High Temperature Caps -
160°C, 200°C
A range of chip capacitors, available in sizes 0805 to 7565, designed
to operate from -55°C to 160°C, (Class II Dielectric) and from
-55ºC to 200ºC (C0G/NP0 and Class II Dielectrics). Voltage ratings
of 25V to 4kV.
Maximum capacitance values - 160
o
C C0G (F)/Class II (G) and 200
o
C C0G/NP0 (D)/Class II (E) Dielectrics
Size
Tmax
0805
0.054
1.37
1206
0.064
1.63
1210
0.065
1.65
1515
0.130
3.30
1808
0.065
1.65
1812
0.065
1.65
1825
0.080
2.03
2225
0.080
2.03
3530
0.250
6.35
4540
0.300
7.62
6560
0.300
7.62
7565
0.300
7.62
Maximum capacitance values - C0G/NP0 - 160
o
C (F) and 200
o
C (D)
Min cap.
0R5
2.7nF
1.8nF
680pF
180pF
100pF
47pF
•
•
•
1R0
5.6nF
3.9nF
1.8nF
1.0nF
390pF
100pF
27pF
•
•
5R0
12nF
8.2nF
3.3nF
2.2nF
820pF
220pF
56pF
•
•
5R0
22nF
18nF
10nF
3.9nF
2.7nF
820pF
180pF
82pF
47pF
120
12nF
8.2nF
3.3nF
2.2nF
1.0nF
220pF
56pF
22pF
12pF
220
22nF
15nF
8.2nF
5.6nF
2.2nF
560pF
120pF
56pF
27pF
330
56nF
39nF
15nF
12nF
3.9nF
820pF
180pF
82pF
33pF
470
56nF
47nF
18nF
18nF
5.6nF
1.0nF
270pF
100pF
47pF
221
100nF
82nF
56nF
33nF
12nF
5.6nF
1.5nF
560pF
330pF
390
180nF
150nF
100nF
56nF
27nF
15nF
3.3nF
1.5nF
820pF
560
330nF
270nF
220nF
120nF
56nF
33nF
8.2nF
3.3nF
1.8nF
101
390nF
330nF
270nF
150nF
68nF
39nF
10nF
3.9nF
2.2nF
25V
50V
100V
250V
500V
1kV
3kV
4kV
inches:
2kV
mm:
Maximum capacitance values - Class II - 160
o
C (G) and 200
o
C (E)
Min cap.
121
82nF
47nF
18nF
4.7nF
1.0nF
180pF
•
•
•
121
220nF
120nF
47nF
10nF
2.2nF
390pF
•
•
•
121
390nF
220nF
100nF
27nF
5.6nF
820pF
150pF
•
•
151
820nF
680nF
270nF
68nF
18nF
2.7nF
560pF
•
•
151
330nF
270nF
82nF
22nF
5.6nF
820pF
•
•
•
151
680nF
470nF
150nF
47nF
10nF
1.5nF
220pF
•
•
471
1.5µF
1.0µF
470nF
120nF
27nF
4.7nF
560pF
•
•
471
1.8µF
1.2µF
470nF
150nF
33nF
5.6nF
680pF
•
•
102
3.9µF
2.7µF
2.2µF
560nF
120nF
27nF
6.8nF
2.7nF
1.2nF
102
5.6µF
4.7µF
3.3µF
1.2µF
330nF
68nF
18nF
6.8nF
2.7nF
222
15µF
12µF
8.2µF
2.7µF
680nF
150nF
39nF
15nF
5.6nF
222
18µF
15µF
12µF
3.9µF
820nF
220nF
47nF
18nF
8.2nF
25V
50V
100V
250V
500V
1kV
2kV
3kV
4kV
Ordering information - High Temperature Capacitors
1206
Chip
size
0805
1206
1210
1515
1808
1812
1825
2225
3530
4540
6560
7565
G
Dielectric
codes
F
= C0G/NP0
High Temp.
(up to 160ºC)
D
= C0G/NP0
High Temp.
(up to 200ºC)
E
= Class II
High Temp.
(up to 200ºC)
G
= Class II
High Temp.
(up to 160ºC)
224
Capacitance in
picofarads (pF)
Value in
Picofarads.
Two significant
figures, followed
by number of
zeros:
224
= 220nF
(220,000pF)
K
Capacitance
tolerance code
F
= ±1% (C0G/NP0)
G
= ±2% (C0G/NP0)
J
= ±5% (X8R)
K
= ±10% (Class II)
M
= ±20% (Class II)
250
Voltage
code
Two
significant
figures,
followed by
number of
zeros:
250
= 25
Volts
N
Termination
codes
P
= Palladium Silver
PR
= Palladium Silver*
K
= Solderable Palladium Silver*
N
= Nickel Barrier* 100% tin
Y
= Nickel Barrier* 90% tin, 10% lead
C
= FlexiCap™/Nickel Barrier* 100% tin
D
= FlexiCap™/Nickel Barrier* 90% tin,
10% lead
S
= Solderable Silver*
*Indicates RoHS terminations
Note: Nickel barrier not available
in 200ºC dielectric
X050
Thickness
options
Blank
=
Standard
thickness
“X“
=
Special
thickness,
specified in
inches:
X050
=
0.050”
H
High
Reliability
Testing
High
Temperature
Screening
T
Packaging
None
=
Bulk
T
=
Tape &
Reel
W
=
Waffle
Pack
M
Marking
None
=
Unmarked
M
=
Marked
*Marking not
available
on sizes
<0603
www.knowlescapacitors.com
Should be ordered as Novacap parts.
