High Pass Filter
50Ω
4250 to 10000 MHz
-55ºC to 100ºC
-55ºC to 100ºC
7W max. at 25ºC
Ceramic
HFCN-3800TR5K+
This is HFCN-3800+
Reel Qty. 5000 pcs.
Maximum Ratings
Operating Temperature
Storage Temperature
RF Power Input*
Features
*Passband
rating, derate linearly to 3W at 100°C ambient
.
Pin Connections
RF IN
RF OUT
GROUND
*
*RF IN & RF OUT can be interchanged
1**
3**
2,4,5,6
• Low Cost
• Small size
• 5 sections
• Temperature stable
• Excellent power handling, 7W
• DC block in/out, breakdown voltage, 1kV typ.
• Hermetically sealed
• Patent pending
CASE STYLE: FV1206-1
Price: Contact Sales Dept.
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix has been added in order to identify RoHS
Compliance. See our web site for RoHS Compliance
methodologies and qualifications.
Application
• Sub-harmonic rejection and DC blocking
• Transmitters/Receivers
Outline Drawing
High Pass Filter Electrical Specifications
1
(T
AMB
= 25
O
C)
STOPBAND
(MHz)
fco, MHz
Nom.
PASSBAND
(MHz)
VSWR
Typ.
POWER
NO. OF
(Loss>30dB) (Loss>20dB) (Loss 3dB) (Loss<1.5dB) (Loss<2dB) Stopband Frequency
(MHz)
Typ.
Min.
Typ.
Max.
Max.
1.5:1
DC-F1
DC-F2
F3
F4-F5
DC-3100
DC-3200
3800
4500-9000
4250-10000
20:1
3950-10000
INPUT SECTIONS
(W)
Max.
7
5
1. For Applications requiring DC voltage to be applied to the input or output, use HFCN-3800D (DC Resistance to
ground is 100 Mohms min.)
Typical Frequency Response
ATTENUATION(dB)
PCB L and Pattern
Electrical Schematic
RF IN
RF OUT
30dB
20dB
3dB
1.5dB
F1 F2 F3 F4
FREQUENCY(MHz)
NON-CATALOG
F5
Typical Performance Data at 25
o
C
Suggested L ayout,
Tolerance to be with in
±.002
Outline Dimensions (
inch
)
mm
A
B
C
D
E
F
G
H
J
K wt.
.126 .063 .035 .024 .022 .012 .039 .042 .024 .123
grams
3.20 1.60 0.89 0.61 0.56 0.30 0.99 1.07 0.61 3.12 .02
Frequency
(MHz)
50
500
1500
3100
3200
3400
3550
3800
3950
4250
4500
7000
9000
10000
11330
12000
HFCN-3800TR5K+
INSERTION LOSS
Insertion Loss
(dB)
54.14
37.58
32.52
33.38
36.68
19.19
10.63
2.59
1.41
1.14
1.02
0.72
0.68
1.13
2.71
3.15
VSWR
(:1)
1737.18
1737.18
108.58
31.60
28.03
18.90
9.33
2.00
1.16
1.45
1.43
1.22
1.28
1.70
1.96
1.70
HFCN-3800TR5K+
VSWR
Demo Board MCL P/N: TB-285
Suggested PCB Layout(PL-158)
6X ø.015 PTH,
FOR GROUND
.012
PACKAGE
OUTLINE
.072 TYP
.010 TYP
.012
PIN 1
.073
.055
70
10000
1000
INSERTION LOSS(dB)
.044 ± .002
TRACE WIDTH, 2 PL.
(SEE NOTE BELOW)
.034
.010 TYP
60
50
40
30
20
10
0
0
4000
8000
12000
FREQUENCY (MHz)
1
.017
NOTES:
1. TRACE WIDTH IS SHOWN FOR ROGERS RO4350B
WITH DIELECTRIC THICKNESS .020” ± .0015”.
COPPER: 1/2 OZ. EACH SIDE.
FOR OTHER MATERIALS TRACE WIDTH MAY NEED
TO BE MODIFIED.
2. BOTTOM SIDE OF THE PCB IS CONTINUOUS GROUND PLANE.
DENOTES PCB COPPER LAYOUT WITH SMOBC
(SOLDER MASK OVER BARE COPPER)
DENOTES COPPER LAND PATTERN FREE OF SOLDER MASK
VSWR
100
10
0
4000
8000
12000
FREQUENCY (MHz)
®
EW
ALL N
Mini-Circuits
ISO 9001 ISO 14001
CERTIFIED
RF/IF MICROWAVE COMPONENTS
minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
The Design Engineers Search Engine
Provides ACTUAL Data Instantly From MINI-CIRCUITS At:
www.minicircuits.com
REV. OR
M121048
EDR-6982/4
HFCN-3800TR5K+
RAV
090205
page 1 of 1
