AEM, Inc.
Multilayer Ferrite Chip Beads
Features
•
Monolithic structure for closed magnetic path and high reliability
•
Standard EIA/EIAJ chip sizes such as 0402/1005, 0603/1608,
•
•
•
•
•
•
•
Operating Temperature
-55ºC — +125ºC
0805/2012, and 1206/3216
A complete set of ferrite and electrode materials providing a wide
range of electrical properties
Superior termination bonding strength
Nickel barrier with solder overplated termination offering excellent
solderability and solder leach resistance, suitable for both wave and
reflow soldering processes
RoHS compliant when -T option is specified
Product Identification
MCB 0805 F 101 P T - T
(1) (2) (3) (4) (5) (6) (7)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
Series code:
MCB: Multilayer Ferrite Chip Bead
Dimensions: L x W inches
The first two digits: L (length)
The last two digits: W (width)
Characteristic code: F, G
Value code: Impedance (ohms at 100 MHz)
The first two digits are significant. The last
digit specifies the number of zeros to follow.
Tolerance code:
P = ±25%
Other tolerances may be available upon request.
Package code:
T = Tape & Reel
B = Bulk
Termination type code:
T = 100% Sn Plating
Applications
Noise suppression in computers and peripherals
Noise suppression in telecommunications
Noise suppression in data communications
Recommended PC Board Land Patterns
CHIP SIZE
EIA/EIAJ
0402(1005)
0603(1608)
0805(2012)
1206(3216)
1210(3225)
1806(4516)
1812(4532)
L
INCH (mm)
0.063 (1.60)
0.102 (2.60)
0.118 (3.00)
0.173 (4.40)
0.173 (4.40)
0.217 (5.50)
0.217 (5.50)
G
INCH (mm)
0.016 (0.40)
0.022 (0.55)
0.026 (0.66)
0.059 (1.50)
0.059 (1.50)
0.110 (2.80)
0.110 (2.80)
H
INCH (mm)
0.024 (0.60)
0.037 (0.94)
0.057 (1.45)
0.071 (1.80)
0.106 (2.70)
0.071 (1.80)
0.134 (3.40)
Shape and Dimensions
SOLDER
W
NICKEL
L
G
H
SILVER
METALLIZATION
T
L
ELECTRODE
BW
CHIP SIZE
EIA/EIAJ
0402/1005
0603/1608
0805/2012
1206/3216
1210/3225
1806/4516
1812/4532
LENGTH (L)
INCH (mm)
0.039 ± 0.004
(1.00 ± 0.10)
0.063 ± 0.006
(1.60 ± 0.15)
0.079 ± 0.008
(2.00 ± 0.20)
0.126 ± 0.008
(3.20 ± 0.20)
0.126 ± 0.008
(3.20 ± 0.20)
0.177 ± 0.010
(4.50 ± 0.25)
0.177 ± 0.010
(4.50 ± 0.25)
WIDTH (W)
INCH (mm)
0.020 ± 0.004
(0.50 ± 0.10)
0.031 ± 0.006
(0.80 ± 0.15)
0.049 ± 0.008
(1.25 ± 0.20)
0.063 ± 0.008
(1.60 ± 0.20)
0.098 ± 0.008
(2.50 ± 0.20)
0.063 ± 0.008
(0.51 ± 0.30)
0.126 ± 0.008
(0.51 ± 0.30)
THICKNESS (T)
INCH (mm)
0.020 ± 0.004
(0.50 ± 0.10)
0.031 ± 0.006
(0.80 ± 0.15)
0.035 ± 0.008
(0.90 ± 0.20)
0.043 ± 0.008
(1.10 ± 0.20)
0.051 ± 0.008
(1.30 ± 0.20)
0.063 ± 0.008
(1.60 ± 0.20)
0.059 ± 0.008
(1.50 ± 0.20)
TERMINATION (BW)
INCH (mm)
0.010 ± 0.004
(0.25 ± 0.10)
0.014 ± 0.006
(0.36 ± 0.15)
0.020 ± 0.012
(0.51 ± 0.30)
0.020 ± 0.012
(0.51 ± 0.30)
0.020 ± 0.012
(0.51 ± 0.30)
0.020 ± 0.012
(0.51 ± 0.30)
0.020 ± 0.012
(0.51 ± 0.30)
Other sizes and values may be available upon customer’s request.
