Series AM15EW-IZ
15 Watt | DC-DC Converter
FEATURES:
•
RoHS compliant
•
Wide 4:1 input range
•
Low ripple and noise
•
Remote On/Off control
•
•
•
•
Power modules for PCB mounting
Regulated output
Operating temperature range: -40 to +75ºC
Capacitive loading up to 4500 µF (18-75V input)
Models
Single output
Model
AM15EW-2403SIZ
AM15EW-2405SIZ
AM15EW-2412SIZ
AM15EW-2415SIZ
AM15EW-4803SIZ
AM15EW-4805SIZ
AM15EW-4812SIZ
AM15EW-4815SIZ
Input
Voltage
(V)
9-36
9-36
9-36
9-36
18-75
18-75
18-75
18-75
Output
Voltage
(V)
3.3
5
12
15
3.3
5
12
15
Output
Current max
(A)
4
3
1.25
1
4
3
1.25
1
Ripple & Noise
% Vout,
max
80mV p-p
80mV p-p
1
1
80mV p-p
80mV p-p
1
1
Isolation
(VDC)
1500
1500
1500
1500
1500
1500
1500
1500
Efficiency
(%)
77
80
85
84
77
80
85
84
Models
Dual output
Model
AM15EW-2405DIZ
AM15EW-2412DIZ
AM15EW-2415DIZ
AM15EW-4805DIZ
AM15EW-4812DIZ
AM15EW-4815DIZ
Input
Voltage
(V)
9-36
9-36
9-36
18-72
18-72
18-72
Output
Voltage
(V)
±5
±12
±15
±5
±12
±15
Output
Current max
(A)
±1.5
±0.625
±0.5
±1.5
±0.625
±0.5
Ripple &
Noise
% Vout,
max
1
1
1
1
1
1
Isolation
(VDC)
1500
1500
1500
1500
1500
1500
Efficiency
(%)
80
85
84
80
85
84
Input Specifications
Parameters
Voltage range
Filter
Conditions
Typical
9-36
18-75
π
(Pi) Network
Maximum
Units
VDC
Isolation Specifications
Parameters
Rated voltage
Resistance
Capacitance
Conditions
60 sec
Typical
1500
> 1000
1000
Maximum
Units
VDC
MOhm
pF
Output Specifications
Parameters
Voltage accuracy
Short Circuit protection
Over voltage protection
Over load protection
Line voltage regulation (Single)
Conditions
Auto recovery
Auto recovery
HL-LL
Typical
Continuous,
Zener diode clamp protection
Over 110% full load
Maximum
±2
Units
%
±0.5
%
www.aimtec.com
Tel: +1 514 620 2722
1 of 2
Toll free: + 1 888 9 AIMTEC
(926 6832)
North America only
Series AM15EW-IZ
15 Watt | DC-DC Converter
Output Specifications (continued)
Parameters
Line voltage regulation (Dual)
Load voltage regulation (Single)
Load voltage regulation (Dual)
Temperature coefficient
Conditions
HL-LL
25-100%
25-100%
Typical
Maximum
±0.5
±0.5
±2
Units
%
%
%
%/
o
C
±0.05
General Specifications
Parameters
Switching frequency
Operating temperature
Storage temperature
Case temperature
Cooling
Humidity
Case material
Weight
Dimensions
MTBF
Conditions
100% load
Without derating
Typical
200
-40 to +75
-55 to +115
Maximum
Units
KHz
o
C
o
C
o
C
95
Free air convection
Non condensing
95
%
Nickel coated copper with non-conductive base
33
g
Tolerance ±0.5mm
2.00 x 1.0 x 0.4 inches
50.8 x 25.4 x 10.2 mm
> 800 000 hrs (MIL-HDBK -217F, Ground Benign, t=+25
o
C)
Pin Out Specifications
Pin
1
2
3
4
5
6
Dimensions
Dual
On/Off Control
-V Input
+V Input
-V Output
Common
+V Output
Single
On/Off Control
-V Input
+V Input
-V Output
No pin
+V Output
Block diagram
www.aimtec.com
Tel: +1 514 620 2722
2 of 2
Toll free: + 1 888 9 AIMTEC
(926 6832)
North America only
