HFTC-19+: DescriptionCeramic HPF, 7 Section(s) Min, 7 Section(s) Max, 1995MHz, ROHS COMPLIANT, HERMETIC SEALED, MINIATURE, CASE FR933, 6 PIN; Categoryfilter Ceramic filter; File Size195KB，1 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com; Environmental Compliance

Download Datasheet Parametric View All

HFTC-19+ Overview

Ceramic HPF, 7 Section(s) Min, 7 Section(s) Max, 1995MHz, ROHS COMPLIANT, HERMETIC SEALED, MINIATURE, CASE FR933, 6 PIN

HFTC-19+ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Mini-Circuits
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Maximum attenuation frequency (+/- delta f)	545000 kHz
Attenuation frequency (+/-Δf) - minimum value	345000 kHz
Attenuation at maximum frequency	40 dB
Attenuation@frequency min	20 dB
average input power	10 W
Center frequency or cutoff frequency (fo/fc)	1995 MHz
filter type	CERAMIC HPF
high	0.71 mm
Input/output impedance	50 OHM
Maximum insertion loss	3 dB
JESD-609 code	e4
length	3.81 mm
Installation type	SURFACE MOUNT
Number of partitions-max	7
Number of partitions - minimum	7
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
physical size	L3.81XB3.81XH0.71 (mm)/L0.15XB0.15XH0.028 (inch)
Terminal surface	Palladium/Silver (Pd/Ag)
voltage standing wave ratio	1.3
width	3.81 mm
Base Number Matches	1

Preview

Download Datasheet

View All

High Pass Filter

50Ω

Operating Temperature

Storage Temperature

Ceramic

HFTC-19+

HFTC-19

2300 to 5500 MHz

Features

-55°C to 100°C

-55°C to 125°C

Maximum Ratings

Pin Connections

RF IN

RF OUT

GROUND

** RF IN & RF OUT can be interchanged

• miniature size, 0.15”X0.15”

• low proﬁle, 0.028” height

• low pass-band insertion loss, 1.0 dB typ.

• excellent input power handling, 10W

• hermetically sealed

CASE STYLE: FR933

PRICE: $3.75 ea. QTY. (10-49)

+ RoHS compliant in accordance

with EU Directive (2002/95/EC)

The +Sufﬁx identiﬁes RoHS Compliance. See our web site

for RoHS Compliance methodologies and qualiﬁcations.

2**

5**

1,3,4,6

Applications

• sub-harmonic rejection

• transmitters/receivers

• dc blocking

Outline Drawing

Electrical Speciﬁcations (T

AMB

=25°C)

STOP BAND

(MHz)

(loss > 40 dB) (loss > 20 dB)

DC-1450

1650

* Derate linearly to 4W at 100°C ambient.

fco, MHz

Nom.

(loss 3 dB)

Typ.

1995

PASSBAND

(MHz)

(loss < 1.3 dB)

2300-5500

VSWR

(:1)

Stopband Passband

Typ.

1.3

POWER MARKING

INPUT*

(W)

NO. OF

SECTIONS

HF6

typical frequency response

PCB Land Pattern

ATTENUATION

40dB

20dB

electrical schematic

RF IN

RF OUT

3dB

f co

Suggested Layout,

Tolerance to be within

.002

Typical Performance Data at 25°C

inch

.028

0.71

Outline Dimensions (

.150

3.81

.060

1.52

.150

3.81

.030

0.76

.028

0.71

.184

4.67

.050

1.27

.075

1.91

.035

0.89

.044

1.12

)

grams

0.15

Frequency

(MHz)

1.00

500.00

1000.00

1450.00

1650.00

1995.00

2300.00

3600.00

4000.00

5500.00

HFTC-19

INSERTION LOSS

Insertion Loss

(dB)

103.75

49.23

42.91

54.47

27.32

4.42

0.94

0.51

0.52

0.66

HFTC-19

VSWR

(:1)

436.58

81.78

64.39

47.42

32.07

3.50

1.19

1.11

1.16

1.25

Demo Board MCL P/N: TB-233

Suggested PCB Layout (PL-112)

1000

INSERTION LOSS (dB)

100

0.1

1000

100

VSWR

1100

2200

3300

4400

5500

1100

2200

3300

4400

5500

FREQUENCY (MHz)

Distribution Centers

NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010

Mini-Circuits

INTERNET

http://www.minicircuits.com

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661

Mini-Circuits

ISO 9001 & ISO 14001

Certified

REV. E

M98898

HFTC-19

EDB-020541

WZ/RS/CP

060912
