M74HC423
DUAL RETRIGGERABLE MONOSTABLE MULTIVIBRATOR
s
s
s
s
s
s
s
s
HIGH SPEED :
t
PD
= 22 ns (TYP.) at V
CC
= 6V
LOW POWER DISSIPATION:
STAND BY STATE :
I
CC
=4µA (MAX.) at T
A
=25°C
ACTIVE STATE :
I
CC
=700µA (TYP.) at V
CC
= 6V
HIGH NOISE IMMUNITY:
V
NIH
= V
NIL
= 28 % V
CC
(MIN.)
SYMMETRICAL OUTPUT IMPEDANCE:
|I
OH
| = I
OL
= 4mA (MIN)
BALANCED PROPAGATION DELAYS:
t
PLH
≅
t
PHL
WIDE OPERATING VOLTAGE RANGE:
V
CC
(OPR) = 2V to 6V
WIDE OUTPUT PULSE WIDTH RANGE :
t
WOUT
= 120 ns ~ 60 s OVER AT V
CC
= 4.5 V
PIN AND FUNCTION COMPATIBLE WITH
74 SERIES 423
DIP
SOP
TSSOP
ORDER CODES
PACKAGE
DIP
SOP
TSSOP
TUBE
M74HC423B1R
M74HC423M1R
T&R
M74HC423RM13TR
M74HC423TTR
DESCRIPTION
The M74HC423 is an high speed CMOS
MONOSTABLE MULTIVIBRATOR fabricated with
silicon gate C
2
MOS technology.
There are two trigger inputs, A INPUT (negative
edge) and B INPUT (positive edge). These inputs
are valid for slow rising/falling signals, (tr = tf = 1
sec). After triggering the output maintains the
MONOSTABLE
state for the time period
PIN CONNECTION AND IEC LOGIC SYMBOLS
determined by the external resistor Rx and
capacitor Cx.
The pulse width constant is K
≅
0.46.
Taking CLR low breaks this MONOSTABLE
STATE. If the next trigger pulse occurs during the
MONOSTABLE
period
it
makes
the
MONOSTABLE period longer. Limit for values of
Cx and Rx :
Cx : NO LIMIT
Rx : V
cc
< 3.0V 5KΩ to 1MΩ
V
cc
> 3.0V 1KΩ to 1MΩ
All inputs are equipped with protection circuits
against static discharge and transient excess
voltage.
July 2001
1/11
M74HC423
TIMING CHART
BLOCK DIAGRAM
1) Cx, Rx, Dx are external components.
(2) Dx is a clamping diode.
The external capacitor is charged to Vcc in the stand-by-state, i.e. no trigger. When the supply voltage is turned off Cx is di scharged mainly
trough an internal parasitic diode(see figures). If Cx is sufficiently large and Vcc decreases rapidly, there will be some possibility of damaging
the I.C. with a surge current or latch-up. If the voltage supply filter capacitor is large enough and Vcc decrease slowly, the surge current is
automatically limited and damage to the I.C. is avoided. The maximum forward current of the parasitic diode is approximately 20 mA. In cases
where Cx is large the time taken for the supply voltage to fall to 0.4 Vcc can be calculated as follows :
t
f
> (Vcc - 0.7) x Cx/20mA
In cases where t
f
is too short an external clamping diode is required to protect the I.C. from the surge current.
3/11
M74HC423
FUNCTIONAL DESCRIPTION
STAND-BY STATE
The external capacitor,Cx, is fully charged to Vcc
in the stand-by state. Hence, before triggering,
transistor Qp and Qn (connected to the Rx/Cx
node) are both turned-off. The two comparators
that control the timing and the two reference
voltage sources stop operating. The total supply
current is therefore only leakage current.
TRIGGER OPERATION
Triggering occurs when :
1 st) A is "LOW" and B has a falling edge;
2 nd) B is "HIGH" and A has a rising edge;
3 rd) A is "LOW" and B is HIGH and C1 has a
rising edge;
After the multivibrator has been retriggered
comparator C1 and C2 start operating and Qn is
turned on. Cx then discharges through Qn. The
voltage at the node R/C external falls.
When it reaches V
REFL
the output of comparator
C1 becomes low. This in turn reset the flip-flop
and Qn is turned off.
At this point C1 stops functioning but C2 continues
to operate.
The voltage at R/C external begins to rise with a
time constant set by the external components Rx,
Cx.
Triggering the multivibrator causes Q to go high
after internal delay due to the flip-flop and the
gate. Q remains high until the voltage at R/C
external rises again to V
REFH
. At this point C2
ABSOLUTE MAXIMUM RATINGS
Symbol
V
CC
V
I
V
O
I
IK
I
OK
I
O
P
D
T
stg
T
L
Supply Voltage
DC Input Voltage
DC Output Voltage
DC Input Diode Current
DC Output Diode Current
DC Output Current
Power Dissipation
Storage Temperature
Lead Temperature (10 sec)
Parameter
Value
-0.5 to +7
-0.5 to V
CC
+ 0.5
-0.5 to V
CC
+ 0.5
±
20
±
20
±
25
±
50
500(*)
-65 to +150
300
Unit
V
V
V
mA
mA
mA
mA
mW
°C
°C
output goes low and O goes low. C2 stop
operating. That means that after triggering when
the voltage R/C external returns to V
REFH
the
multivibrator has returned to its MONOSTABLE
STATE. In the case where Rx · Cx are large
enough and the discharge time of the capacitor
and the delay time in the I.C. can be ignored, the
width of the output pulse tw (out) is as follows :
tW(OUT) = 0.46 Cx · Rx
RE - TRIGGERED OPERATION
When a second trigger pulse follows the first its
effect will depend on the state of the multivibrator.
If the capacitor Cx is being charged the voltage
level of R/C external falls to V
REFL
again and Q
remains High i.e. the retrigger pulse arrives in a
time shorter than the period Rx · Cx seconds, the
capacitor charging time constant. If the second
trigger pulse is very close to the initial trigger pulse
it is ineffective ; i.e. the second trigger must arrive
in the capacitor discharge cycle to be ineffective;
Hence the minimum time for a second trigger to be
effective depends on Vcc and Cx
RESET OPERATION
CL is normally high. If CL is low, the trigger is not
effective because Q output goes low and trigger
control flip-flop is reset.
Also transistor Op is turned on and Cx is charged
quickly to Vcc. This means if CL input goes low the
IC becomes waiting state both in operating and
non operating state.
I
CC
or I
GND
DC V
CC
or Ground Current
Absolute Maximum Ratings are those values beyond which damage to the device may occur. Functional operation under these conditions is
not implied
(*) 500mW at 65
°
C; derate to 300mW by 10mW/
°
C from 65
°
C to 85
°
C
4/11
