FINISHED RECEPTACLE TERMINALS
PART NUMBER
CONTACT PLATING OPTION
L
WIRE SIZE [AWG]
DIM A
5.54
5.54
4.54
4.54
4.54
4.54
L
172253-3023
172253-3123
172253-3011
172253-3111
172253-3012
172253-3112
TIN/NICKEL
TIN/NICKEL
15AU/NICKEL
15AU/NICKEL
30AU/NICKEL
30AU/NICKEL
16-18
20-22
16-18
20-22
16-18
20-22
SEE DETAIL 3
K
3.45
+0.10
-0.29
1.41
1.41
K
J
DETAIL 3
SCALE 2:1
J
H
DIM "A"
REF
H
19.87
REF
Z
G
Z
DIM "B"
16-18 AWG
20-22 AWG
G
2.71
2.77
2.63
2.89
2.16
2.20
2.08
2.33
F
0.20
REF
CUT OFF VESTIGE
DIM "C"
DIM "D"
DIM "E"
Y
⌀
1.50
F
Y
3.79
REF
DIM "C"
DIM "E"
E
NOTES:
2.97
REF
8.50
REF
E
1. MATERIAL: HIGH CONDUCTIVITY COPPER ALLOY
2. PLATING FINISH:
OPTION 1 - 1.5µm(60µin)-2.5µm(100µin) TIN OVER
1.25µm(50µin)-2.5µm(100µin) NICKEL OVERALL
OPTION 2 - 0.35µm(15µin) GOLD CONTACT AREA,
17.00
REF
DIM "B"
DIM "D"
D
1.5µm(60µin)-2.5µm(100µin) TIN CRIMP AREA OVER
D
1.25µm(50µin)-2.5µm(100µin) NICKEL OVERALL
OPTION 3 - 0.70µm(30µin) GOLD CONTACT AREA,
1.5µm(60µin)-2.5µm(100µin) TIN CRIMP AREA OVER
1.25µm(50µin)-2.5µm(100µin) NICKEL OVERALL
3. PRODUCT SPECIFICATION PS-172323-0001
4. PACKAGING SPECIFICATION PK-172253-5101
SECTION
Z-Z
SECTION
Y-Y
C
5. TERMINAL FOR USE WITH 172256, 172258, 172260 AND 172262
C
RECEPTACLE HOUSING
6. WHEN TERMINALS ARE INSTALLED IN THE HOUSING THE WIRES
ARE TO BE DRESSED IN SUCH WAY TO ALLOW THE TERMINALS TO
FLOAT FREELY IN THE POCKET
7. TERMINAL DESIGNED FOR SINGLE WIRE CRIMP
8. PART CONFORMS TO CLASS "B" REQUIREMENTS OF COSMETIC
SPECIFICATION PS-45499-002
9.APPLICATION SPECIFICATION AS-172323-0001
B
MXN
B
2016/05/24
2016/05/24
2015/09/29
QUALITY THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX INCORPORATED AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
DIMENSION UNITS
SCALE
GENERAL
SYMBOLS
TOLERANCES
mm
1:1
=
0
(UNLESS SPECIFIED)
DRWN BY
DATE
10.RECOMMENDED INSULATOR
16AWG WIRE - OD 2.00MM MAX.
18AWG WIRE - OD 1.70MM MAX.
20AWG WIRE - OD 1.50MM MAX.
22AWG WIRE - OD 1.30MM MAX.
MOLEX LOGO
SCALE 8:1
EC DESCRIPTION
=
=
=
=
0
0
0
0
0
0
0
ANGULAR TOL ±
°
4 PLACES
3 PLACES
±
±
±
±
±
DROSCA
CHK'D BY
DATE
2014/03/07
2015/11/13
DATE
ULTRA-FIT RECEPTACLE
