PCA-6F-04-HL-3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> PCA-6F-04-HL-3

PCA-6F-04-HL-3: DescriptionCard Edge Connector, 4 Contact(s), 1 Row(s), Right Angle, 0.02 inch Pitch, Surface Mount Terminal, Locking; CategoryThe connector; File Size87KB，1 Pages; ManufacturerAdam Tech; Environmental Compliance

Download Datasheet Parametric Compare View All

PCA-6F-04-HL-3 Overview

Card Edge Connector, 4 Contact(s), 1 Row(s), Right Angle, 0.02 inch Pitch, Surface Mount Terminal, Locking

PCA-6F-04-HL-3 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Adam Tech
Reach Compliance Code	compliant
Is Samacsys	N
Board mount options	SOLDER HOLDING POSTS
body width	0.039 inch
body length	0.149 inch
Connector type	FFC/FPC CONNECTOR
Contact to complete cooperation	SN ON CU
Contact completed and terminated	Tin/Copper (Sn/Cu)
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact resistance	30 mΩ
Contact style	BELLOWED TYPE
Dielectric withstand voltage	500VAC V
maximum insertion force	ZIF N
Insulation resistance	500000000 Ω
insulator material	LIQUID CRYSTAL POLYMER (LCP)
JESD-609 code	e2
Plug contact pitch	0.02 inch
Installation option 1	LOCKING
Installation method	RIGHT ANGLE
Installation type	BOARD
PCB row number	1
Number of rows loaded	1
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
PCB contact pattern	RECTANGULAR
Rated current (signal)	0.4 A
Guideline	UL, CSA
reliability	COMMERCIAL
Terminal pitch	0.508 mm
Termination type	SURFACE MOUNT
Total number of contacts	4
Base Number Matches	1

Preview

Download Datasheet

View All

PCA-6F-04-HL-3 Related Products

	PCA-6F-04-HL-3	HCHP1206K2611FNTE	PCA-6F-08-HL-3	PCA-6F-09-HL-3
Description	Card Edge Connector, 4 Contact(s), 1 Row(s), Right Angle, 0.02 inch Pitch, Surface Mount Terminal, Locking	Fixed Resistor, Metal Glaze/thick Film, 0.25W, 2610ohm, 200V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 1206, CHIP	Card Edge Connector, 8 Contact(s), 1 Row(s), Right Angle, 0.02 inch Pitch, Surface Mount Terminal, Locking	Card Edge Connector, 9 Contact(s), 1 Row(s), Right Angle, 0.02 inch Pitch, Surface Mount Terminal, Locking
Is it Rohs certified?	conform to	conform to	conform to	conform to
Reach Compliance Code	compliant	unknown	compliant	compliant
JESD-609 code	e2	e2	e2	e2
Maximum operating temperature	85 °C	155 °C	85 °C	85 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C
Maker	Adam Tech	-	Adam Tech	Adam Tech
Board mount options	SOLDER HOLDING POSTS	-	SOLDER HOLDING POSTS	SOLDER HOLDING POSTS
body width	0.039 inch	-	0.039 inch	0.039 inch
body length	0.149 inch	-	0.229 inch	0.249 inch
Connector type	FFC/FPC CONNECTOR	-	FFC/FPC CONNECTOR	FFC/FPC CONNECTOR
Contact to complete cooperation	SN ON CU	-	SN ON CU	SN ON CU
Contact completed and terminated	Tin/Copper (Sn/Cu)	-	Tin/Copper (Sn/Cu)	Tin/Copper (Sn/Cu)
Contact material	PHOSPHOR BRONZE	-	PHOSPHOR BRONZE	PHOSPHOR BRONZE
contact mode	RECTANGULAR	-	RECTANGULAR	RECTANGULAR
Contact resistance	30 mΩ	-	30 mΩ	30 mΩ
Contact style	BELLOWED TYPE	-	BELLOWED TYPE	BELLOWED TYPE
Dielectric withstand voltage	500VAC V	-	500VAC V	500VAC V
maximum insertion force	ZIF N	-	ZIF N	ZIF N
Insulation resistance	500000000 Ω	-	500000000 Ω	500000000 Ω
insulator material	LIQUID CRYSTAL POLYMER (LCP)	-	LIQUID CRYSTAL POLYMER (LCP)	LIQUID CRYSTAL POLYMER (LCP)
Plug contact pitch	0.02 inch	-	0.02 inch	0.02 inch
Installation option 1	LOCKING	-	LOCKING	LOCKING
Installation method	RIGHT ANGLE	-	RIGHT ANGLE	RIGHT ANGLE
Installation type	BOARD	-	BOARD	BOARD
PCB row number	1	-	1	1
Number of rows loaded	1	-	1	1
PCB contact pattern	RECTANGULAR	-	RECTANGULAR	RECTANGULAR
Rated current (signal)	0.4 A	-	0.4 A	0.4 A
Guideline	UL, CSA	-	UL, CSA	UL, CSA
reliability	COMMERCIAL	-	COMMERCIAL	COMMERCIAL
Terminal pitch	0.508 mm	-	0.508 mm	0.508 mm
Termination type	SURFACE MOUNT	-	SURFACE MOUNT	SURFACE MOUNT
Total number of contacts	4	-	8	9
