Printed-circuit board connector - MC 1,5/ 5-G-3,5 P14 THR - 1789009
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Header, Nominal current: 8 A, Rated voltage (III/2): 160 V, Number of positions: 5, Pitch: 3.5 mm, Color: black,
Contact surface: Tin, Mounting: THR soldering
Key Commercial Data
Packing unit
Minimum order quantity
Custom tariff number
Country of origin
1 pc
50 pc
85366990
Germany
Technical data
Dimensions
Length
Pitch
Dimension a
Width
Constructional height
Height
Length of the solder pin
Pin dimensions
Hole diameter
9.2 mm
3.50 mm
14 mm
18.9 mm
6.9 mm
8.3 mm
1.4 mm
0,8 x 0,8 mm
1.4 mm
General
Range of articles
Insulating material group
Rated surge voltage (III/3)
Rated surge voltage (III/2)
MC 1,5/..-G-THR
IIIa
2.5 kV
2.5 kV
04/12/2016 Page 1 / 4
https://www.phoenixcontact.com/us/products/1789009
Printed-circuit board connector - MC 1,5/ 5-G-3,5 P14 THR - 1789009
Technical data
General
Rated surge voltage (II/2)
Rated voltage (III/3)
Rated voltage (III/2)
Rated voltage (II/2)
Connection in acc. with standard
Nominal current I
N
Maximum load current
Insulating material
Flammability rating according to UL 94
Color
Number of positions
2.5 kV
160 V
160 V
250 V
EN-VDE
8A
8A
LCP
V0
black
5
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
EN-VDE
CUL
V0
Classifications
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 7.0
eCl@ss 8.0
eCl@ss 9.0
272607xx
27260701
27260701
27260701
27260704
27440402
27440402
27440402
ETIM
ETIM 4.0
ETIM 5.0
EC002637
EC002637
UNSPSC
UNSPSC 6.01
UNSPSC 7.0901
UNSPSC 11
UNSPSC 12.01
30211810
39121409
39121409
39121409
04/12/2016 Page 2 / 4
https://www.phoenixcontact.com/us/products/1789009
Printed-circuit board connector - MC 1,5/ 5-G-3,5 P14 THR - 1789009
Classifications
UNSPSC
UNSPSC 13.2
39121409
Approvals
Approvals
Approvals
VDE Gutachten mit Fertigungsüberwachung / EAC / cULus Recognized / IECEE CB Scheme / EAC
Ex Approvals
Approvals submitted
Approval details
VDE Gutachten mit Fertigungsüberwachung
Nominal current IN
Nominal voltage UN
8A
160 V
EAC
cULus Recognized
Nominal current IN
Nominal voltage UN
B
8A
300 V
D
8A
300 V
IECEE CB Scheme
Nominal current IN
Nominal voltage UN
8A
160 V
04/12/2016 Page 3 / 4
https://www.phoenixcontact.com/us/products/1789009
Printed-circuit board connector - MC 1,5/ 5-G-3,5 P14 THR - 1789009
Approvals
EAC
Drawings
Drilling diagram
a
3,5
(3,81)
2,45
(2,6)
18,7
9,2
a+4,9
(a+5,2)
Dimensional drawing
Ø1,4
8
11,1
8
1,4
6,9
2,45
(2,6)
3,5
(3,81)
a
Diagram
Current strength [A]
16
14
12
10
8
6
4
2
0
0
= 2-pos.
= 5-pos.
= 12-pos.
20
40
60
80
100
Ambient temperature [°C]
Type: MC 1,5/...-ST(F)-3,5 with MC 1,5/...-G(F)-3,5 P.. THR
Phoenix Contact 2016 © - all rights reserved
http://www.phoenixcontact.com
04/12/2016 Page 4 / 4