1
11525 Sorrento Valley Road, San Diego, CA 92121, U.S.A.
www.aem-usa.com
Phone: (858)481-0210, Fax: (858)481-1123
AEM, Inc.
MCB Series (General Use)
AEM Part
Number
MCB0805G102
MCB0805G152
MCB0805G202
MCB0805G222
MCB1206F190
MCB1206F260
MCB1206F300
MCB1206F310
MCB1206F500
MCB1206F600
MCB1206F700
MCB1206F800
MCB1206F900
MCB1206F101
MCB1206F121
MCB1206F151
MCB1206F201
MCB1206F301
MCB1206F601
MCB1206G102
MCB1206G152
MCB1206G202
MCB1210G520
MCB1210G600
MCB1806F600
MCB1806F800
MCB1806F101
MCB1806F151
MCB1812F700
MCB1812F121
MCB1812F131
Z@100Mz
Ω
Tolerance
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
Max. R
DC
Ω
Max.
I
A
0.20
0.20
0.20
0.20
0.80
0.80
0.80
0.80
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.40
0.40
0.30
0.20
0.20
0.20
0.40
0.40
0.50
0.40
0.40
0.40
0.60
0.40
0.40
1000
1500
2000
2200
19
26
30
31
50
60
70
80
90
100
120
150
200
300
600
1000
1500@50MHz
2000@30MHz
52
60
60
80
100
150
70
120
130
0.40
0.55
0.60
0.80
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.20
0.20
0.20
0.20
0.15
0.30
0.30
0.40
0.60
0.70
0.70
0.30
0.30
0.20
0.30
0.30
0.30
0.10
0.30
0.30
Please add tolerance, packaging and termination type codes when ordering.
3
11525 Sorrento Valley Road, San Diego, CA 92121, U.S.A.
www.aem-usa.com
Phone: (858)481-0210, Fax: (858)481-1123
AEM, Inc.
Electrical Characteristics
(Curves not listed are available upon request)
MCB0402G150
100.00
1000
MCB0402G221
10.00
|Z|, XL, R (Ohm)
|Z|,XL,R (Ohm)
100
1.00
|Z|
XL
R
10
|Z|
XL
R
0.10
1
0.01
1
10
100
1000
FREQUENCY (MHz)
0.1
1
10
100
1000
FREQUENCY (MHz)
MCB 0603G300
1000
1000
MCB 0603G600
100
|Z|, XL, R (O hm)
|Z|
10
XL
R
1
|Z|, XL, R (O hm)
100
|Z|
10
XL
R
1
0.1
1
10
100
1000
FREQUENCY (MHz)
0.1
1
10
100
1000
FREQUENCY (MHz)
MCB 0603G800
1000
1000
MCB 0603G900
100
|Z|
10
XL
R
1
|Z|, XL, R (O hm)
|Z|, XL, R (Ohm)
100
|Z|
10
XL
R
1
0.1
1
10
100
1000
FREQUENCY (MHz)
0.1
1
10
100
1000
FREQUENCY (MHz)
4
11525 Sorrento Valley Road, San Diego, CA 92121, U.S.A.
www.aem-usa.com
Phone: (858)481-0210, Fax: (858)481-1123
AEM, Inc.
Electrical Characteristics
(Curves not listed are available upon request)
MCB 0603G101
1000
1000
MCB 0603G121
100
|Z|, XL, R (O hm)
|Z|
10
XL
R
1
|Z|, XL, R (O hm)
100
|Z|
10
XL
R
1
0.1
1
10
100
1000
FREQUENCY (MHz)
0.1
1
10
100
1000
FREQUENCY (MHz)
MCB 0603G151
1000
1000
MCB 0603G301
100
|Z|, XL, R (O hm)
|Z|
10
XL
R
1
|Z|, XL, R (O hm)
100
|Z|
10
XL
R
1
0.1
1
10
100
1000
FREQUENCY (MHz)
0.1
1
10
100
1000
FREQUENCY (MHz)
MCB 0603G601
1000
10000
MCB 0603G102
1000
100
|Z|, XL, R (O hm)
|Z|, XL, R (O hm)
100
|Z|
XL
10
R
|Z|
10
XL
R
1
1
0.1
1
10
100
1000
FREQUENCY (MHz)
0.1
1
10
100
1000
FREQUENCY (MHz)
5
11525 Sorrento Valley Road, San Diego, CA 92121, U.S.A.
www.aem-usa.com
Phone: (858)481-0210, Fax: (858)481-1123
