Solderless terminals
QUICK DISCONNECT
Male, Vinyl-insulated with copper sleeve
E
L
File No.:
E70188
LR20812
Dimensions mm (in.)
Tool No.
YNT-2216
YNT-1614
YNT-1210S
YA-1
YA-2
YA-4
BCT-0514
o
o
o
o o o o
o o o o
o o
L
Applicable Wire
AWG#(mm
2
)
øD
W
Part No.
Standard
W
L
E
øD
Material Mating Tab
Thickness Thickness
Color
Qty/box
250
22 to 16 (0.25 to 1.65)
FVDDM1.25-250
16 to 14 (1.04 to 2.63)
FVDDM2 -250
12 to 10 (2.63 to 6.64)
FVDDM5.5 -250
6.3 (.248) 20.5 (.807) 8.0 (.315) 3.5 (.138) 9.5 (.374) 0.4 (.016) 0.8 (.031)
6.3 (.248) 20.5 (.807) 8.0 (.315) 4.3 (.169) 9.5 (.374) 0.4 (.016) 0.8 (.031)
Red
Blue
6.3 (.248) 24.5 (.965) 8.5 (.335) 6.2 (.244) 13.5 (.531) 0.4 (.016) 0.8 (.031) Yellow
1,000
1,000
500
Note:1)
Delivery lead times may vary depending on the product. Contact JST for details.
Solderless terminals
PIGGYBACK
Vinyl-insulated with copper sleeve
W
2
T
E
2
E
1
File No.:
E70188
LR20812
Dimensions mm (in.)
Tool No.
YNT-2216
YNT-1614
YA-1
YA-2
YA-4
BCT-0514
o
o o o o
o o o o o
Material
Thickness
0.4
(.016)
0.4
(.016)
Color
T
0.8
(.031)
0.8
(.031)
Red
Blue
Qty/box
Applicable Wire
AWG#(mm
2
)
Part No.
Standard
W
W
1
7.4
(.291)
7.6 (.299)
7.4 (.291)
W
2
6.3
(.248)
L
20.5
(.807)
22.0(.866)
E
E
1
7.8
(.307)
7.8
(.307)
E
2
8.0
(.315)
8.0
(.315)
øD
3.5
(.138)
4.3
(.170)
9.5
(.374)
9.5
(.374)
22 to 16 (0.25 to 1.65)
FVDDFM1.25-250A
250
16 to 14 (1.04 to 2.63)
FVDDFM2
FVDDFM2
-250A
-250B
W
1
øD
500
500
6.3
(.248) 22.2(.874)
Note:1) Terminals FVDDFM2-250A have no slits in the receptacle part.
2)
Delivery lead times may vary depending on the product. Contact JST for details.
64
