to Be Discontinued: 2 Form C type (Standard, Reverse polarity type)
Last time buy:
March
31, 2015
DS
2) 2 coil latching type
Type
Nominal coil
voltage
1.5V DC
3V DC
5V DC
6V DC
9V DC
12V DC
24V DC
48V DC
1.5V DC
3V DC
5V DC
High
sensitivity
(S) type
6V DC
9V DC
12V DC
24V DC
48V DC
1 Form C:
80%V or less of
nominal voltage
2 Form C:
70%V or less of
nominal voltage
(Initial)
1 Form C:
80%V or less of
nominal voltage
2 Form C:
70%V or less of
nominal voltage
(Initial)
Set voltage
(at 20°C
68°F)
Reset voltage
(at 20°C
68°F)
Nominal operating
current [±10%]
(at 20°C
68°F)
Set coil Reset coil
240mA
120mA
72mA
60mA
40mA
30mA
15mA
7.5mA
120mA
60mA
36mA
30mA
20mA
15mA
7.5mA
3.75mA
240mA
120mA
72mA
60mA
40mA
30mA
15mA
7.5mA
120mA
60mA
36mA
30mA
20mA
15mA
7.5mA
3.75mA
Coil resistance
[±10%]
(at 20°C
68°F)
Set coil Reset coil
6.25Ω
25Ω
69.4Ω
100Ω
225Ω
400Ω
1,600Ω
6,400Ω
12.5Ω
50Ω
139Ω
200Ω
450Ω
800Ω
3,200Ω
12,800Ω
6.25Ω
25Ω
69.4Ω
100Ω
225Ω
400Ω
1,600Ω
6,400Ω
12.5Ω
50Ω
139Ω
200Ω
450Ω
800Ω
3,200Ω
12,800Ω
180mW
180mW
2 Form C:
200%V of
nominal voltage
Nominal operating
power
Set coil
Reset coil
1 Form C:
120%V of
nominal voltage
360mW
360mW
2 Form C:
150%V of
nominal voltage
Max. applied voltage
(at 50°C
122°F)
Standard
(M) type
70%V or less of
nominal voltage
(Initial)
70%V or less of
nominal voltage
(Initial)
1 Form C:
160%V of
nominal voltage
2. Specifications
Characteristics
Contact
Item
Arrangement
Initial contact resistance, max.
Contact material
Nominal switching capacity
Max. switching power
Max. switching voltage
Max. carrying current
Min. switching capacity (Reference value)*
1
Nominal operating power
Insulation resistance (Initial)
Breakdown voltage
(Initial)
Electrical
characteristics
Temperature rise
Operate time [Set time] (at 20°C
68°F)
Release time [Reset time] (at 20°C
68°F)
Functional*
2
Destructive
Functional
Vibration resistance
Destructive
Mechanical
Electrical
Shock resistance
Conditions for operation, transport and storage*
3
Max. operating speed (at rated load)
Unit weight
Between open contacts
Between contact and coil
Specifications
1 Form C
2 Form C
Max. 50 mΩ (By voltage drop 6 V DC 1A)
Ag+Au clad
2 A 30 V DC (resistive load)
60 W, 125 VA (resistive load)
220 V DC, 250 V AC
3A
10µA 10m V DC
Single side stable (M type: 400 mW, S type: 200 mW);
latching (M type: 360 mW, S type: 180 mW)
Min. 100MΩ (at 500V DC)
Measurement at same location as “Initial breakdown voltage” section.
1,000 Vrms for 1min.
(500 Vrms for 1min: 1 Form C high sensitivity type) (Detection current: 10mA.)
1,500 Vrms for 1min.
(1,000 Vrms for 1min: 1 Form C high sensitivity type) (Detection current: 10mA.)
Max. 65°C
(By resistive method, nominal coil voltage applied to the coil, contact carrying current: 2A.)
Max. 10 ms [10 ms] (Nominal coil voltage applied to the coil, excluding contact bounce time.)
Max. 5 ms [10 ms] (Nominal coil voltage applied to the coil, excluding contact bounce time.)
(without diode)
Min. 490 m/s
2
Min. 490 m/s
2
2
(Half-wave pulse of sine wave: 6 ms.)
Min. 980 m/s
10 to 55 Hz at double amplitude of 3.3 mm (Detection time: 10µs.)
10 to 55 Hz at double amplitude of 5 mm
Min. 10
8
(10
7
: 1 Form C latching type) (at 600 cpm)
Min. 5×10
5
rated load (at 60 cpm)
Ambient temperature: –40°C to +70°C
–40°F to +158°F
Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature)
60 cpm
Approx. 3 g
.11 oz
Approx. 4g
.14oz
Rating
Mechanical
characteristics
Expected life
Conditions
Notes: *1 This value can change due to the switching frequency, environmental conditions, and desired reliability level, therefore it is recommended to check this with the
actual load. (TX/TX-S/TX-D relay AgPd contact type are available for low level load switching [10V DC, 10mA max. level])
*2 Half-wave pulse of sine wave: 11ms; detection time: 10µs
*3 Refer to 6. Conditions for operation, transport and storage mentioned in AMBIENT ENVIRONMENT (Page 24).
