AIC1735
500mA Low Dropout Linear Regulator
n
FEATURES
l
n
DESCRIPTION
The AIC1735 is a 3-pin low dropout linear
regulator. The superior characteristics of the
AIC1735 include zero base current loss, very
low dropout voltage, and 2% accuracy output
voltage.
Typical
ground
current
from
no
remains
load
to
approximately
65
µ
A,
Low Dropout Voltage of 650mV at 500mA
Output Current (3V Output Version).
Guaranteed 500mA Output Current.
Low Ground Current at 65µA.
2% Accuracy Output Voltage of 1.8V/ 2.0V
/2.5V /2.7V/ 3.0V/ 3.3V/ 3.5V/ 3.7V/ 3.8V/ 5.0V/
5.2V.
l
l
l
maximum loading conditions. Dropout voltage
at 100mA output current is exceptionally low.
Output current limiting and thermal limiting are
built in to provide maximal protection to the
AIC1735 against fault conditions.
The AIC1735 comes with the popular SOT-
223 and TO-252 packages.
l
l
Needs only 4.7µF for Stability.
Current and Thermal Limiting.
n
APPLICATIONS
l
l
l
l
l
l
Voltage Regulator for CD-ROM Drivers.
Voltage Regulator for LAN Cards.
Voltage Regulator for Microprocessor.
Voltage Regulator for RAM Module.
Wireless Communication Systems.
Battery Powered Systems.
n
TYPICAL APPLICATION CIRCUIT
VIN
V
IN
AIC1735
VOUT
V
OUT
+
1
µ
F
C
IN
GND
+
4.7
µ
F
C
OUT
Low Dropout Linear Regulator
Analog Integrations Corporation
4F, 9 Industry E. 9th Rd, Science-Based Industrial Park, Hsinchu, Taiwan
TEL: 886-3-5772500
FAX: 886-3-5772510
www.analog.com.tw
DS-1735-01 040902
1
AIC1735
n
ORDERING INFORMATION
AIC1735-XXCX XX
PACKING TYPE
TR: TAPE & REEL
TB: TUBE
PACKAGE TYPE
E: TO-252
Y: SOT-223
OUTPUT VOLTAGE
18: 1.8V
20: 2.0V
25: 2.5V
27: 2.7V
30: 3.0V
33: 3.3V
35: 3.5V
37: 3.7V
38: 3.8V
50: 5.0V
52: 5.2V
Example: AIC1735-18CETR
à
1.8V Version, in TO-252 Package &
Tape & Reel Packing Type
PIN CONFIGURATION
TO-252 (CE)
TOP VIEW
1: VOUT
2. GND
3. VIN
SOT-223 (CY)
TOP VIEW
1: VOUT
2. GND
3. VIN
1
2
3
1
2
3
n
ABSOLUTE MAXIMUM RATINGS
Input Supply Voltage...................................................…
… … … ..… … .................. -0.3~12V
Operating Junction Temperature Range
.....… … … ........… … … … ................ -40°C~
85°C
Storage Temperature Range
....................… … ......................… … … .............
-65°C~150°C
Thermal Resistance
θ
JC
TO-252 Package
...… .… … … ..…
12.5°C/W
SOT-223 Package
.....… … … ........
15°C/W
n
TEST CIRCUIT
Refer to the TYPICAL APPLICATION CIRCUIT
2
AIC1735
n
ELECTRICAL CHARACTERISTICS
(T
A
=25°C, C
IN
=1µF, C
OUT
=4.7µF, unless
otherwise specified.)
PARAMETER
TEST CONDITIONS
No Load
AIC1735-52
AIC1735-50
AIC1735-38
AIC1735-37
AIC1735-35
AIC1735-33
AIC1735-30
AIC1735-27
AIC1735-25
AIC1735-20
AIC1735-18
(Note 1)
I
L
=1mA,
1.4V≤V
OUT
≤3.2V
3.3V≤V
OUT
≤5.2V
I
L
=0.1~500mA
1.4V≤V
OUT
≤3.9V
4.0V≤V
OUT
≤5.2V
V
IN
=7V, V
OUT
=0V
4.0V≤V
OUT
≤5.2V
3.0V≤V
OUT
≤3.9V
2.5V≤V
OUT
≤2.9V
2.0V≤V
OUT
≤2.4V
1.4V≤V
OUT
≤1.9V
V
IN
=5~12V
V
IN
=7~12V
V
IN
=5.5~12V
V
IN
=5.5~12V
V
IN
=4.7~12V
V
IN
=4.7~12V
V
IN
=4.7~12V
V
IN
=4.7~12V
V
IN
=4.0~12V
V
IN
=4.0~12V
V
IN
=4.0~12V
V
IN
=4.0~12V
V
IN
=4.0~12V
MIN.
5.100
4.900
3.725
3.625
3.430
3.235
2.940
2.646
2.450
1.960
1.764
TYP.
5.200
5.000
3.800
3.700
3.500
3.300
3.000
2.700
2.500
2.000
1.800
50
MAX.
5.300
5.100
3.875
3.775
3.570
3.365
3.060
2.754
2.550
2.040
1.836
UNIT
Output Voltage
V
Output Voltage
Temperature
Coefficiency
Line Regulation
PPM/°C
V
IN
=4V~12V
V
IN
=5.5V~12V
V
IN
=5V
V
IN
=7V
500
3
3
10
20
10
10
30
50
mV
Load Regulation
(Note 2)
Current Limit
(Note 3)
mV
mA
510
650
780
1100
1400
65
65
90
90
Dropout Voltage
(Note 4)
I
L
=500mA
mV
Ground Current
I
O
=0.1mA~I
MAX
1.4V≤V
OUT
≤3.9V
4.0V≤V
OUT
≤5.2V
µA
Note 1:
Note 2:
Note 3:
Note 4:
Guaranteed by design.
Regulation is measured at constant junction temperature, using pulse testing with a low ON time.
Current limit is measured by pulsing a short time.
Dropout voltage is defined as the input to output differential at which the output voltage drops
100mV below the value measured with a 1V differential.
3
