ETD49/25/16-3C97-G500

Description
ER AND ETD CORES
CategoryPassive components
File Size68KB,2 Pages
ManufacturerFerroxcube
Websitehttp://www.ferroxcube.com/
Environmental Compliance
Download Datasheet View All

ETD49/25/16-3C97-G500 Overview

ER AND ETD CORES

Product specifications
Core
ETD49/25/16
Effective parameters
Symbol
∑(I/A)
Ve
Le
Ae
Amin
m
Parameter
core factor (C1)
effective volume
effective length
effective area
minimum area
ETD49/25/16
Value
0.534
24000
114
211
209
≈ 62
Unit
mm⁻¹
mm³
mm
mm²
mm²
g/pcs
Dimensions for product: ETD49/25/16
Symbol
A
B
D2
D3
E
F
Nom
49.80
16.70
36.10
16.70
24.70
17.70
Tol +
0.00
0.00
1.80
0.00
0.20
0.80
Tol -
2.20
0.60
0.00
0.60
0.20
0.00
Max
49.80
16.70
37.90
16.70
24.90
18.50
Min
47.60
16.10
36.10
16.10
24.50
17.70
Unit
mm
mm
mm
mm
mm
mm
Inductance factor
Material
3C94
3C95
3C97
3F36
Value
4200
5140
5140
2800
Tol +
25%
25%
25%
25%
Tol -
25%
25%
25%
25%
Unit
nH/turns²
nH/turns²
nH/turns²
nH/turns²
Power loss: 3C94
Measuring conditions
100 kHz
200 mT
100 ºC
Power loss: 3C95
Measuring conditions
100 kHz
100 kHz
200 mT
200 mT
100 ºC
25 ºC
Power loss: 3C97
Measuring conditions
100 kHz
200 mT
60 ºC
Max
12.000
Unit
W/set
Max
12.000
12.000
Unit
W/set
W/set
Max
12.000
Unit
W/set
