposts: 300 Series Stainless Steel,
Passivated
© 2014 Glenair, Inc.
Rectangular Connector Backshells
U.S. CAGE Code 06324
Rev 8-18-14
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
C-14
500-010
EMI/RFI Micro-D Banding Backshell
Round Cable Entry
Style T - Top Entry
E
R
Max Typ
.06(1.5)
.44(11.2)
Table III: Dimensions
Available for Style T and S Only
Code B
P Typ
.04 Min
L
Configuration
Mfr Option
Code BJ
D
F .175
(4.4)
Code EJ
Extended Jackscrew
H
Connector Shown
For Reference Only
Code E
Floating Extended Jackscrew
H
Code F
Female Jackpost
Style E - 45° Entry
Style S - Side Entry
M
N
.390
(9.9)
.188(4.8)
Code HJ
Hex Socket Jackscrew
Code H
Extended Jackscrew
G
K
Configuration
Mfr Option
Style D - 45° Dual Entry
EMI Gasket Option (559-005)
See Note 4
C
Optional
Configuration
See Note 3
B
A
M
N
Code S
Qwik-Ty
Size
09
15
A Max.
B Max.
C
D Max.
E Max.
F Max
G Max
H Max.
J Max.
K
L Max.
M Max.
N Max.
In. mm. In. mm. In. mm. In. mm. In. mm. In. mm. In. mm. In. mm. In. mm. In. mm. In. mm. In. mm. In. mm.
.850 21.59 .370 9.40 .565 14.35 .780 19.81 .410 10.41 .350 8.89 .637 16.18 .350 8.89 .637 16.18 .435 11.05 1.040 26.42 1.000 25.40 .680 17.27
1.000 25.40 .370 9.40 .715 18.16 .910 23.11 .580 14.73 .470 11.94 673 17.09 .470 11.94 .673 17.09 .440 11.2 1.170 29.72 1.030 26.16 .730 18.54
21
1.150 29.21 .370 9.40 .865 21.97 1.030 26.16 .740 18.80 .590 14.99 .707 17.95 .590 14.99 .707 17.95 .458 11.63 1.290 32.77 1.050 26.67 .765 19.43
25
1.250 31.75 .370 9.40 .965 24.51 1.090 27.69 .850 21.59 .650 16.51 .748 19.00 .650 16.51 .748 19.00 .483 12.27 1.350 34.29 1.090 27.69 .830 21.08
31
1.400 35.56 .370 9.40 1.115 28.32 1.150 29.21 .980 24.89 .710 18.03 .756 19.20 .710 18.03 .756 19.20 .476 12.09 1.420 36.07 1.130 28.70 .890 22.61
37
1.550 39.37 .370 9.40 1.265 32.13 1.190 30.23 1.130 28.70 .750 19.05 .774 19.66 .750 19.05 .774 19.66 .478 12.14 1.450 36.83 1.230 31.24 .955 24.26
51
1.500 38.10 .410 10.41 1.215 30.86 1.220 30.99 1.080 27.43 .780 19.81 .859 21.82 .780 19.81 .859 21.82 .548 13.91 1.480 37.59 1.250 31.75 1.005 25.53
51-2
1.910 48.51 .370 9.40 1.615 41.02 1.220 30.99 1.510 38.35 .780 19.81 .859 21.82 .780 19.81 .859 21.82 .548 13.91 1.480 37.59 1.250 31.75 1.005 25.53
67
2.310 58.67 .370 9.40 2.015 51.18 1.220 30.99 1.880 47.75 .780 19.81 .859 21.82 .780 19.81 .859 21.82 .548 13.91 1.480 37.59 1.250 31.75 1.005 25.53
69
1.810 45.97 .410 10.41 1.515 38.48 1.220 30.99 1.380 35.05 .780 19.81 .859 21.82 .780 19.81 .859 21.82 .548 13.91 1.480 37.59 1.250 31.75 1.005 25.53
100
2.235 56.77 .460 11.68 1.800 45.72 1.280 32.51 1.470 37.34 .840 21.34 1.014 25.76 .840 21.34 1.014 25.76 .687 17.45 1.580 40.13 1.320 33.53 1.080 27.43
© 2014 Glenair, Inc.
Rectangular Connector Backshells
U.S. CAGE Code 06324
Rev 8-18-14
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
C-15
