THROUGH-HOLE RADIAL LEADED INDUCTOR
AIRD-110A&B SERIES
| | | | | | | | | | | | | | |
STANDARD SPECIFICATIONS:
Part Number
2
L
1,4
(µH)
1.0
1.0
3.3
4.7
4.7
4.7
10
10
10
10
15
15
22
22
22
27
33
47
47
47
82
100
100
100
150
150
180
220
270
270
390
390
I
DC
5
(A)
25
10
10
3
10
20
3
5
10
20
3
10
3
5
10
5
12
3
5
10
3
1
3
5
3
5
5
3
4
10
3
5
DCR
(Ω MAX)
0.002
0.002
0.005
0.021
0.012
0.004
0.023
0.017
0.015
0.006
0.025
0.020
0.035
0.023
0.015
0.024
0.017
0.050
0.035
0.022
0.110
0.190
0.072
0.055
0.140
0.065
0.110
0.210
0.250
0.160
0.250
0.190
A
6
(MAX)
0.60/15.2
0.50/12.7
0.5/12.7
0.51/13.0
0.50/12.7
0.53/13.5
0.50/12.7
0.50/12.7
0.52/13.2
0.75/19.1
0.50/12.7
0.52/13.2
0.50/12.7
0.50/12.7
0.66/16.8
0.50/12.7
0.70/17.8
0.55/14.0
0.65/16.5
0.85/21.6
0.50/12.7
0.40/10.2
0.55/14.0
0.65/16.5
0.60/15.2
0.65/16.5
0.65/16.5
0.55/14.0
0.95/24
1.1/28
1.1/28
1.1/28
B
6
(MAX)
0.68/17.3
0.75/19.1
1.0/25.4
0.75/19.1
1.0/25.4
1.2/30.5
0.75/19.1
0.75/19.1
1.0/25.4
1.8/45.7
1.0/25.4
1.0/25.4
1.0/25.4
1.0/25.4
1.3/33.0
1.0/25.4
1.3/33.0
1.0/25.4
1.1/28.0
1.3/33.0
0.65/16.5
0.90/22.9
1.2/30.5
1.3/33.0
1.2/30.5
1.3/33.0
1.3/33.0
1.2/30.5
0.72/18.3
1.0/25.4
1.0/25.4
1.0/25.4
C
6
0.42/10.7
0.42/10.7
0.42/10.7
0.42/10.7
0.42/10.7
0.42/10.7
0.42/10.7
0.42/10.7
0.42/10.7
0.60/15.2
0.42/10.7
0.42/10.7
0.42/10.7
0.42/10.7
0.42/10.7
0.49/12.5
0.55/14.0
0.42/10.7
0.70/17.8
0.70/17.8
0.375/9.5
0.30/7.6
0.70/17.8
0.70/17.8
0.43/10.9
0.70/17.8
0.70/17.8
0.42/10.7
0.71/18
0.72/18.3
0.72/18.3
0.72/18.3
D
6
0.068/1.73
0.054/1.37
0.054/1.37
0.035/0.89
0.054/1.37
0.068/1.73
0.035/0.89
0.042/1.07
0.054/1.37
0.075/1.91
0.035/0.89
0.054/1.37
0.035/0.89
0.035/0.89
0.060/1.52
0.042/1.07
0.060/1.52
0.035/0.89
0.042/1.07
0.060/1.52
0.028/0.71
0.020/0.51
0.035/0.89
0.042/1.07
0.028/0.71
0.042/1.07
0.042/1.07
0.025/0.64
0.030/0.76
0.038/0.097
0.035/0.89
0.038/0.97
AIRD-110A-1R0K-25
AIRD-110A-1R0K-10
AIRD-110A-3R3K-10
AIRD-110A-4R7K-03
AIRD-110A-4R7K-10
AIRD-110A-4R7K-20
AIRD-110A-100K-03
AIRD-110A-100K-05
AIRD-110A-100K-10
AIRD-110A-100K-20
AIRD-110A-150K-03
AIRD-110A-150K-10
AIRD-110A-220K-03
AIRD-110A-220K-05
AIRD-110A-220K-10
AIRD-110A-270K-05
AIRD-110A-330K-12
AIRD-110A-470K-03
AIRD-110A-470K-05
AIRD-110A-470K-10
AIRD-110A-820K-03
AIRD-110A-101K-01
AIRD-110A-101K-03
AIRD-110A-101K-05
AIRD-110A-151K-03
AIRD-110A-151K-05
AIRD-110A-181K-05
AIRD-110A-221K-03
AIRD-110A-271K-04
AIRD-110A-271K-10
AIRD-110A-391K-03
AIRD-110A-391K-05
PHYSICAL CHARACTERISTICS:
A
TECHNICAL INFORMATION:
• Inductance (L) measured @ 10 kHz 0.1 V
RMS
.
• Note 2: Change A to B in P/N for header mounting
• Operating temperature -40
o
C to 125
o
C
• Inductance (L) tolerance: j = 5%, k = 10%, m = 20%
• Rating for continuous operation
• Dimensions: inches / mm; see spec sheet for tolerance limits
Note:
All specifications subject to change without notice.
B
See Note #2
D
0.250
(6,35)
C
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
rev1.1-8/04
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001
| www.abracon.com
